Honeywell 3820 Manual de usuario

3820, 3820i, 4820, 4820i

Cordless Imaging Systems

Quick Start Guide

Note: Refer to your user’s guide for information

about cleaning your device.

For localized language versions of this document,

go to www.honeywell.com/aidc.

Getting Started

Turn off the computer’s power before connecting

the base, then power up the computer once the

base is fully connected. When the base is

connected and powered up, put the imager in the

base to establish a link. The green LED on the base

flashes to indicate the imager’s battery is charging.

USB Connection

Keyboard Wedge Connection

Serial (RS-232) Connection

Reading Techniques

The view finder

projects an aiming

beam that should

be centered over

the barcode. (The

4820/4820i can be

positioned in any

direction for a

good read.)

Hold the imager over the barcode, pull the trigger,

and center the aiming beam on the barcode.

The aiming beam is smaller when the imager is

closer to the code and larger when it is farther from

the code. Hold the imager close to smaller

barcodes, and farther away from large barcodes to

get a proper read.

If the barcode is highly reflective (e.g., laminated),

you may need to tilt the imager at an angle so the

barcode can be scanned.

Note: If the imager beeps 3 times when scanning a

barcode, the link has not been established.

If the imager beeps once, the link has been

established.

4820/4820i

can read in

any direction

Center

beam over

barcode

Standard Product Defaults

This barcode resets all standard product default

settings.

PC Interface

Scan the barcode that describes the PC or interface

you are using.

Standard Product Defaults

RS-232

USB Keyboard (PC)

Japan DOS/V

USB Japanese Keyboard

(PC)

PC Interface (continued)

Keyboard Country

Scan the Program Keyboard Country barcode

below, then scan the numeric barcode(s) from

page 12, then the Save barcode to program the

keyboard for your country. As a general rule, the

following characters are not supported by the

imager for countries other than the United States:

@ | $ # { } [ ] = / ‘ \ < > ~.

Country Code Scan Country Code Scan

Belgium 1 Italy 5

Denmark 8 Norway 9

Finland 2 Spain 10

France 3 Switzerland 6

Emulate External Keyboard

AT/PS2 Keyboard Wedge

(Default)

Program Keyboard Country

Note: For complete list of country codes, see the

User’s Guide for your product at our website,

www.honeywell.com/aidc.

Open Link

Scan the Open Link barcode, then place the imager

into the base to establish a link. Placing a different

imager into the base establishes a new link and the

old imager is unlinked.

Germany/Austria 4 USA (Default) 0

Great Britain 7

Country Code Scan Country Code Scan

Save

Open Link

Override Locked Imager

If you need to replace a broken or lost imager that

is linked to a base, scan the Override Locked

Imager barcode with a new imager, and place that

imager in the base. The locked link will be

overridden; the broken or lost imager’s link with the

base will be removed, and the new imager will be

linked.

Unlinking the Imager

If the base has an imager linked to it, that imager

must be unlinked before a new imager can be

linked. Once the previous imager is unlinked, it will

no longer communicate with the base. Scan the

Unlink Imager barcode to unlink an imager.

Override Locked Imager

Unlink Imager

Trigger

The following barcodes will allow you to use the

reader in Manual Trigger mode (need to press the

trigger to read) or Presentation mode (the reader is

activated when it “sees” a barcode).

Streaming Presentation™ (4820/4820i)

Note: Streaming presentation mode applies only to

units with advanced illumination. Units with

advanced illumination have a software

revision of 31205481-027 or higher.

When in Streaming Presentation mode, the imager

leaves the scan illumination on all the time and

continuously searches for barcodes.

Manual Trigger

(Default)

Presentation Mode

Streaming Presentation Mode

Reread Delay

This sets the time period before the imager can

read the

same

barcode a second time. Setting a

reread delay protects against accidental rereads of

the same barcode.

Suffix

If you want a carriage return after the barcode, scan

the Add CR Suffix barcode. To add a tab after the

barcode, scan the Add Tab Suffix barcode.

Otherwise, scan the Remove Suffix barcode to

remove the suffixes.

Medium Reread Delay

Add CR Suffix

Remove Suffix

Add Tab Suffix
