Smart MK3

Installation Guide

Notice

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for incidental

or consequential damages in connection with the furnishing, performance, or use

of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its

software on equipment that is not furnished by Hewlett-Packard.

This document contains proprietary information that is protected by copyright.

All rights are reserved. No part of this document may be photocopied,

reproduced, or translated to another language without the prior written consent

of Hewlett-Packard Company.

Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft

Corporation.

MMX TM is a trademark of Intel Corporation.

Pentium® is a registered trademark of Intel Corporation.

Hewlett-Packard France

Business Desktop Division

38053 Grenoble Cedex 9

France

Read This First

Before installing the network adapter:

If your OS is Windows NT 4.0, go into the BIOS setup and set PnP OS field to NO.

If your OS is Windows 98 2nd edition, go into the BIOS setup and set PnP OS field to

YES.

If your OS is Windows 2000 Professional, go into the BIOS setup and set PnP OS

field to YES.

If your OS is Windows NT4.0 and Wake on LAN capability is needed, go into the

BIOS setup and enable power-up when a specific command is received by the

Network Interface.

For all OS, remove any previously installed network adapter (usually located in slot

#5) if it is not needed.

Installing the network adapter in slot #4 is recommended. HP has tested this

installation procedure using slot #4.

For advanced users only: In case of resource conflict, you can try to change the

resources for the network adapter. To do this, turn the Vectra system power off,

remove the network adapter and install it into a different PCI slot.

Connecting to a Novell NetWare 5.1 or 4.11 Server

Microsoft Windows NT 4.0 Workstation

Requirements

Operating System Windows NT 4.0 Workstation

Driver Version 6.04

Driver File MDGNDIS4.SYS

Server OS NetWare 5.1 or 4.11 Server

Client OS Client v4.80 for Windows NT/2000

Procedure

1. With the HP Vectra turned off, install the network adapter into an available PCI

slot.

2. Connect the network cable to the newly installed network adapter.

3. Connect the WOL cable between the network adapter and the PC motherboard.

4. Power on the machine and boot to Windows.

5. Logon to Windows with administrator privileges.

6. Click OK to ignore the warning message indicating a driver failed during system

startup. This is caused the removal of the previously installed network adapter.

This message should no longer appear after removing the driver from the

Network properties.

7. The following steps are based on a subsequent installation of Networking on the

system. Adding a network adapter for the first time has some minor differences.

Ask your administrator for more information.

8. Open the Network properties windows to remove a previously installed network

adapter and to add a new one.

9. Click on the “Adapters”tab and highlight the network adapter you want removed

then click on the “Remove”button.

10. Click on the “Adapters”tab then on the “Add”button.

11. Insert the driver disk and click on “Have Disk”.

12. Type in the location of the NDIS4 drivers and click on “OK”.

13. With “Madge Automated Installation - RECOMMENDED”highlighted, click on

“OK”.

14. Select “Madge Smart 16/4 PCI Ringnode Mk3”and click on “Properties”. Click on

the “Advanced”button and enable Wake-On-LAN.

15. Additional changes in the Network properties, such as: workgroup name,

computer name, TCP/IP properties, etc. may be necessary. Ask your Network

Administrator for more information.

16. Click on “Close”to complete the installation.

17. Remove the driver disk and click on “Yes”when prompted to restart your

computer.

18. Logon to Windows with administrator privileges.

19. From the location of the “Novell Client v4.80 for Windows NT/2000”installation

files, execute “SETUPNW.EXE”.

20. Select either “Typical”or “Custom”and click on “Install”. Typical Installation is

normally chosen. Select Custom Installation only if you are an administrator or an

advanced user. When prompted for options during installation, ask your Network

Administrator for more information.

21. Click on “Yes”to accept the “Novell Terms and Conditions”.

22. Click on “Reboot”to restart the system once the installation is complete.

23. Logon to Windows with administrator privileges and re-install the current service

pack.

Connecting to a Microsoft Windows 2000 Advanced or NT 4.0

Server

Microsoft Windows NT 4.0 Workstation

Requirements

Operating System Windows NT 4.0 Workstation

Driver Version 6.04

Driver File MDGNDIS4.SYS

Server OS Windows 2000 Advanced or NT 4.0

Server

Client OS Microsoft

Procedure

1. With the HP Vectra turned off, install the network adapter into an available PCI

slot.

2. Connect the network cable to the newly installed network adapter.

3. Connect the WOL cable between the network adapter and the PC motherboard.

4. Power on the machine and boot to Windows.

5. Logon to Windows with administrator privileges.

6. Click OK to ignore the warning message indicating a driver failed during system

startup. This is caused the removal of the previously installed network adapter.

This message should no longer appear after removing the driver from the

Network properties.

7. The following steps are based on a subsequent installation of Networking on the

system. Adding a network adapter for the first time has some minor differences.

Ask your administrator for more information.

8. Open the Network properties windows to remove a previously installed network

adapter and to add a new one.

9. Click on the “Adapters”tab and highlight the network adapter you want removed

then click on the “Remove”button.

10. Click on the “Add”button to add the new network adapter.

11. Insert the driver disk and click on “Have Disk”.

12. Type in the location of the NDIS4 drivers and click on “OK”.

13. With “Madge Automated Installation - RECOMMENDED”highlighted, click on

“OK”.

14. Select “Madge Smart 16/4 PCI Ringnode Mk3”and click on “Properties”. Click on

the “Advanced”button and enable Wake-On-LAN.

15. Additional changes in the Network properties, such as: workgroup name,

computer name, TCP/IP properties, etc. may be necessary. Ask your Network

Administrator for more information.

16. Click on “Close”to complete the installation.

17. Remove the driver disk and click on “Yes”when prompted to restart your

computer.

18. Logon to Windows with administrator privileges and re-install the current service

pack.

Connecting to a Novell NetWare 5.1 or 4.11 Server

Microsoft Windows 98 2nd edition

Requirements

Operating System Windows 98 2nd edition

Driver Version 6.04

Driver File MDGNDIS4.SYS

Server OS NetWare 5.1 or 4.11 Server

Client OS Client v3.30 for Windows 95/98

Procedure

1. With the HP Vectra turned off, install the network adapter into an available PCI

slot.

2. Connect the network cable to the newly installed network adapter.

3. Connect the WOL cable between the network adapter and the PC motherboard.

4. Power on the machine and boot to Windows.

5. Windows will detect the network adapter as “PCI Token Ring Controller”.

6. Insert the driver disk and click on “Next”to continue the installation.

7. Accept the default selection: “Search for the best driver for your device

(Recommended).”and click “Next”.

8. Select the locations Windows will search for drivers. Check “Specify a location:”

and type in or browse the location of the NDIS4 driver. Click “Next”to continue.

9. Accept the driver found, “Madge Smart 16/4 PCI Ringnode Mk3”, by clicking on

“Next”.

10. Click on “Finish”when the driver installation is complete.

11. Remove the driver disk and click on “Yes”when prompted to restart the system.

12. Additional changes in the Network properties, such as: workgroup name,

computer name, TCP/IP properties, etc. may be necessary. Ask your Network

Administrator for more information. After changes are made, a restart will be

necessary.

13. From the location of the “Novell Client v3.30 for Windows 95/98”installation files,

execute “Setup.exe”.

14. Click on “Yes”to accept the “Novell Terms and Conditions”.

15. Select either “Typical”or “Custom”and click on “Install”. Typical Installation is

normally chosen. Select Custom Installation only if you are an administrator or an

advanced user. When prompted for options during installation, ask your Network

Administrator for more information.

16. Click on “Reboot”once the Novell client installation is complete.

Known Problems

Problem1

There is an issue with waking up the system. Currently there is no resolution to the

problem. However, the problem can be prevented by not placing the system on

Stand by. Also, the Power Management properties’"Turn off monitor:" and “System

standby:”settings must be set to “Never”.

Connecting to a Microsoft Windows 2000 Advanced or NT 4.0

Server

Microsoft Windows 98 2nd edition

Requirements

Operating System Windows 98 2nd edition

Driver Version 6.04

Driver File MDGNDIS4.SYS

Server OS Windows 2000 Advanced or NT 4.0

Server

Client OS Microsoft

Procedure

1. With the HP Vectra turned off, install the network adapter into an available PCI

slot.

2. Connect the network cable to the newly installed network adapter.

3. Connect the WOL cable between the network adapter and the PC motherboard.

4. Power on the machine and boot to Windows.

5. Windows will detect the network adapter as “PCI Token Ring Controller”.

6. Insert the driver disk and click on “Next”to continue the installation.

7. Accept the default selection: “Search for the best driver for your device

(Recommended).”and click “Next”.

8. Select the locations Windows will search for drivers. Check “Specify a location:”

and type in or browse the location of the NDIS4 driver. Click “Next”to continue.

9. Accept the driver found, “Madge Smart 16/4 PCI Ringnode Mk3”, by clicking on

“Next”.

10. Click on “Finish”when the driver installation is complete.

11. Remove the driver disk and click on “Yes”when prompted to restart the system.

12. Additional changes in the Network properties, such as: workgroup name,

computer name, TCP/IP properties, etc. may be necessary. Ask your Network

Administrator for more information. After changes are made, a restart will be

necessary.

Otros manuales para Vectra VL800

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Software de HP

HP ProLiant ML310 Generation 5p Manual de usuario

HP StorageWorks 2/32 - SAN Switch Manual de instrucciones

HP BL680c - ProLiant - G5 Manual de usuario

HP StorageWorks 2/140 - Director Switch Manual de instrucciones

HP BladeSystem bc2000 - Blade PC Manual de usuario

HP StorageWorks MSA 2/8 - SAN Switch Manual de usuario

HP P Class 450/500/550/600/650/700/750 Manual de usuario

HP Deskjet 812c Manual de instrucciones

HP eld Manual de usuario

HP Pro 3130 MT Manual de usuario

HP D6030A - NetServer - E50 Manual de usuario

HP C7791C - DesignJet 130 Color Inkjet Printer Guía de configuración

HP ActivCard Smart Card Guía rápida

HP AJ765A - StorageWorks RDX Removable Disk Backup... Manual de instrucciones

HP ProLiant ML310 Generation 5p Manual de usuario

HP KAYAK XM600 Manual de instrucciones

HP HP 2605dn Print Drivers Manual de servicio

HP 455031-L22 - Intel Quad-Core Xeon 2.13 GHz Processor... Manual de usuario

HP AK373A - StorageWorks All-in-One Storage System 1200r 5.4TB SAS Model NAS... Cómo utilizar

HP Data Protector A.06.11 Guía de configuración rápida

HP T5145 - Thin Client - Tower Manual de usuario

HP FTAM/9000 Manual de usuario

HP P9000 Manual de instrucciones

HP 500 G2 Manual de usuario

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Avaya

Avaya Interaction Center Manual de usuario

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario

Novell

Novell SP2 - S Manual de instrucciones
