HPE Aruba 6300M Instrucciones de montaje

MF877-00 Page 1

Template Revision C, 30-July-2018

HPE instructions for this template are available at MF877-01

Product End-of-Life Disassembly Instructions

Product Category: Networking

Marketing Name / Model

[List multiple models if applicable.]

JL762A: Aruba 6300M 48G Pwr2Prt 2F 1PS Bdl

Name / Model #2

Name / Model #3

Name / Model #4

Name / Model #5

Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions

for the disassembly of HPE products to remove components and materials requiring selective treatment, as defined by

Directive 2012/19/EU of the European Parliament and of the Council on Waste Electrical and Electronic Equipment

(WEEE).

1.0

Items Requiring Selective Treatment

1.1 Items listed below are classified as requiring selective treatment.

1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as

applicable.

Item Description Notes

Quantity

of items

included

in product

Printed Circuit Boards (PCB) or Printed Circuit

Assemblies (PCA)

With a surface greater than 10 sq cm

Batteries All types including standard alkaline and lithium

coin or button style batteries

Mercury-containing components For example, mercury in lamps, display backlights,

scanner lamps, switches, batteries

Liquid Crystal Displays (LCD) with a surface

greater than 100 sq cm

Includes background illuminated displays with gas

discharge lamps

Cathode Ray Tubes (CRT)

Capacitors / condensers (Containing PCB/PCT)

Electrolytic Capacitors / Condensers measuring

greater than 2.5 cm in diameter or height

External electrical cables and cords

Gas Discharge Lamps

Plastics containing Brominated Flame Retardants

weighing > 25 grams (not including PCBs or PCAs

already listed as a separate item above)

Components and parts containing toner and ink,

including liquids, semi-liquids (gel/paste) and toner

Include the cartridges, print heads, tubes, vent

chambers, and service stations.

Components and waste containing asbestos

MF877-00 Page 2

Template Revision C, 30-July-2018

HPE instructions for this template are available at MF877-01

Item Description Notes

Quantity

of items

included

in product

Components, parts and materials containing

refractory ceramic fibers

Components, parts and materials containing

radioactive substances

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components

and materials requiring selective treatment can be removed.

Tool Description Tool Size (if

applicable)

Torque Driver (Standard)

Torque Bit T10

Torque Bit T25

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:

1. Remove PULL OUT

2. Press handle and remove – 1 pc of BLANK FILLER

3. Press handle and remove – 1 Unit of Power Supply

4. Unscrew and remove – 2 units of FAN TRAY

5. Unscrew and remove – M5 SCREW at 1 location

6. Unscrew and remove – M3 SCREW at 16 Locations and CHASSIS COVER

7. Unplug and remove – CABLE connect between PCBA, MAIN BOARD and PCBA, FAN BRIDGING BOARD

8. Unplug – FFC CABLE from PCBA, LED BOARD

9. Unscrew and remove – M3 SCREW at 2 locations

10. Remove – PCBA, LED BOARD

11. Remove - PUSHBUTTON

12. Unscrew and remove – M3 SCREW at 4 Locations and PCBA, FAN BRIDGING BOARD

13. Unscrew and remove - M3 SCREW at 11 Locations and PCBA, MAIN BOARD

14. Remove - COIN BATTERY from BATTERY SOCKET

15. Unplug – FFC CABLE from PCBA, MAIN BOARD

16. Remove - INSULATOR from CHASSIS

17. Remove - INSULATOR from CHASSIS

18. Remove – FRONT OVERLAY from CHASSIS

MF877-00 Page 3

Template Revision C, 30-July-2018

HPE instructions for this template are available at MF877-01

3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items

contained in the product that require selective treatment (with descriptions and arrows identifying locations).

MF877-00 Page 4

Template Revision C, 30-July-2018

HPE instructions for this template are available at MF877-01

MF877-00 Page 5

Template Revision C, 30-July-2018

HPE instructions for this template are available at MF877-01

MF877-00 Page 6

Template Revision C, 30-July-2018

HPE instructions for this template are available at MF877-01
