Honeywell MS1890 Focus Manual de usuario

MS1890 Focus

Honeywell’s MS1890 Focus

industrial-grade area-imaging

scanner

provides unmatched scanning performance in challenging environments.

MS1890 Focus maximizes productivity with a set of features previously

unavailable in rugged area imagers.

Engineered to withstand two-meter falls, this IP54-rated omnidirectional

scanner precisely executes applications for retail back-of-store,

manufacturing, transportation and logistics. It excels in punishing

locales such as: dusty warehouses, steamy storerooms, rainy loading

docks and freezing distribution centers.

The MS1890 Focus outperforms the ﬁeld in decoding all standard bar

codes in a single ﬂash with minimal concern for orientation or print

quality. It reads codes damaged, worn or wrapped in clear plastic.

The MS1890 Focus further separates itself with patented CodeSelect™

technology which allows the scanner to capture up to seven bar codes

in a single ﬂash and then decode them in any predetermined order.

Honeywell’s exclusive TotalFreedom™architecture expands scanner

funtionality by allowing formatting, parsing and decoding plug-ins to

be loaded directly to the MS1890 instead of the host system.

For more information on the MS1890 Focus industrial-grade area-

imaging scanner, please visit www.honeywell.com/aidc

Industrial-Grade Area-Imaging Scanner

IP54-rated:• Withstands exposure to dirt, dust and

splashing water

Durable Metal Hook:• Creates safer working conditions

by attaching to universal tether

Total• Freedom: Expands scanner functionality by

allowing image processing, decoding and formatting

plug-ins to be loaded directly to the scanner instead of

the host system

Flexible Licensing Solution:• Meets diverse scanning

requirements by offering models with limited decoding

capabilities—purchase decoding licenses to enable

additional functionality as the need arises

Omnidirectional Scanning:• Eliminates need to orientate

scanner to bar code

Code• Select: Scans up to 7 bar codes in a single ﬂash

and outputs data in any predetermined order

Features

Security & Data Collection

Honeywell Scanning & Mobility

Honeywell

90 Coles Road

Blackwood, NJ 08012

856.228.8100

www.honeywell.com

For more information:

www.honeywell.com/aidc

RoHS

2002/95/EC

MS1890 Focus Technical Speciﬁcations

Operational

Light Source LED 645 nm ± 7.5 nm

Audible Indicators 7 tones or no beep

Visual Indicators Blue = ready to scan; White = good read; Yellow = automatic scanning

Host System Interfaces USB, RS232, Keyboard Wedge, IBM 46xx (RS485)

Mechanical

Dimensions (LxWxH) 111 mm x 79 mm x 183 mm (4.4˝ x 3.1˝ x 7.2˝)

Weight 284 g (10 oz)

Electrical

Input Voltage 5 VDC ± 0.25 V

Operating Power 2 W (400 mA @ 5 V) - typical

Standby Power 800 mW (160 mA @ 5 V) - typical

DC Transformers Class 2: 5.2 VDC @ 1 A

LED Class Class 1: IEC60825-1, EN60825-1

EMC FCC Part 15, IEC60825-1, EN55022 Class A

Environmental

Operating Temperature 0°C to 50°C (32°F to 122°F)

Storage Temperature -40°C to 60°C (-40°F to 140°F)

Humidity 0% to 95% relative humidity, non-condensing

Drop Designed to withstand 2 m (6.5´) drops

Environmental Sealing IP54

Light Levels 100,000 Lux (9,290 foot-candles)

Scan Performance

Scan Pattern Area

Sensor Resolution 1.3 megapixel

Motion Tolerance 10 cm/s (4 in/s) for 13 mil UPC @ 10 cm (4.0˝) distance

Scan Angle Horizontal: 50°; Vertical: 20°

Print Contrast 20% minimum reﬂectance difference

Tilt, Pitch, Skew 360°, 75°, 75°

Decode Capability 1D: Code 39, Code 93, Code 128, UPC/EAN/JAN, Code 2 of 5, Code 11, Codabar, MSI Plessey, GS1 DataBar,

Telepen, Trioptic

*PDF: PDF417, MicroPDF417

*2D: QR Code, Micro QR Code, Data Matrix, Aztec Code, Maxicode, Codablock,

Composite Code, POSTNET,

PLANET, UPU, Intelligent Mail, Canada Post, Australia Post, Japanese Post, Royal Mail RM4SCC, KIX Code

*OCR: OCR-A, OCR-B, E-13B MICR *Note: Enable by purchasing decoding license

Typical Performance*

Narrow Width Depth of Field

5.2 mil (1D) 51 mm - 108 mm (2.0˝ - 4.3˝)

7.5 mil (1D) 32 mm - 184 mm (1.3˝ - 7.3˝)

13 mil (1D) 0 mm - 300 mm (0˝ - 11.8˝)

10 mil (PDF) 0 mm - 216 mm (0˝ - 8.5˝)

15 mil (PDF) 0 mm - 305 mm (0˝ - 12.0˝)

*Resolution: 5 mil (0.127 mm)

*Performance may be impacted by bar code

quality and environmental conditions
