Linux Ubuntu Server on SSD7505 Installation Guide
SSD7505 Controller
Linux Ubuntu Server 20.04.4
Installation Guide
Version 1.02
Copyright © 2022 HighPoint Technologies, Inc.
All rights reserved.
Last updated on June 30, 2022
Linux Ubuntu Server on SSD7505 Installation Guide
i
Table of Contents
1 Overview.......................................................................................................................................1
2 Installing Linux Ubuntu Server on SSD7505 controller...........................................................1
Step 1 PrepareYour Hardware for Installation .........................................................................1
Step 2 Check System EFI Settings............................................................................................1
Step 3 Flash UEFI Rom to SSD7505........................................................................................3
Step 4 Create Array...................................................................................................................4
Step 5 Prepare the Driver Diskette............................................................................................5
Step 6 Install Linux Ubuntu Server...........................................................................................6
3 Monitoring the Driver .................................................................................................................8
4 Installing RAID Management Software.....................................................................................9
5 Rebuilding Driver Module for System Update..........................................................................9
6 Trouble Shooting..........................................................................................................................9
Linux Ubuntu Server on SSD7505 Installation Guide
- 1 -
1 Overview
The purpose of this document is to provide clear instructions on how to install Linux
Ubuntu Server on the SSD7505 controller.
2 Installing Linux Ubuntu Server on SSD7505
controller
If you would like to install Linux Ubuntu Server onto drives attached to SSD7505
controller, please perform the following operations:
Step 1 Prepare Your Hardware for Installation
After you attach your NVMe SSD to SSD7505 controller, you can use SSD7505 EFI
Utility to configure your NVMe SSD as RAID arrays, or just use them as single disks.
Before installation, you must remove all the NVMe SSD, which are not physically
attached to SSD7505 controller, from your system.
Note
SSD7505 only support EFI boot. If you have other SCSI adapters installed, you must
make sure the SSD7505 controller EFI will be loaded firstly. If not, try to move it to
another PCI slot. Otherwise you may be unable to boot up your system.
Step 2 Check System EFI Settings
In your system EFI SETUP menu, change Boot Sequence in such a way that the system
will first boot from EFI CDROM, and then from SSD7505 RAID. Refer to your
motherboard EFI manual to see how to set boot sequence.
If your EFI settings do not support such a boot sequence, you can first set it to boot from
EFI CDROM.After you finish installation, set SSD7505 RAID as the first boot device to
boot up the system.
1. Set UEFI setting with SuperMicro H12SSL -i motherboard as an example.
a. "Advanced->PCIe/PCI/PnP Configuration->CPUSlot PCI-E OPROM"
to "EFI".Suppose SSD7505 is connected to motherboard CPU1 Slot 2 PCI-E
X16,then you should set "CPU1 Slot 2 PCI-E X16 OPROM" to "EFI";
Linux Ubuntu Server on SSD7505 Installation Guide
- 2 -
b. Disable "Secure Boot", set "Attempt Secure Boot" to "Disabled".
2. Set UEFI setting with ASUS PRIME X299 -DELUXE motherboard as an example:
a. Set "Boot from Storage Devices" to "UEFI driver first";
b. And "Boot Device Control" to "UEFI Only" or "UEFI and Legacy OPROM";
Linux Ubuntu Server on SSD7505 Installation Guide
- 3 -
c. Set "OS Type" to "Other OS".
Step 3 Flash UEFI Rom to SSD7505
a. Unzip SSD7505 UEFI package to root dir(/) of a USB flash driver,and insert the
USB flash drive to the motherboard;
b. Booting from the UEFI USB flash and enter the UEFI environment ;
c. Command with “SSD7505.nsh”, flash UEFI rom to SSD7505 Controller and
reboot;
Linux Ubuntu Server on SSD7505 Installation Guide
- 4 -
Step 4 Create Array
a. Attach four NVMe SSD to SSD7505 Controller ;
Note
Make sure your USB flash partition format is NTFS or FAT32.
b. Boot, in the presence of the motherboard Log screen, there will be NVMe SSD
information：
c. Enter the motherboard’s Boot List and select start from UEFI USB flash:
d. Command ”Arraycreate.efi” to enter the Utility:
Linux Ubuntu Server on SSD7505 Installation Guide
- 5 -
e. Command “create RAID0 ”.
Create RAID0 array with all disks and with maximum capacity.
f. Command “exit”；
g. For more command usages, refer toAppendixA.
Step 5 Prepare the Driver Diskette
Extract HighPoint_NVMe_Ubuntu_20.04.4_x86_64_vx.x.x_xx_xx_xx.tar.gz to top(/)
directory of an USB flash drive. It will look like:
Linux Ubuntu Server on SSD7505 Installation Guide
- 6 -
Step 6 Install Linux Ubuntu Server
a. Insert the USB flash drive to the target system.
b. Booting from Installation DVD disc (EFI mode).
c. When the Installation screen appears, press ‘e’ to edit boot command line option.
On the edit command window, move the cursor to the end of line “linux
/casper/vmlinuz...quiet ”, and append "modprobe.blacklist=nvme" (double quotation
mark are not include).
Press CTRL-x or F10 to start the system.
d. When the installation started:
Press ALT-F2 to switch new console window and press ENTER to activate this console.
Ubuntu login: ubuntu
Linux Ubuntu Server on SSD7505 Installation Guide
- 7 -
And the then execute following commands to copy the driver contents.
# mkdir /hptdd ← Create mount point for USB flash drive
# mount /dev/sda1 /hptdd ← Mount the USB flash drive to /hptdd
#cp -a /hptdd/hptdd /tmp ← Copy driver installation file to
system temporary directory
# umount /dev/sda1 ← Unmount the USB flash drive
# sh /tmp/hptdd/preinst.sh ← Load SSD7505 driver.
e. Press ALT-F1 to continue system installation.
f. When the installation prompts “Reboot now”.
Linux Ubuntu Server on SSD7505 Installation Guide
- 8 -
Press ALT-F2 and execute following command to install driver to the installed Linux
Ubuntu Server on the array of SSD7505.
# sh /tmp/hptdd/postinst.sh ← Install SSD7505 driver.
g. Press ALT-F1 and press “Reboot Now” to finish the installation.
h. Open source driver needs to be installed after system installation.
https://www.highpoint-tech.com/ssd/ssd7505-overview
Run the .bin file to install the driver package.
# ./hptnvme_g5_linux_src_vxx.x.x_xx_xx_xx.bin
i. Follow the prompts to complete the driver installation.
j. After the installation is complete, you can perform system update operations.
3 Monitoring the Driver
Once the driver is running, you can monitor it through the Linux proc file system support.
There is a special file under /proc/scsi/hptnvme /. Through this file you can view driver
status and send control commands to the driver.
Note
The file name is the SCSI host number allocated by OS. If you have no other SCSI cards
installed, it will be 0. In the following sections, we will use x to represent this number.
Using the following command to show driver status:
# cat /proc/scsi/hptnvme /x
