Huawei E1831 Manual de usuario

Thank you for choosing the Mobile Broadband USB

Slider. With your USB Slider, you can access a wireless

network at high speed.

Note:

This manual describes the appearance of the USB Slider, as well as the procedures for

preparation, installation, and removal. For operation details about the management

program, see the online help included in the management program.

Getting to Know Your USB Slider

The following figure shows the appearance of the USB Slider. It is provided only for your

reference. The actual product may be different.

nUSB Connector

It connects the USB Slider to a PC.

oSlider

Press and slide the slider to extend or retract the USB Connector, as shown in the following

figure.

pMicroSD Card Slot

It holds a microSD card.

qIndicator

It indicates the status of the USB Slider.

zGreen, blinking twice every 3s: The USB Slider is powered on.

zGreen, blinking once every 3s: The USB Slider is registering with a 2G network.

zBlue, blinking once every 3s: The USB Slider is registering with a 3G/3G+ network.

zGreen, solid: The USB Slider is connected to a 2G network.

zBlue, solid: The USB Slider is connected to a 3G network.

zCyan, solid: The USB Slider is connected to a 3G+ network.

zOff: The USB Slider is removed.

rSIM/USIM Card Slot

It holds a Subscriber Identity Module (SIM)/Universal Subscriber Identity Module (USIM)

card.

Getting Your USB Slider Ready

Installing the SIM/USIM Card

1. Slide the back cover to remove it from the USB Slider.

2. Insert the SIM/USIM card into the corresponding card slots, as shown in the following

figure.

3. Replace the back cover and slide it into place.

Installing the microSD Card

Insert the microSD card into the USB Slider, as shown in the following figure.

Note:

zThe microSD card is an optional accessory. If it is not provided in the package, you can

buy one yourself.

zEnsure that the beveled edge of the SIM/USIM card is properly aligned with that of the

SIM/USIM card slot and the microSD card is inserted according to the direction as

labeled on the microSD card slot.

zDo not remove the microSD or SIM/USIM card when the card is in use. Otherwise, the

card as well as your USB Slider may get damaged and the data stored on the card may

be corrupted.

Installation/Removal Guide

The procedure for installing the management program depends on the operating system

(OS) installed on your PC. The following sections take Windows XP as an example.

Connecting the USB Slider to a PC

Push the slider on the side of the USB Slider to fully extend the USB connector. Then plug

the USB Slider into the USB port of your PC.

Installing the USB Slider Management Program

1. Connect the USB Slider with the PC.

2. The OS automatically detects and recognizes the new hardware and starts the

installation wizard.

Note:

If the auto-run program does not respond, find the AutoRun.exe file in the driver path.

Then double-click AutoRun.exe to run the program.

3. Follow the on-screen instructions of the installation wizard.

4. After the program is installed, a shortcut icon for the management program appears on

the desktop.

Starting the Management Program

After being installed, the management program starts automatically. Then every time the

USB Slider is connected to the PC, the management program starts automatically.

You can also double-click the shortcut icon on the desktop to start the management

program.

Removing the USB Slider

1. Double-click in the notification area. Then the Unplug or Eject Hardware dialog

box appears.

2. Select the corresponding hardware and then click Stop.

3. When the message "It is safe to remove the device" appears, remove the USB Slider.

Uninstalling the Management Program

1. Choose Start > Control Panel > Add or Remove Programs.

2. Find the management program and click Remove to uninstall the management

program.

Note:

Exit the management program before uninstalling it.

Version: V100R001_01 Part Number: 3101****
