HighPoint Rocket 700 Series Manual de usuario

1

Rocket 730A (R730A)

PCI-Express 3.0 x16 Controller

R730A

Quick Installation Guide

V1.00

2

R730 Kit Contents

•Rocket 730A Controller Card

•Quick Installation Guide

Operating System

•System with a free PCIe 3.0/4.0 x16 slot

•Windows 11, 10 / Server 2022, 2019, 2016/ Microsoft Hyper-V

•RHEL/Debian/Ubuntu/Fedora/Proxmox (Linux kernel

3.10 and later)

•Arch Linux (Kernel 5.17.5 and above)

Required Accessories

Certified cables are available directly from HighPoint and our

authorized resellers. For more information, please contact our

Sales Department (sales@highpoint-tech.com).

1. In order to use SATA drives with the R730A SAS controller,

you will need at least one 8643-4SATA-1M cable.

Each cable can support four SATA hard drives or SSD

via an SFF-8643 port.

3

2. In order to use SAS/SATA drives with the R730A SAS

controller, you will need at least one 8643-4SAS-1M cable.

Each cable can support up to four SAS/SATA hard drives or

SSD via an SFF-8643 port.

R730A Hardware

Front View

4

R730A Hardware Installation

Note: Make sure the system is powered-off before installing the SAS

Controller.

1. Connect the R730A into the PCIe 3.0/ 4.0 x16 slot of the

motherboard;

2. How to connect disks to the R730A using the 8643-4SATA-

1M cable.

SATA Power

SATA

5

3. How to connect disks to the R730A using the 8643-4SAS-

1M cable.

Each cable can support up to four SAS/SATA hard drives or

SSD via an SFF-8643 port.

SAS Power Connector

SATA/SAS Drivers

6

R730A Channel Layout

Channels 5-8

Channels 1-4

Channels 9-

Channels 13-

Channels 17-

Channels 21-

7

Optional Certified Cable Accessories

Device Cables

8643-4SAS-1M

SFF-8643 SAS to 4x SFF-8482

SAS cable

Length: 1M

8643-4SATA-1M

SFF-8643 SAS to 4x SATA

cable,with Power Connector

Length: 1M

8

Resources

A variety of manuals, guides and FAQs are available for Rocket

730A SAS controllers. In addition, we recommend visiting the

Software Downloads webpage for the latest drivers,

management interfaces, and installation guides.

For Software Downloads, Documentation and more information

about this product, please visit the following website:

https://www.highpoint-tech.com/rocket700-series

FAQ & Troubleshooting:

FAQ - HighPoint Technologies, Inc. (helpjuice.com)

9

Customer Support

If you encounter any problems while utilizing the SAS

controllers, orhave any questions about HighPoint Technologies,

Inc. products & solutions, feel free to contact our Customer

Support Department.

Web Support:

https://www.highpoint-tech.com/support-and-services

HighPoint Technologies, Inc. websites:

https://www.highpoint-tech.com

© Copyright 2022 HighPoint Technologies, Inc. All rights reserved.
