Huawei E156C Manual de usuario

All RightsReserved

Nopartofthisdocumentmaybereproducedortransmittedinanyformorbyany

meanswithoutpriorwritten consent ofHuaweiTechnologiesCo.,Ltd.

TrademarksandPermissions

andotherHuaweitrademarks aretrademarks ofHuaweiTechnologiesCo.,

Ltd.

Allothertrademarks andtradenamesmentionedinthisdocumentare the

property oftheirrespective holders.

Notice

The informationinthisdocumentissubjecttochangewithout notice.Everyeffort

hasbeenmadeinthe preparationof thisdocumenttoensureaccuracy of the

contents,butall statements,information,andrecommendationsinthisdocument

donotconstitutethewarranty ofanykind,express orimplied.

Tableof Contents

WhatIsinYour Package........................................................................1

GettingtoKnowYourE156C...................................................................2

Preparation.........................................................................................5

Installation/RemovalGuide.....................................................................7

Safety Information.............................................................................10

AcronymsandAbbreviations.................................................................17

Thankyouforchoosing HuaweiE156C HSDPAUSB

Stick(hereinafter referred toasthe E156C).With

the E156C,you canaccess the Internetthrough

wireless networkatahighspeed.

Note:

Thismanualdescribesthe appearance,installationandremovaloftheE156C.For

theoperationof the management program,refertotheUserManual.

WhatIsinYourPackage

The package ofyourE156C containsthe followingitems:

nOne E156C

nOne Quick Start

nOne USBcable

GettingtoKnowYourE156C

The followingfigure showstheappearance ofthe E156C.Itisonly foryour

reference.The actualproductmaydiffer.

ŒUSBInterface

Itconnectsthe E156Ctoacomputer.

•SIM/USIMCardSlot

Itiswhere youinsertthe subscriberidentity module/UMTS subscriberidentity

module (SIM/USIM) card.

ŽMicroSDCardSlot

Itiswhere youinsertthe MicroSecureDigitalMemory(SD)card

•RF testingslot

Itconnectsthe RFtestcablesforRFtesting.

•StrapHole

‘Indicator

Itindicatesthe statusoftheE156C.

Colour

Status Meaning

Green

Blinking(onfor100msand

off for100ms; thenonfor

100msandoff for

2700ms)

The E156Cispoweredon.

Green

Blinking(onfor100msand

off for2900ms) The E156Cisregisteredtoa

GSM/GPRS/EDGEnetwork.

Blue Blinking(onfor100msand

off for2900ms) The E156CisregisteredtoaUMTS

network.

Green

On The E156CisconnectedtoaGPRS/EDGE

network.

Blue On The E156CisconnectedtoaWCDMA

network.

Cyan On The E156CisconnectedtoaHSDPA

network.

- Off The E156Cisremoved.

Preparation

RequirementsfortheComputer

TousetheE156C,the computershouldmeetthefollowingrequirements:

nUSB TypeAReceptacle,Compatible with USB 2.0HighSpeed.

nWindows2000SP4,WindowsXPSP2,WindowsVista.

nYour computershardwaresystemshouldmeetorexceedthe recommended

system requirementsfortheinstalledversionof OS.

nResolutionforthe display: 800 ×600orabove.

GettingYourE156CReady

1. Removethe USIM/SIMcardslotfromthe E156C.

2. Insert the USIM/SIMcardintothecardslot.

3. Insert the cardslotintotheE156C.

InsertingtheMicroSDCard(Optional)

Insert the microSDcardintotheE156C,asshowninthe followingfigure.

Note:

Donotremovethe microSDcardwhen itisbeingused.Removingthecardduring

an operationmay damagethe microSDcardaswell asthe device,anddata

storedonthecardmaybe corrupted.

Installation/Removal Guide

Ondifferentoperatingsystems(OSs),the installationandremovalprocedures

may differ.Followthe systempromptsduringoperation.

ConnectingtheE156Cwith aComputer

Note:

First,poweronthecomputer.ThenconnecttheE156C with the computer.

Otherwise,theE156C cannotbe installedasnormal.

1. Plugthe E156Cintothe USB interface ofthe laptopordesktopcomputer.

Youcanconnectthe E156CtoalaptopordesktopcomputerusingtheUSBcable

forbettersignals.

2. The OS automatically detectsandrecognisesnewhardware andstartsthe

installationwizard.

3. Followthe promptsoftheinstallationwizard.

4. Afterthe program isinstalled,ashortcuticonfortheE156Cmanagement

programisdisplayedonthedesktop.

StartingtheManagementProgram

AftertheE156Cisinstalled,themanagement programislaunchedautomatically.

Theneverytime the E156C isconnectedtothePC,the managementprogramis

launchedautomatically.

Youcanalsodouble-click the shortcuticononthe desktoptolaunchthe

management program.

RemovingtheE156C

Removethe E156Cdirectly.

RemovingtheManagementProgram

1. Click StartMenu.

2. Click ControlPanel.

3. Click Add/RemoveProgram toremove the managementprogram ofthe
