PREFACE

Let us make this world a safer, healthier and more environment friendly place.

We at Hero MotoCorp, are committed to demonstrate excellence in our environment

performance on a continual basis, as an intrinsic element of our corporate philosophy. To

achieve this we commit ourselves to continue product innovations to improve environment

compatibility, comply with all applicable legislation including environment legislation and

strengthen the green supply chain.

This booklet is your guide to the basic operation and maintenance of your new

Hero MotoCorp ACHIEVER 150. Please take time to read it carefully. As with any fine

machine, proper care and maintenance are essential for trouble-free operation and optimum

performance.

This vehicle is fitted with a lighting feature known as “Automatic Headlamp ON”. The feature

is mandated for all 2 Wheelers by Ministry of Road Transport & Highways (Government of

India) vide notification GSR 188 (E) dated 22nd February 2016. This feature helps in

conspicuity for improving rider safety. The headlamp of this vehicle will always be lit ON when

the engine gets ON.

Your vehicle is conforming to latest (Bharat stage-IV norms) regulation for emission, safety &

noise levels. We are also using non asbestos brake shoes/pads and engine gaskets which are

environment friendly in nature.

Thank you for selecting a Hero MotoCorp ACHIEVER 150. We wish you many miles of

continued riding pleasure in the years ahead.

Your Authorised Hero MotoCorp dealer will be glad to provide further information or

assistance and is equipped to handle your future service needs.

ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,

SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S

MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION AVAILABLE

AT THE TIME OF ITS PRINTING APPROVAL, AND THE ACCURACY OR

CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR GUARANTEED.

Hero MotoCorp Ltd RESERVES THE RIGHT TO MAKE CHANGES IN ITS

CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR INCURRING ANY

OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO REPRODUCE ANY

PART OF THIS PUBLICATION WITHOUT OBTAINING PRIOR WRITTEN

PERMISSION FROM Hero MotoCorp Ltd.

NOTE

Pg. No.Pg. No.

CONTENTS

Pg. No.

îMaintenance safety/Saftey precaution 25

îMaintenance schedule 26

VEHICLE SAFETY 4

VEHICLE IDENTIFICATION 1

PRODUCT SPECIFICATION 2

îImportant safety information 4

SAFE RIDING TIPS 6

ACCESSORIES & MODIFICATIONS 7

îProtective apparel 5

STARTING THE ENGINE 21

îInstruments & Indicators 12

îSide stand indicator/Switch 16

îSeat Lock 19

îLeft handlebar controls 14

îFuel Valve 17

îRight handlebar controls 14

îFuel Tank 18

îHelmet Lock (Optional) 19

PRE-RIDE INSPECTION 20

MAINTENANCE 24

FIRST AID KIT 24

RIDING 22

îSteering lock/i3s (Idle stop start system) 15

ANTI-THEFT TIPS 7

îIgnition switch 13

TIPS FOR HEALTHY ENVIRONMENT 8

VEHICLE VIEWS 9

PARTS FUNCTION 12

BRAKING/PARKING/TOOL KIT 23

îImportance of maintenance 24

îBrake wear indicators 42

îFuse replacement/Stop lamp switch 48

îDrive chain slider/Front brake 39

îThrottle operation/Valve clearance 34

îEngine oil 29

EVAPORATIVE EMISSION CONTROL 53

îSpark plug 31

îDrive chain 37

îEngine oil replacement process 30

îRear brake 41

îOil filter screen & centrifugal filter 30

îAir cleaner element 32

îEngine oil level inspection/Top up process 29

îAir cleaner drain tube 33

îCarburetor (Idle speed)/Clutch 36

îTubeless tyre 43

îBattery 46

îSide stand/Side stand indicator 49

îHeadlamp adjustment 49

îSuspension 50

îFront wheel removal/Rear wheel removal 51

WASHING THE VEHICLE 52

CATALYTIC CONVERTER 52

AIR SUCTION VALVE 53

BASIC TROUBLESHOOTING 54

WARRANTY DETAILS

HERO GENUINE PARTS

ROAD SIGNS 56

ZONAL/REGIONAL/AREA OFFICES

2. For dealing with Legal & Insurance Departments.

VIN and Engine No. may be required:

1. During registration of the vehicle.

Location: Stamped on the right side of the

steering head tube.

Location: Stamped on the lower side of the

left Crankcase.

VEHICLE IDENTIFICATION

Model: ACHIEVER 150

VIN Engine

Variants

Cast wheel/Electric start/Disc R04

S30 EJ

Vehicle Identification Number (VIN) Engine No.

MBLXXS30XYZXYYYYY

Cast wheel/Electric start/Drum

VIN: MBLXXS30XYZXYYYYY

MBL XXS30 Y Z X YYYYY

Manufacturer

code Vehicle

Description Model Year Plant

Code Month of

Manufacturing Production

Serial Number

Check

Digit

Engine No.: XXXXEJYZXYYYYY

XXXXEJ Y Z X YYYYY

Engine

Description Year of

Manufacturing Assembly Plant Month of

Manufacturing Serial Number

XXXXEJY

ZXYYYYY

SPECIFICATIONSITEM

Overall length

Overall width

Overall height

Wheelbase

Ground clearance

2060 mm

763 mm

1086 mm

1290 mm

160 mm

PRODUCT SPECIFICATION

Kerb weight 139 kg

Engine oil

Fuel tank

Fuel reserve capacity

Front fork oil

Maximum power

Maximum torque

Bore and stroke

Compression ratio

Displacement

Spark plug gap

Valve clearance

Idle speed

Front Suspension

Rear Suspension

Caster angle

1.2 litres at disassembly and 1 litre at draining

13 litres

1.8 litres (Usable reserve)

150 ml

10 kW (13.4 BHP) @ 8000 r/min

12.80 N-m @ 5000 r/min

57.3x.57.8 mm

9.1:1

149.1 cc

NGK-CPR 8 EA9, CHAMPION-RG 6 YC,

BOSCH-UR5DC

0.8-0.9 mm

0.08 mm

0.12 mm

1400±100 r/min

Telescopic Hydraulic Shock Absorbers

Swingarm with adjustable Hydraulic Shock Absorbers

26°

Capacities

Engine

Intake (cold)

Exhaust (cold)

Chassis and suspension

Spark plug

Hydraulic brake fluid Castrol Q Stop-DoT 3/DoT 4

Trail length 89 mm

Dimensions

Weight

PRODUCT SPECIFICATION SPECIFICATIONSITEM

Fuse 15A/20A

Brakes Dia. 240 mm

Front (Disc type)

Dia. 130 mm

Rear (Drum type)

12V-5/21W-* MFR*

Primary reduction

Final reduction

Gear ratio, 1

3th

Battery

Alternator

Starting system

Headlamp (High/Low)

Tail/Stop lamp

Turn signal lamp

Meter illumination

Neutral indicator

Turn signal indicator

Position lamp

Hi Beam indicator

3.3500

2.8000

3.0769

1.7895

1.3043

1.0909

*MF Battery (ETZ-5), 12V-4Ah

125 W @ 5000 r/min

Electric Start

Transmission

Electricals

12V-35/35W Halogen Bulb-* MFR*

12V-1.7W

12V-5.0Wx2

12V-3.0W

12V-1.7W

12V-1.7Wx3

12V-10Wx4- *MFR*

Tyre size 80/100-18-47P (Tubeless)

Front

Rear

50.9375

80/100-18-54P (Tubeless)

Front (Drum type) Dia. 130 mm

i3s indicator

Side stand indicator

* MF stands for Maintenance Free

** MFR stands for Multi-Focal Reflector

12V-1.7W

VEHICLE SAFETY

There is much that you can do to protect

yourself when you ride. You will find many

helpful recommendations through out this

manual. Following are a few that we consider

most important.

Make sure that you are physically fit, mentally

focused and free of alcohol and drugs. Check

that you and your pillion are both wearing an

approved vehicle helmet and protective

apparel. Instruct your pillion on holding onto

the grab rail or your waist, leaning with you in

turns, and keeping their feet on the footrest,

even when the vehicle is stopped.

It is a proven fact, Helmet significantly reduces

the number and severity of head injuries. So

always wear a helmet and make sure your pillion

rider does the same. We also recommend that

you wear eye protection, sturdy boots, gloves

and other protective gear.

Always wear a helmet

Before riding your vehicle

IMPORTANT SAFETY INFORMATION

Take time to learn & practice your vehicle

Even if you have ridden other vehicles,

practice riding in a safe area to become

familiar with how this vehicle works and

handles, and to become accustomed to the

vehicle's size and weight.

Your vehicle can provide many years of

service and pleasure if you take responsibility

for your own safety and understand the

challenges you can meet on the road.

Riding under the influence of alcohol or drugs

is dangerous. Alcohol can reduce your ability

to respond to changing conditions and reduce

the reaction time. Do not drink and ride.

Do not drink and ride

Make yourself easily visible

Ride within your limits

For safe riding, its important to inspect your

vehicle before every ride and perform all

recommended maintenance. Never exceed

load limits, and use accessories that have been

recommended by Hero MotoCorp for this

vehicle.

Keep your vehicle in safe condition

Always pay due attention to other vehicles

around you, and do not assume that other

drivers see you. Be prepared to stop quickly or

perform an evasive maneuver.

Pushing the limits is another major cause of

vehicle accidents. Never ride beyond your

personal abilities or faster than conditions

demand. Remember that fatigue and

negligence can significantly reduce your ability

to make good judgements and ride safely.

Some drivers do not see because they vehicles

are not looking for them. To make yourself more

visible, wear bright reflective clothing, position

yourself so that others can see you, signal before

turning or changing lanes, and use horn which

will help others to notice you.

Ride defensively

An open-face helmet offers some protection,

but a full-face helmet offers more. Always

wear face shield or goggles to protect your

eyes and help your vision.

Helmets and eye protection

Your Helmet is your most important piece of

riding gear because it offers the best

protection against head injuries. A helmet

should fit your head comfortably and securely.

A bright coloured helmet can make you more

noticeable in traffic, as can reflective strips.

Additional riding gear

In addition to a helmet and eye protection, we

also recommend:

îSturdy boots with non-slip soles to help

protect your feet and ankles.

îLeather gloves to keep your hands warm

and help prevent blisters, cuts, burns, and

bruises.

îA two wheeler riding suit or jacket for

comfort as well as protection. Bright

coloured reflective clothing can help make

you more noticeable in traffic. Be sure to

avoid loose clothes that could get caught on

any part of your vehicle.

If you decide to continue riding, first evaluate

the condition of your vehicle. If the engine is

still running, turn it off. Inspect for fluid leaks,

check the tightness of critical nuts and bolts,

and check the handlebar, brake levers, brakes,

and wheels. Ride slowly and cautiously. Your

vehicle may have suffered damage that is not

immediately apparent. Have your vehicle

thoroughly checked at a qualified service

facility as soon as possible.

PROTECTIVE APPAREL

Following are suggestions to help you choose

proper riding gear.

Personal safety is your first priority. If you or

anyone else has been injured, take time to

assess the severity of the injuries and whether

it is safe to continue riding. Call for emergency

assistance if needed. Also follow applicable

laws and regulations if another person or

vehicle is involved in the crash.

If you are involved in a crash

For your safety, we strongly recommend that

you always wear an approved helmet (ISI

marked), eye protection, boots, gloves, long

pants and a long sleeve shirt or jacket

whenever you ride. Take care of loose/

hanging clothes while solo/pillion riding.

Although complete protection is not possible,

wearing proper gear can reduce the chance of

injury when you ride.

îNot wearing a helmet increases the chance of

serious injury or death in a crash.

îBe sure you and your pillion always wear a

helmet, eye protection and other protective

apparel when you ride.

WARNING

SAFE RIDING TIPS

Do's:

îAlways conduct simple pre-ride inspection

(page 20).

îAlways wear a helmet (ISI marked) with

chin strap securely fastened and insist on a

helmet for your pillion rider.

îWhile riding, sit in a comfortable position

with your legs close to fuel tank.

îGet your vehicle serviced regularly by the

Authorised Hero MotoCorp workshop.

îBefore riding make sure in which mode you

are riding whether with i3s switch “ON’ or

“OFF”.

îRespect road signs and obey traffic rules for

your own safety and that of others on the

road (page 56 & 57).

îRide defensively and at a steady speed

(between 40-50 km/hr).

îGive way to others on the road and signal

before you make a turn.

îTightly wrap loose/hanging clothes & avoid

entangling with moving parts.

îFor stopping vehicle, use both brakes

simultaneously, keeping throttle in the close

position.

îDuring night time, dip headlamps of your

vehicle for oncoming traffic, or when

following another vehicle.

îTo make yourself more visible, wear bright

reflective clothing that fits well.

Don't:

îAvoid sudden acceleration, braking and

turning of your vehicle.

îNever ride under the influence of alcohol or

drugs.

îConcentrate on the road and avoid talking

to the pillion rider or others on the road.

îDo not litter the road.

îNever take your hands off the steering

handle while riding.

îNever shift gears without disengaging the

clutch and closing the throttle.

îNever use cell phone while riding the

vehicle.

îNever touch any part of the hot exhaust

system like muffler.

îDo not cross the continuous white/

yellow line in the center of the road, while

overtaking.

îDo not attach large or heavy items to the

handlebars, front forks, or fenders.

ACCESSORIES & MODIFICATIONS

Modifying your vehicle or using non-Hero

MotoCorp accessories can make your vehicle

unsafe. Before you consider making any

modifications or adding an accessory, be sure to

read the following information.

îAlways lock the steering and never leave the

key in the ignition switch. This sounds

simple but people do forgets.

îBe sure the registration information for

your vehicle is accurate and correct.

îUse an additional anti-theft device of good

quality.

îNever park your vehicle in an isolated area.

Park as far as possible in a designated area.

îEnter your name, address and phone

number in this Owner's Manual and keep it

in your vehicle at all times. Many times

stolen vehicles are identified by information

in the Owner's Manuals that are still with

them.

impair your vehicle's handling, stability and

braking, making it unsafe to ride. Removing or

modifying your lamps, mufflers, emission

control system or other equipment can also

make your vehicle illegal.

ANTI-THEFT TIPS

îPark your vehicle in a locked garage

whenever possible.

_______________________________________________________

ADDRESS: _______________________________________

_______________________________________________________

PHONE NO : _____________________________________

NAME: _____________________________________________

îBe sure electrical equipment does not

exceed the vehicle's electrical system

capacity (page 3). A blown fuse can cause

a loss of lights.

îDo not pull a trailer or sidecar with your

vehicle. This vehicle was not designed for

these attachments, and their use can seriously

impair your vehicle's handling.

îMake sure that the accessory does not

obscure any lamps, reduce ground

clearance, limit suspension travel or steering

travel, affect your riding position or interfere

with operating any controls.

Accessories

Modifications

We strongly advise you not to remove any

original equipment or modify your vehicle in

any way that would change its design or

operation. Such changes could seriously

îImproper accessories or modifications can

cause a crash in which you can be seriously

hurt or killed.

îFollow all instructions in this owner's

manual regarding accessories and

modifications.

WARNING

Tabla de contenidos

Otros manuales de Motocicleta de HERO

HERO

HERO Splendor Plus Manual de usuario

HERO

HERO XTREME SPORTS Manual de usuario

HERO

HERO HF-Deluxe Manual de usuario

HERO

HERO SPLENDOR iSMART+ Manual de usuario

HERO

HERO GLAMOUR Manual de usuario

HERO

HERO GLAMOUR PROGRAMMED FI Manual de usuario

HERO

HERO XPULSE 200T 4V 2023 Manual de usuario

HERO

HERO Super Splendor Manual de usuario

HERO

HERO SPLENDOR+ Manual de usuario

HERO

HERO IGNITOR Manual de usuario

HERO

HERO ECO DELUXE Manual de usuario

HERO

HERO MAESTRO EDGE 125 PROGRAMMED FI Manual de usuario

HERO

HERO IGNITOR TECHNO Manual de usuario

HERO

HERO DAWN-150 Manual de usuario

HERO

HERO MAESTRO EDGE 125 PROGRAMMED FI Manual de usuario

HERO

HERO MAESTRO EDGE PROGRAMMED FI Manual de usuario

HERO

HERO HF 100 Manual de usuario

HERO

HERO GLAMOUR Manual de usuario

HERO

HERO Splendor Pro CLASSIC Manual de usuario

HERO

HERO XTREME 200R Manual de usuario

HERO

HERO HF-DAWN Manual de usuario

HERO

HERO SPLENDOR+ PROGRAMMED FI Manual de usuario

HERO

HERO SPLENDOR iSMART PROGRAMMED FI Manual de usuario

HERO

HERO SPLENDOR+ Manual de usuario

Manuales populares de Motocicleta de otras marcas

OHVALE

OHVALE GP-0 Manual de lista de piezas

Yamaha

Yamaha Star XV19CTSZ 2009 Manual de usuario

KTM

KTM 350 XCF-W USA Manual de usuario

HYOSUNG

HYOSUNG ST7 Manual de usuario

Husqvarna

Husqvarna FC 250 2016 Manual de usuario

Ducati

Ducati SCRAMBLER 800 Manual de instrucciones

MOTO GUZZI

MOTO GUZZI QUOTA 1100 ES Manual de usuario

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manual de usuario

Yamaha

Yamaha 2006 YZF-R1V Manual de usuario

KTM

KTM Freeride E-XC 2021 Manual de usuario

Fantic

Fantic Enduro 125 Manual de usuario

Ducati

Ducati Supersport 750 desmodue Manual de usuario

MV Agusta

MV Agusta 2008 F4 312RR 1078 Manual de instrucciones

Yamaha

Yamaha XVS650A Manual de usuario

Yamaha

Yamaha YZF-R6T(C) Manual

Ducati

Ducati 748 monoposto strada Manual de usuario

ATK

ATK 1988 250 Manual de usuario

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Manual de usuario
