HERO Super Splendor Manual de usuario
PREFACE
Your motorcycle is conforming to latest (Bharat stage-III norms) regulation for emission,
safety & noise levels. We are also using non asbestos brake shoes/pads and engine gaskets
which are environment friendly in nature.
Thank you for selecting a Hero MotoCorp Super Splendor. We wish you many miles of
continued riding pleasure in the years ahead.
This booklet is your guide to the basic operation and maintenance of your new
Hero MotoCorp Super Splendor. Please take time to read it carefully. As with any fine
machine, proper care and maintenance are essential for trouble-free operation and optimum
performance.
Your Authorised Hero MotoCorp dealer will be glad to provide further information or
assistance and is equipped to handle your future service needs.
Let us make this world a safer, healthier and more environment friendly place.
We at Hero MotoCorp, are committed to demonstrate excellence in our environment
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve environment
compatibility, comply with all applicable legislation including environment legislation and
strengthen the green supply chain.
ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION AVAILABLE
AT THE TIME OF ITS PRINTING APPROVAL, AND THE ACCURACY OR
CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR GUARANTEED. Hero
MotoCorp Ltd RESERVES THE RIGHT TO MAKE CHANGES IN ITS CONTENTS
AT ANY TIME WITHOUT NOTICE AND/OR INCURRING ANY OBLIGATION,
WHATSOEVER. NO ONE IS ALLOWED TO REPRODUCE ANY PART OF THIS
PUBLICATION WITHOUT OBTAINING PRIOR WRITTEN PERMISSION FROM
Hero MotoCorp Ltd.
NOTE
Pg. No.Pg. No.
CONTENTS
Pg. No.
MAINTENANCE
îThe Importance of Maintenance
îSafety Precaution
îOil filter screen & Centrifugal filter
îMaintenance Schedule
25
MOTORCYCLE IDENTIFICATION 1
PRODUCT SPECIFICATION 2
SAFE RIDING TIPS 4
ACCESSORIES & MODIFICATIONS 5
MOTORCYCLE VIEWS 7
PARTS FUNCTION 10
îInstruments & Indicators
îIgnition switch
LEFT HANDLEBAR CONTROLS
RIGHT HANDLEBAR CONTROLS
STEERING LOCK
SIDE STAND INDICATOR/SIDE STAND SWITCH
FUEL VALVE
FUEL TANK
10
11
12
12
13
ENGINE OIL 17
ENGINE OIL LEVEL CHECK/TOP UP PROCESS 17
ENGINE OIL REPLACEMENT PROCESS 18
16
TYRES 18
PRE-RIDE INSPECTION 20
RIDING 21
BRAKING/PARKING/UTILITY BOX 22
15
15
ANTI-THEFT TIPS 5
TIPS FOR HEALTHY ENVIRONMENT 6
23
TOOL KIT/FIRST AID KIT
25
24
STARTING THE ENGINE ROAD SIGNS
îAir cleaner
îFuse replacement
îSpark plug
îBattery
îDrive chain slider
îThrottle operation
îDrive chain
îFront brake
îCarburetor
îValve clearance
îClutch
îRear brake
îBrake wear indicators
îStop lamp switch
îHeadlamp adjustment
îSide Stand
SUSPENSION
FRONT WHEEL
REAR WHEEL
WASHING THE MOTORCYCLE
CATALYTIC CONVERTER
BASIC TROUBLESHOOTING
WARRANTY DETAILS
HERO GENUINE PARTS
ZONAL/REGIONAL/AREA OFFICES
26
29
43
44
44
46
47
47
48
50
47
AIR SUCTION VALVE
i3s SYSTEM (idle stop start system) 13
25
29
30
32
33
34
34
35
38
39
40
40
42
42
43
37
XXXXECY
ZXYYYYY
2. For dealing with legal & insurance departments.
1. During registration of the motorcycle.
VIN and Engine No. may be required:
Location: Stamped on the right side of the
steering head tube.
VIN: MBLXXXXEWYZXYYYYY
Location: Stamped on the lower side of the
left crankcase.
MOTORCYCLE IDENTIFICATION
Engine No.: XXXXECYZXYYYYY
Model: Super Splendor
VIN Engine
Variants
XXXXEC Y Z X YYYYY
Engine
Description Year of
Manufacturing Assembly Plant Month of
Manufacturing Serial Number
MBL XXXXEW Y Z X YYYYY
Manufacturer
code Vehicle
Description Year of
Manufacturing Assembly Plant Month of
Manufacturing Serial Number
Cast wheel/Electric start/Drum brake/i3s
Spoke wheel/Electric start/Drum brake/i3s EV
EW
EC
EC
Vehicle Identification Number (VIN) Engine No.
1
MBLXXXXEWYZXYYYYY
SPECIFICATIONSITEM
Dimensions
Overall length
Overall width
Overall height
Wheelbase
Saddle height
Ground clearance
Kerb weight
1995 mm
735 mm
1095 mm
1265 mm
785 mm
150 mm
Weight
Engine oil
Fuel tank
Fuel reserve capacity
Front fork oil disassembly
Maximum power
Bore and stroke
Compression ratio
Displacement
Spark plug gap
Valve clearance (cold)
Idle speed
Front Suspension
Rear Suspension
0.95 litre at disassembly and 0.75 litre at draining
13 litres (Minimum)
1.0 litre (Usable reserve)
157 ml
6.72 kW (9 BHP) @ 7000 r/min
52.4x57.8 mm
9.1:1
124.7 cc
0.8-0.9 mm
0.05 mm
0.05 mm
1400±100 r/min
Telescopic Hydraulic Shock Absorbers
Rectangular swingarm with 5 step adjustable
Hydraulic Shock Absorber
Capacities
Engine
Intake (cold)
Exhaust (cold)
Chassis and suspension
Spark plug NGK CPR 6EA9
PRODUCT SPECIFICATION
121 kg
2
Trail length 89 mm
Caster angle 26°
Maximum torque 10.35 N-m @ 4000 r/min
PRODUCT SPECIFICATION SPECIFICATIONSITEM
**MFR stands for Multi-Focal Reflector
*MF stands for Maintenance Free
3
12V-21/5W-**MFR
Primary reduction
Final reduction
st
Gear ratio, 1
rd
3th
4
Battery
Alternator
Starting system
Headlamp (High/Low)
Tail/Stop lamp
Turn signal lamp
Meter illumination
Neutral indicator
Turn signal indicator
Position lamp
Hi Beam indicator
Side stand indicator
3.350 (67/20)
3.000 (42/14)
2.769 (36/13)
1.500 (30/20)
1.095 (23/21)
0.913 (21/23)
*MF Battery, ETZ-4:12V-3Ah
94 W @ 5000 r/min
Electric Start
i3s indicator 12V-1.7W
Fuse 15A/20A
Transmission
Electricals
Spoke Wheel/Cast Wheel (Optional)
Spoke Wheel/Cast Wheel (Optional)
Front Wheel
Rear Wheel
nd
2
Brakes Dia. 130 mm
Dia. 130 mm
Front (Drum type)
Rear (Drum type)
12V-35/35W Halogen Bulb-**MFR
12V-1.7W
12V-1.7W
12V-3.0W
12V-3.4Wx2
12V-1.7W
12V-1.7Wx3
12V-10Wx4 (Amber bulb) with clear lens- MFR**
Tyre size 2.75x18-42P/4PR
2.75x18-48P/6PR
Front
Rear
SAFE RIDING TIPS
4
Do's: Don't:
îNever use cell phone while riding the
motorcycle.
îNever touch any part of the hot exhaust
system like muffler.
îNever shift gears without disengaging
the clutch and closing the throttle.
îAvoid sudden acceleration, braking and
turning of your motorcycle.
îNever ride under the influence of alcohol or
drugs.
îConcentrate on the road and avoid talking
to the pillion rider or others on the road.
îDo not cross the continuous white/ yellow
line in the center of the road, while
overtaking.
îDo not attach large or heavy items to the
handlebars, front forks, or fenders.
îNever take your hands off the steering
handle while riding.
îDo not litter the road.
îFor stopping motorcycle, use both brakes
simultaneously, keeping throttle in the close
position.
îRespect road signs and obey traffic rules for
your own safety and that of others on the
road (page 50 & 51).
îTo make yourself more visible, wear bright
reflective clothing that fits well.
îAlways wear a helmet (ISI marked) with
chin strap securely fastened and insist on a
helmet for your pillion rider.
îAlways conduct simple pre-ride inspection
(page 20).
îGet your motorcycle serviced regularly by
the Authorised Hero MotoCorp
workshop.
îWhile riding, sit in a comfortable position
with your legs close to fuel tank.
îTightly wrap loose/hanging clothes & avoid
entangling with moving parts.
îGive way to others on the road and signal
before you make a turn.
îBefore riding make sure in which mode you
are riding whether with i3s switch “ON’ or
“OFF”.
îRide defensively and at a steady speed
(between 40-50 km/hr).
îDuring night time, dip headlamps of your
motorcycle for oncoming traffic, or when
following another vehicle.
ACCESSORIES & MODIFICATIONS
Modifying your motorcycle or using non-
Hero MotoCorp accessories can make your
motorcycle unsafe. Before you consider
making any modifications or adding an
accessory, be sure to read the following
information.
îAlways lock the steering and never leave the
key in the ignition switch .
îMany times stolen motorcycles are identified
by information in the Owner's Manuals that
are still with them.
NAME: _____________________________________________
PHONE NO : _____________________________________
îPark your motorcycle in a locked garage
whenever possible.
îUse an additional anti-theft device of good
quality.
ANTI-THEFT TIPS
_______________________________________________________
_______________________________________________________
_______________________________________________________
ADDRESS: _______________________________________
îPut your name, address and phone number
in this Owner's Manual and keep it in your
motorcycle at all times.
5
Accessories
îMake sure that the accessory does not
obscure any lamps, reduce ground
clearance, limit suspension travel or steering
travel, affect your riding position or interfere
with operating any controls.
îBe sure electrical equipment does not
exceed the motorcycle's electrical system
capacity (page 3). A blown fuse can cause
a loss of lights.
îDo not pull a trailer or sidecar with your
motorcycle. This motorcycle was not
designed for these attachments, and their
use can seriously impair your motorcycle's
handling.
îFollow all instructions in this owner's manual
regarding accessories and modifications.
îImproper accessories or modifications can
cause a crash in which you can be seriously
hurt or killed.
WARNING
!!
Modifications
We strongly advise you not to remove any
original equipment or modify your motorcycle
in any way that would change its design or
operation. Such changes could seriously
impair your motorcycle's handling, stability
and braking, making it unsafe to ride.
Removing or modifying your lamps, mufflers,
emission control system or other equipment
can also make your motorcycle illegal.
SOME TIPS FOR HEALTHY ENVIRONMENT
6
The following tips shall ensure a healthy motorcycle, healthy environment, and a healthy you.
îHealthy engine: The engine is the lifeline of every vehicle. To keep it healthy, it should be
tuned regularly, which will also help reduce pollution and improve vehicle performance &
fuel efficiency.
îFuel Saving & Reduce Pollution: Switch "OFF" the engine while waiting at traffic signal
points to save fuel and reduce pollution, if the waiting period is long.
îGenuine Spares: Always insist on Hero MotoCorp genuine parts as spurious or
incompatible spares and accessories can upset or deteriorate your motorcycle’s running
condition.
îGenuine engine oil: Hero 4T Plus SAE 10W 30 SL grade (JASO MA2) engine oil
recommended by Hero MotoCorp and make sure you change it every 6000 km. (with
top up every 3000 kilometres) to keep the engine fit and environment healthy.
îNoise pollution: Noise beyond a certain decibel is pollution. Whether it is from horns or defective
mufflers, excessive noise will cause headaches and discomfort.
îEmission Pollution: Get emission of your motorcycle checked by Authorised agencies
atleast once every 3 months or as notified by the government from time to time.
îRegular Servicing: Get your motorcycle serviced at an Authorised Hero MotoCorp
workshop, as per the service schedule, for an optimum performance and keep the emission
level under check.
MOTORCYCLE VIEWS
*Accessories and features shown may not be part of standard fitment.
7
TOP VIEW
(12) Speedometer
(1) Trip meter knob
(2) Side stand indicator
(3) Headlamp dimmer switch
(4) Horn switch
(5) Turn signal switch
(6) Headlamp switch
(7) Passing switch
(8) Rear view mirror
(9) High beam indicator
(10) i3s indicator
(11) Neutral indicator
(14) Turn signal indicator
(19) Ignition switch with steering lock
(20) Throttle grip
(13) Odometer
(15) Trip meter
(16) Fuel indicator
(17) i3s switch
(18) Front brake lever
(21) Electric starter switch
(22) Fuel tank cap
(23) Leg guard
11
910 12 14
13 15
8
1
6
3
2
4
5
717
18
19
20
21
22
23
16
Otros manuales para Super Splendor
2
Tabla de contenidos
Otros manuales de Motocicleta de HERO
HERO
HERO XTREME 200R Manual de usuario
HERO
HERO HF-Deluxe Manual de usuario
HERO
HERO Karizma ZMR Manual de usuario
HERO
HERO IGNITOR Manual de usuario
HERO
HERO XPULSE 200 PROGRAMMED FI Manual de usuario
HERO
HERO SPLENDOR PRO Manual de usuario
HERO
HERO SPLENDOR iSmart Manual de usuario
HERO
HERO SPLENDOR i Smart Manual de usuario
HERO
HERO Passion PRO TR Manual de usuario
HERO
HERO XPULSE 200T 4V 2023 Manual de usuario
HERO
HERO MAESTRO EDGE 125 PROGRAMMED FI Manual de usuario
HERO
HERO MAESTRO EDGE Manual de usuario
HERO
HERO HF 100 Manual de usuario
HERO
HERO KARIZMA Manual de usuario
HERO
HERO SPLENDOR+ Manual de usuario
HERO
HERO Passion Pro Manual de usuario
HERO
HERO DAWN-150 Manual de usuario
HERO
HERO SPLENDOR+ Manual de usuario
HERO
HERO Passion Pro Manual de usuario
HERO
HERO XTREME SPORTS Manual de usuario
Manuales populares de Motocicleta de otras marcas
MOTO GUZZI
MOTO GUZZI QUOTA 1100 ES Manual de usuario
APRILIA
APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manual de usuario
Yamaha
Yamaha 2006 YZF-R1V Manual de usuario
KTM
KTM Freeride E-XC 2021 Manual de usuario
Fantic
Fantic Enduro 125 Manual de usuario
Ducati
Ducati Supersport 750 desmodue Manual de usuario
