HPE Aruba 3810M Instrucciones de montaje

MF877-00 Page 1

Template Revision A

HPE instructions for this template are available at MF877-01

Product End-of-Life Disassembly Instructions

Product Category: Networking Equipment

Marketing Name / Model

[List multiple models if applicable.]

JL075A Aruba 3810M 16SFP+ 2-slot Swch

Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions

for the disassembly of HPE products to remove components and materials requiring selective treatment, as defined by EU

directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).

1.0 Items Requiring Selective Treatment

1.1 Items listed below are classified as requiring selective treatment.

1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as

applicable.

Item Description Notes

Quantity

of items

included

in product

Printed Circuit Boards (PCB) or Printed Circuit

Assemblies (PCA)

With a surface greater than 10 sq cm

Batteries

All types including standard alkaline and lithium

coin or button style batteries

Mercury-containing components

For example, mercury in lamps, display backlights,

scanner lamps, switches, batteries

Liquid Crystal Displays (LCD) with a surface

greater than 100 sq cm

Includes background illuminated displays with gas

discharge lamps

Cathode Ray Tubes (CRT)

Capacitors / condensers (Containing PCB/PCT)

Electrolytic Capacitors / Condensers measuring

greater than 2.5 cm in diameter or height

External electrical cables and cords

Gas Discharge Lamps

Plastics containing Brominated Flame Retardants

weighing > 25 grams (not including PCBs or PCAs

already listed as a separate item above)

Components and parts containing toner and ink,

including liquids, semi-liquids (gel/paste) and toner

Include the cartridges, print heads, tubes, vent

chambers, and service stations.

Components and waste containing asbestos

Components, parts and materials containing

refractory ceramic fibers

MF877-00 Page 2

Template Revision A

HPE instructions for this template are available at MF877-01

Item Description Notes

Quantity

of items

included

in product

Components, parts and materials containing

radioactive substances

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components

and materials requiring selective treatment can be removed.

Tool Description

Tool Size (if

applicable)

Torx Screw Drivers

T-10

Phillips Screw Driver

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:

1. 1. See 3.2 for pictorial disassembly instruction. Please open the attachment and print out if needed.

3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items

contained in the product that require selective treatment (with descriptions and arrows identifying locations).

JL075A Disassembly

Instruction.pptx

Find Steps Description Quantity

1Remove Mac address label 1

2Un-install Chassis serial number label 1

3Un-install PS Blank Filler 1

4Unscrew and un-install Assy,Fan Module, 3810 Switch 1

5Unscrew and un-install Assy, Module blank module 1

6Unscrew and remove SCREW-MACHINE ASSEMBLY M5 X 0.8 10M ROHS 2

7Unscrew and remove SCREW-THD-RLG M3 X 0.5 6MM-LG ROHS 2

Screws must tighten

PG : 1

REV: 01

aFollow Sequence.

b a c

klm

g i

opq

e d f

Find Steps Description Quantity

1Remove Bar Code Label, JL075A 1

2Un-screw SCREW-THD-RLG M3 X 0.5 18

3Remove Assy, Cover 3810 Non-POE Switch 1

PG : 2

REV: 01

PG : 3

REV: 01

Find Steps Description Quantity

1Un-install COVER, RJ45 CONNECTOR 3810 Switch 1

2Unscrew SCREW-MACHINE M3X0.5 6M 6

3Un-install Assy, CPU Module w Mech (Wolfgang CPU) 1Screws must tighten

aFollow Sequence.

PG : 4

REV: 01

Find Steps Description Quantity

1Un-install SFP+ dust cover 16

2Unscrew Stdoff Hex Female Stdoff M3-0.5x28mm CS Wz 1

3Cut CABLE TIE .062-1.25-DIA .1-WD NYL ROHS 2

4Disconnect form the 3 x PCA Wire Harness, 3810 Usability 1

5Unscrew SCREW-MACHINE M3X0.5 6M 2

6Un-install PCA, Usability_Management 1

7Unscrew Screw FH, M3x0.5mm, 6mmL, machine 2

8Uninstall PCA, Usability board (Spectre)1

9Uninstall Pushbutton, SMT, Mode Switch 1

Connect

This

Connect

This

Connect

This

Dis-Connect

from 3x PCA

PG : 5

REV: 01

Find Steps Description Quantity

1remove HP 3810 16 SFP+ Composite Label 1

2Unscrew and Uninstall Assy, Bulkhead Blank FP 2

3Unscrew SCREW-TAPPING M3 X 0.5 18

4Un-install Assy, 16x10GSFP+ w Mech (Icarus) 1

5Remove INSULATOR, CHASSIS BASE 3810 SWITCH 1

6Remove Lbl, Regulatory JL075A 1

21 6.0 lb/in

h i
