HUAWEI E1615 HSDPA USB
Stick
Quick Start
Copyright © Huawei Technologies Co., Ltd. 2009.
All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any
means without prior written consent of Huawei Technologies Co., Ltd.
The product described in this manual may include copyrighted software of Huawei
Technologies Co., Ltd and possible licensors. Customers shall not in any manner
reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse
engineer, lease, assign, or sublicense the said software, unless such restrictions
are prohibited by applicable laws or such actions are approved by respective
copyright holders under licenses.
Trademarks and Permissions
, HUAWEI, and
are trademarks or registered trademarks of Huawei
Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned are the
property of their respective owners.
Notice
Some features of the product and its accessories described herein rely on the
software installed, capacities and settings of local network, and may not be
activated or may be limited by local network operators or network service
providers, thus the descriptions herein may not exactly match the product or its
accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or modify any
information or specifications contained in this manual without prior notice or
obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED
BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN
RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL
HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL,
INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and regulations
and will obtain all necessary governmental permits and licenses in order to export,
re-export or import the product mentioned in this manual including the software
and technical data therein.
i
Table of Contents
What Is in Your Package ......................................................................... 1
Getting to Know Your USB Stick............................................................... 2
Preparation........................................................................................... 4
Installation/Removal Guide...................................................................... 5
Safety Information................................................................................. 8
1
Thank you for choosing Huawei HSDPA USB Stick.
With the USB Stick, you can access the Internet
through wireless network at a high speed.
Note:
This manual describes the appearance, installation and removal of the USB Stick.
For the operation of the management program, refer to the User Manual.
What Is in Your Package
The package of your USB Stick contains the following items:
One USB Stick
One Quick Start
One USB cable
Getting to Know Your USB Stick
The following figure shows the appearance of the USB Stick. It is only for your
reference. The actual product may differ.
1
23
nUSB Interface
It connects the USB Stick to a computer.
oIndicator
It indicates the status of the USB Stick.
Color Status Meaning
Green Blinking (on for 100ms and The USB Stick is powered on.
2
3
off for 100ms; then on for
100ms and off for
2700ms)
Green Blinking (on for 100ms and
off for 2900ms) The USB Stick is registered to a GPRS
(GSM/GPRS/EDGE) network.
Blue Blinking (on for 100ms and
off for 2900ms) The USB Stick is registered to a UMTS
(WCDMA/HSDPA) network.
Green On The USB Stick is connected to a GPRS
network.
Blue On The USB Stick is connected to a WCDMA
network.
Cyan On The USB Stick is connected to a HSDPA
network.
- Off The USB Stick is removed.
pSIM/USIM Card Slot
It is where you insert the subscriber identity module/UMTS subscriber identity
module (SIM/USIM) card.
Preparation
Requirements for the Computer
To use the USB Stick, the computer must meet the following requirements:
USB Type A Receptacle, Compatible with USB 2. 0 High Speeds.
Windows 2000 SP4, Windows XP SP2, Windows Vista.
Your computer’s hardware system should meet or exceed the recommended
system requirements for the installed version of OS.
Resolution for the display: 800 × 600 or above.
Getting Your USB Stick Ready
1. Remove the back cover of the USB Stick.
2. Insert the USIM/SIM card into the card slots. Make sure that the cards are
properly inserted.
3. Install the back cover of the USB Stick.
4
Installation/Removal Guide
On different operating systems (OSs), the installation and removal procedures
may differ. Follow the system prompts during operation.
Connecting the USB Stick with a Computer
Note:
First, power on the computer. Then connect the USB Stick with the computer.
Otherwise, the USB Stick cannot be installed as normal.
1. Plug the USB Stick into the USB interface of the laptop or desktop computer.
2. You can connect the USB Stick to a laptop or desktop computer using the USB
cable for better signals.
5
