Honeywell 2020-5 Manual de usuario

™

2020/3820/3820i

Cordless System

User’s Guide

Disclaimer

Honeywell International Inc. (“Honeywell”) reserves the right to make changes

in specifications and other information contained in this document without prior

notice, and the reader should in all cases consult Honeywell to determine

whether any such changes have been made. The information in this publication

does not represent a commitment on the part of Honeywell.

Honeywell shall not be liable for technical or editorial errors or omissions con-

tained herein; nor for incidental or consequential damages resulting from the

furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright.

All rights are reserved. No part of this document may be photocopied, repro-

duced, or translated into another language without the prior written consent of

Honeywell.

Other product names or marks mentioned in this document may be trademarks

or registered trademarks of other companies and are the property of their

respective owners.

Web Address: www.honeywellaidc.comw.honeywell.com/aidc

Microsoft® Windows® and the Windows logo are trademarks or registered

trademarks of Microsoft Corporation.

The

Bluetooth

®word mark and logos are owned by Bluetooth SIG, Inc.

Product Agency Compliance

USA

FCC Part 15 Subpart C

This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference

that may cause undesired operation.

Caution: Any changes or modifications made to this equipment not

expressly approved by Honeywell may void the FCC authorization

to operate this equipment.

Use only shielded data cables with this system. This unit has been tested

with cables less than 3 meters. Cables greater than 3 meters may not meet

class B performance.

UL Statement

UL listed: UL60950-1, 2nd Edition.

Canada

Industry Canada

This device complies with Canadian RSS-210. Operation is subject to the

following conditions:

1. This device may not cause interference, and

2. This device must accept any interference, including interference that may

cause undesired operation of this device.

Conformité à la règlementation canadienne

Cet appareil ISM est conforme à la norme CNR-210 du Canada.

Son fonctionnement est assujetti aux conditions suivantes :

1. Cet appareil ne doit pas causer de brouillage préjudiciable.

2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le

brouillage pouvant causer un fonctionnement indésirable.

c-UL Statement

C-UL listed: CSA C22.2 No.60950-1-03, 2nd Edition for I.T.E. product safety.

Europe

The CE marking on the product indicates that this device is in

conformity with all essential requirements of the 1999/5/EC R&TTE

Directive. In addition, complies to 2006/95/EC Low Voltage Directive,

when shipped with recommended power supply.

For CE-related inquiries, please contact:

Honeywell Imaging & Mobility Europe BV

International Inc.

Nijverheidsweg 9-13

5627 BT Eindhoven

The Netherlands

Honeywell shall not be liable for use of our product with equipment (i.e.,

power supplies, personal computers, etc.) that is not CE marked and does

not comply with the Low Voltage Directive. This equipment is intended for

use throughout the European Community and has been assessed to the

following standards:

EN 300 328

EN 301 489-1

EN 301 489-17

EN 60950-1

Waste Electrical and Electronic Equipment

Information

Honeywell complies with Directive 2002/96/EC OF THE EUROPEAN

PARLIAMENT AND OF THE COUNCIL on waste electrical and electronic

equipment (WEEE).

This product has required the extraction and use of natural resources for its

production. It may contain hazardous substances that could impact health

and the environment, if not properly disposed.

In order to avoid the dissemination of those substances in our environment

and to diminish the pressure on the natural resources, we encourage you to

use the appropriate take-back systems for product disposal. Those systems

will reuse or recycle most of the materials of the product you are disposing in

a sound way.

The crossed out wheeled bin symbol informs you that the product

should not be disposed of along with municipal waste and invites you to use

the appropriate separate take-back systems for product disposal.

If you need more information on the collection, reuse, and recycling systems,

please contact your local or regional waste administration.

You may also contact your supplier for more information on the

environmental performances of this product.

Germany

If your product is marked with the GS symbol, then the product has

been issued a GS certificate showing compliance to EN 60950-1,

Second Edition.

This device is not intended for use in direct field of view at visual

display workplaces. To avoid distracting reflections at visual display workplaces,

this device should not be placed in direct field of view.

Australia/NZ

C-Tick Statement

Conforms to AS/NZS 3548 EMC requirement.

Korea

If the following label is attached to your product, the product meets Korean

agency approval:

이 기기는 가정용(B급) 전자파적합기기로서 주로 가정에서 사용하는 것

을 목적으로 하며 ,

모든 역에서 사용할 수 있습니다 .

This product is EMC B grade equipment, intended for residential use.

This equipment can be used in any area.

Brazil (3820i, 2020-5 Scanner and AP-010BT)

This product is approved by Anatel, according to the procedures regulated

by Resolution No. 242/2000 and meets the technical requirements applied.

Este produto está homologado pela ANATEL, de acordo com os

procedimentos regulamentados pela Resolução No. 242/2000 e atende aos

requisitos técnicos aplicados.

Para maiores informações, consulte o site da ANATEL – www.anatel.gov.br

Japan

Complies with Technical Regulations Conformity Certification of

Specified Radio equipment.

Mexico

Applicable if NOM logo is marked on product. Conforms

to NOM-019.

Comision Federal de Telecomunicaciones (radio aprobación)

International

Safety Precautions for Lithium Batteries

• Do not place batteries in fire or heat the batteries.

• Do not store batteries near fire or other high temperature locations.

• Do not store or carry batteries together with metal objects.

• Do not expose batteries to water or allow the batteries to get wet.

• Do not connect (short) the positive and negative terminals, of the

batteries, to each other with any metal object.

• Do not pierce, strike or step on batteries or subject batteries to strong

impacts or shocks.

Modelo: 2020-5

1881-11-7084

(01)07898927490119

" Este equipamento operaem caráter secundário, isto é, não tem

direito aproteção contrainterferênciaprejudicial, mesmo de estações

do mesmo tipo, e não pode causar interferênciaasistemas operando

em caráter primário."

Modelo: 3820i

1880-11-7084

(01)07898927490102

" Este equipamento operaem caráter secundário, isto é, não tem

direito aproteção contrainterferênciaprejudicial, mesmo de estações

do mesmo tipo, e não pode causar interferênciaasistemas operando

em caráter primário."

Modelo: AP-010BT

0921-11-6583

(01)07898927490089

" Este equipamento operaem caráter secundário, isto é, não tem

direito aproteção contrainterferênciaprejudicial, mesmo de estações

do mesmo tipo, e não pode causar interferênciaasistemas operando

em caráter primário."

• Do not disassemble or modify batteries.

Caution:

Danger of explosion if batteries are incorrectly replaced. Replace only

with the same or equivalent type recommended by the manufacturer.

Dispose of used batteries according to the recycle program for batteries

as directed by the governing agency for the country where the batteries

are to be discarded.

LED Safety Statement

Scanner LEDs have been tested and classified as “EXEMPT RISK GROUP”

to the standard: IEC 62471:2006.

Radio Technology

Class II

CB Scheme

Certified to CB Scheme IEC 60950-1, Second Edition.

Solids and Water Protection

The 3820 has a rating of IP41, immunity of foreign particles and dripping

water.

The 3820i has a rating of IP54, immunity of foreign particles and sprayed

water.

Patents

For patent information, please refer to www.honeywellaidc.com/patents.

Warning

To reduce the possibility of heat-related injuries, avoid touching

sections of the scanner that feel warm.

Required Safety Labels

Scanner

Compliance

Label locations

Item Number,

Serial Number

and Revision

Information

location

Base

Compliance

Label locations

Item Number,

Serial Number

and Revision

Information

location
