HighPoint SSD7580B Manual de usuario

1

SSD7580B

8x U.2 Port to PCIe 4.0x16 NVMe RAID Controller

Quick Installation Guide

V1.00

2

System Requirements

PC Requirements

System with a free PCIe4.0 (or 3.0) x16 slot

Windows 10, Windows Server 2016, Windows Server 2019

Microsoft Hyper-V

Linux kernel 3.10 and later

SSD7580B Kit Content

SSD7580B Controller Card

Quick Installation Guide

Low Profile bracket

3

SSD7580B Hardware

Front View

SFF-8654 ports

PCIe 4.0 x16 Host Interface

4

Hardware Installation:

1. The SSD7580B provides 4 SFF-8654 to U.2 SFF-8639 connectors

on the right side and top of the controller PCB. Each of these ports

was designed for use with HighPoint TS8i-8639-060 NVMe cables

that have 15-pin SATA power connectors.

SFF-8654 ports

5

2. Shown above is an SFF-8654 to U.2 SFF-8639 cable with a 15-pin

SATA power connector. The SFF-8639 port should be connected to

the NVMe SSD’s U.2 port. The 15 pin SATA power connector

should be connected to the system’s power supply.

3. Insert the SSD7580B controller into one of the motherboard’s open

PCI-E 4.0x16 slots.

SFF-8654

SFF-8639

SATA-15pin

TS8i-8639-060

NVMe cable

6

4. Connect two pieces of NVMe with SFF-8639 port, and connect

SFF-8654 port to SSD7580B. Connect the 15-pin SATA power

connector to the system's power supply.

7

SFF-8639

15-pin SATA power connector

8

5. Connect the remaining NVMe SSDs to the SSD7580B controller

as described above. Once complete, Power on the system

Note: Please be sure to connect NVMe before using the product to

reduce the occurrence of unnecessary errors!

Note: Install the driver in the system first and then install the board

！

Resources

A variety of manuals, guides and FAQs are available for the SSD7580B

RAID controller.

In addition, we recommend visiting the Software Downloads webpage

for the latest drivers, management interfaces, and installation guides.

Software Download:

SSD7580B Driver, WebGUI, Installation Guides:

https://highpoint-tech.com/USA_new/series-ssd7580-download.htm

9

Other Reference Information:

Motherboard & NVMe SSD Compatibility List

SSD7580B User Guides

https://highpoint-tech.com/USA_new/series-ssd7580-resource.htm

Customer Support

If you encounter any problems while utilizing the SSD7580B, or have

any questions about this or any other HighPoint Technologies, Inc.

product, feel free to contact our Customer Support Department.

Web Support:

https://www.highpoint-tech.com/websupport/main.php

HighPoint Technologies, Inc. websites:

https://www.highpoint-tech.com

© Copyright 2021 HighPoint Technologies, Inc. All rights reserved.
