HERO GLAMOUR PROGRAMMED FI Manual de usuario

We, at Hero MotoCorp, are committed to demonstrate excellence in our environment

performance on a continual basis, as an intrinsic element of our corporate philosophy. To

achieve this we commit ourselves to continue product innovations to improve environment

compatibility, comply with all applicable legislation including environment legislation and

strengthen the green supply chain.

This booklet is your guide to the basic operation and maintenance of your new

Hero MotoCorp GLAMOUR PROGRAMMED FI. Please take time to read it carefully. As

with any fine machine, proper care and maintenance are essential for trouble-free operation

and optimum performance.

Your motorcycle is conforming to latest (Bharat stage-III norms) regulation for emission,

safety & noise levels. We are also using non asbestos brake shoes / pads and engine gaskets

which are environment friendly in nature.

Your Authorised Hero MotoCorp dealer will be glad to provide further information or

assistance and is equipped to handle your future service needs.

Let us make this world a safer, healthier and more environment friendly place.

Thank you for selecting a Hero MotoCorp GLAMOUR PROGRAMMED FI. We wish you

many miles of continued riding pleasure in the years ahead.

PREFACE

ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,

SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S

MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION

AVAILABLE AT THE TIME OF ITS PRINTING APPROVAL, AND THE

ACCURACY OR CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR

GUARANTEED. Hero MotoCorp Ltd. RESERVES THE RIGHT TO MAKE

CHANGES IN ITS CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR

INCURRING ANY OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO

REPRODUCE ANY PART OF THIS PUBLICATION WITHOUT OBTAINING

PRIOR WRITTEN PERMISSION FROM Hero MotoCorp Ltd.

NOTE

Pg. No.

CONTENTS

Pg. No.

MAINTENANCE 27

PARKING/TOOL KIT/FIRST AID KIT 26

RIDING/BRAKING 25

PRODUCT SPECIFICATION 2

MOTORCYCLE SAFETY 4

SAFE RIDING TIPS 5

ACCESSORIES & MODIFICATION 7

ANTI-THEFT TIPS 7

TIPS FOR HEALTHY ENVIRONMENT 8

MOTORCYCLE VIEWS 9

PARTS FUNCTION 12

• INSTRUMENTS & INDICATORS 12

MOTORCYCLE IDENTIFICATION 1

• FUEL GAUGE 15

PRE-RIDE INSPECTION 22

ENGINE OIL REPLACEMENT PROCESS 19

• REALTIME MILEAGE INDICATOR (RTMI) 16

ENGINE OIL 19

• LEFT HANDLEBAR CONTROLS 16

• FUEL TANK 18

TYRES 20

• IGNITION SWITCH 14

• SEAT LOCK/HELMET HANGER 18

• STEERING LOCK 17

STARTING THE ENGINE 23

• RIGHT HANDLEBAR CONTROLS 17

ENGINE OIL TOP UP PROCESS 19

• SUSPENSION 43

• VALVE CLEARANCE 34

• REAR BRAKE 39

• REAR WHEEL REMOVAL 44

ROAD SIGNS 48

• AIR CLEANER 31

• FRONT BRAKE 38

• STOP LAMP SWITCH 42

• HEADLAMP ADJUSTMENT 43

• SPARK PLUG 30

• FRONT WHEEL REMOVAL 44

• SAFETY PRECAUTION 27

• CLUTCH 35

• THROTTLE OPERATION 33

• BATTERY 40

• FUSE REPLACEMENT 42

• MAINTENANCE SCHEDULE 28

• OIL SCREEN FILTER&CENTRIFUGAL FILTER 30

• DRIVE CHAIN 36

• WASHING THE MOTORCYCLE 45

• CATALYTIC CONVERTER 45

• AIR SUCTION VALVE 45

BASIC TROUBLESHOOTING 46

WARRANTY DETAILS

HERO GENUINE PARTS

ZONAL/REGIONAL/AREA OFFICES

2. For dealing with Legal & Insurance Departments.

VIN and Engine No. may be required:

1. During registration of the motorcycle.

Location: Stamped on the right side of the

steering head tube.

VIN: MBLXXXXARYZXYYYYY

Location: Stamped on the lower side of the

left Crankcase.

MOTORCYCLE IDENTIFICATION

Engine No.: XXXXEMYZXYYYYY

Model: Glamour Programmed FI VIN Engine

Variants

XXXXEM Y Z X YYYYY

Engine

Description Year of

Manufacturing Assembly Plant Month of

Manufacturing Serial Number

MBL XXXXAR Y Z X YYYYY

Manufacturer

code Vehicle

Description Year of

Manufacturing Assembly Plant Month of

Manufacturing Serial Number

Vehicle Identification Number (VIN) Engine No.

XXXXEMY

ZXYYYYY

AR EM

Electric start/Disc/Cast wheel

MBLXXXXARYZXYYYYY

SPECIFICATIONSITEM

Dimensions

Overall length

Overall width

Overall height

Wheelbase

Saddle height

Ground clearance

Kerb weight

2005 mm

735 mm

1070 mm

1265 mm

790 mm

150 mm

Weight

Engine oil

Fuel tank

Front fork oil capacity

Maximum power

Maximum torque

Bore and stroke

Compression ratio

Displacement

0.95 litres at disassembly

0.75 litre at draining

163 ml

52.4 x 57.9 mm

9.2:1

124.8 cc

Capacities

Engine

Spark plug gap

Valve clearance (cold)

Idle speed

Front Suspension

Rear Suspension

0.8-0.9 mm

In:0.05 mm

Ex:0.05 mm

1500 100 r/min

Telescopic Hydraulic Shock Absorbers

Intake (cold)

Exhaust (cold)

Chassis and suspension

Spark plug NGK-CPR 6EA9

PRODUCT SPECIFICATION

124 kg (Electric Start)

Hydraulic Brake fluid DoT 3 or DoT 4

10.35 N-m @ 4000 r/min

6.72 kw (9 BHP) @ 7000 r/min

12 litres (minimum)

Rectangular Swingarm with 5 step

Adjustable Hydraulic Shock Absorber

PRODUCT SPECIFICATION SPECIFICATIONSITEM

*MFR stands for Multi-Focal Reflector

**MF stands for Maintenance Free

12V-5/21W-*MFR

Trail length 89 mm

Tyre size 2.75x18-42P/4 PR

3.00x18-52P/6PR

Front

Rear

Primary reduction

Final reduction

Gear ratio, 1

3th

Battery

Alternator

Starting system

Headlamp (High/Low)

Tail/Stop lamp

Turn signal lamp

Meter illumination

Neutral indicator

Turn signal indicator

Position lamp

Hi Beam indicator

Programmed-FI malfunction indicator lamp

3.350 (67/20)

3.071 (43/14)

2.769 (36/13)

1.500 (30/20)

1.095 (23/21)

0.913 (21/23)

Electric Start / Kick Start

POWER Transmission

Electricals

Brakes Dia. 240 mm

Dia. 130 mm

Front (Disc type)

Rear (Drum type)

12V-35W/35W Halogen Bulb-*MFR

LED

12V-5.0W

LED

12V-1.12W

LED

12V-10Wx4 (Amber bulb) with clear lens-*MFR

Caster 26°

**MF Battery,12V 3Ah (ETZ-4)

140 W @ 5000 r/min

MOTORCYCLE SAFETY

IMPORTANT SAFETY INFORMATION

Your motorcycle can provide many years of

service and pleasure if you take responsibility

for your own safety and understand the

challenges you can meet on the road.

There is much that you can do to protect

yourself when you ride. You will find many

helpful recommendations through out this

manual. Following are a few that we consider

most important.

Always wear a helmet

It is a proven fact, Helmet significantly reduces

the number and severity of head injuries. So

always wear a helmet and make sure your pillion

rider does the same. We also recommend that

you wear eye protection, sturdy boots, gloves

and other protective gear.

Before riding your motorcycle

Make sure that you are physically fit, mentally

focused and free of alcohol and drugs. Check

that you and your pillion are both wearing an

approved motorcycle helmet and protective

apparel. Instruct your pillion on holding onto

the grab rail or your waist, leaning with you in

turns, and keeping their feet on the footrest,

even when the motorcycle is stopped.

Take time to learn & practice your

motorcycle

Even if you have ridden other motorcycles,

practice riding in a safe area to become

familiar with how this motorcycle works and

handles, and to become accustomed to the

motorcycle's size and weight.

Ride defensively

Ride within your limits

Make yourself easily visible

Keep your motorcycle in safe condition

For safe riding, its important to inspect your

motorcycle before every ride and perform all

recommended maintenance. Never exceed

load limits, and use accessories that have been

recommended by Hero MotoCorp for this

vehicle.

Riding under the influence of alcohol or drugs

is dangerous. Alcohol can reduce your ability

to respond to changing conditions and reduce

the reaction time. Do not drink and ride.

Always pay due attention to other vehicles

around you, and do not assume that other

drivers see you. Be prepared to stop quickly or

perform an evasive maneuver.

Pushing the limits is another major cause of

motorcycle accidents. Never ride beyond your

personal abilities or faster than conditions

demand. Remember that fatigue and

negligence can significantly reduce your ability

to make good judgements and ride safely.

Do not drink and ride

Some drivers do not see because motorcycles

they are not looking for them. To make yourself

more visible, wear bright reflective clothing,

position yourself so that others can see you,

signal before turning or changing lanes, and use

horn which will help others to notice you.

îFor stopping motorcycle, use both brakes

simultaneously, keeping throttle in the close

position.

îRide defensively and at a steady speed

(between 40-50 km/hr).

îAlways wear a helmet (ISI marked) with

chin strap securely fastened and insist on a

helmet for your pillion rider.

îDuring night time, dip headlamps of your

motorcycle for oncoming traffic, or when

following another vehicle.

îWhile riding, sit in a comfortable position

with your legs close to fuel tank.

îRespect road signs and obey traffic rules for

your own safety and that of others on the

road . (page 48 & 49)

îTo make yourself more visible, wear bright

reflective clothing that fits well.

îGive way to others on the road and signal

before you make a turn.

îAlways conduct simple pre-ride inspection

(page 22).

îTake care of loose/hanging clothes while

solo/pillion riding.

îGet your motorcycle serviced regularly by

the Authorised Hero MotoCorp workshop.

îDo not litter the road.

îAvoid sudden acceleration, braking and

turning of your motorcycle.

îDo not cross the continuous white/

yellow line in the center of the road, while

overtaking.

îNever touch any part of the hot exhaust

system like muffler.

îDo not attach large or heavy items to the

handlebars, front forks, or fenders.

îNever use cell phone while riding the

motorcycle.

îNever take your hands off the steering

handle while riding.

îConcentrate on the road and avoid talking

to the pillion rider or others on the road.

îNever shift gears without disengaging the

clutch and closing the throttle.

îNever ride under the influence of alcohol or

drugs.

SAFE RIDING TIPS

Do's: Don't:

îA two wheeler riding suit or jacket for

comfort as well as protection. Bright

coloured reflective clothing can help make

you more noticeable in traffic. Be sure to

avoid loose clothes that could get caught on

any part of your motorcycle.

Helmets and eye protection

Your Helmet is your most important piece of

riding gear because it offers the best

protection against head injuries. A helmet

should fit your head comfortably and securely.

A bright coloured helmet can make you more

noticeable in traffic, as can reflective strips.

An open-face helmet offers some protection,

but a full-face helmet offers more. Always

wear face shield or goggles to protect your

eyes and help your vision.

Additional riding gear

In addition to a helmet and eye protection, we

also recommend:

îSturdy boots with non-slip soles to help

protect your feet and ankles.

îLeather gloves to keep your hands warm

and help prevent blisters, cuts, burns, and

bruises.

îNot wearing a helmet increases the chance

of serious injury or death in a crash.

îBe sure you and your pillion always wear a

helmet, eye protection and other protective

apparel when you ride.

WARNING

Personal safety is your first priority. If you or

anyone else has been injured, take time to

assess the severity of the injuries and whether

it is safe to continue riding. Call for emergency

assistance if needed. Also follow applicable

laws and regulations if another person or

vehicle is involved in the crash.

If you are involved in a crash

PROTECTIVE APPAREL

For your safety, we strongly recommend that

you always wear an approved helmet (ISI

marked), eye protection, boots, gloves, long

pants and a long sleeve shirt or jacket

whenever you ride. Take care of loose/

hanging clothes while solo/pillion riding.

Although complete protection is not possible,

wearing proper gear can reduce the chance of

injury when you ride.

Following are suggestions to help you choose

proper riding gear.

If you decide to continue riding, first evaluate

the condition of your motorcycle. If the engine

is still running, turn it off. Inspect for fluid

leaks, check the tightness of critical nuts and

bolts, and check the handlebar, brake levers,

brakes, and wheels. Ride slowly and

cautiously. Your motorcycle may have

suffered damage that is not immediately

apparent. Have your motorcycle thoroughly

checked at a qualified service facility as soon

as possible.

îMake sure that the accessory does not

obscure any lamps, reduce ground

clearance, limit suspension travel or

steering travel, affect your riding position or

interfere with operating any controls.

îDo not pull a trailer or sidecar with your

motorcycle. This motorcycle was not

designed for these attachments, and their

use can seriously impair your motorcycle's

handling.

îBe sure electrical equipment does not exceed

the motorcycle's electrical system capacity

(page 3). A blown fuse can cause a loss of

lights.

Modifying your motorcycle or using non-

Hero MotoCorp accessories can make your

motorcycle unsafe. Before you consider

making any modifications or adding an

accessory, be sure to read the following

information.

ACCESSORIES & MODIFICATIONS

We strongly advise you not to remove any

original equipment or modify your

motorcycle in any way that would change its

design or operation. Such changes could

seriously impair your motorcycle's handling,

stability and braking, making it unsafe to

ride. Removing or modifying your lamps,

mufflers, emission control system or other

equipment can also make your motorcycle

illegal.

Modifications

îFollow all instructions in this owner's manual

regarding accessories and modifications.

îImproper accessories or modifications can

cause a crash in which you can be seriously

hurt or killed.

WARNING

________________________________________________________

_____________________________________________________

PHONE NO : _____________________________________

ANTI-THEFT TIPS

îAlways lock the steering and never leave the

key in the ignition switch .

îPark your motorcycle in a locked garage

whenever possible.

îPut your name, address and phone number

in this Owner's Manual and keep it in your

motorcycle at all times.

îMany times stolen motorcycles are identified

by information in the Owner's Manuals that

are still with them.

NAME: _____________________________________________

îUse an additional anti-theft device of good

quality.

ADDRESS: _______________________________________

Accessories

Otros manuales para GLAMOUR PROGRAMMED FI

Tabla de contenidos

Otros manuales de Motocicleta de HERO

HERO

HERO PASSION XTEC Manual de usuario

HERO

HERO DAWN-150 Manual de usuario

HERO

HERO MAESTRO EDGE Manual de usuario

HERO

HERO MAESTRO EDGE 125 PROGRAMMED FI Manual de usuario

HERO

HERO PLEASURE+ PROGRAMMED FI Manual de usuario

HERO

HERO HF-DAWN Manual de usuario

HERO

HERO HF-Deluxe Manual de usuario

HERO

HERO MAESTRO EDGE 125 PROGRAMMED FI Manual de usuario

HERO

HERO Splendor Pro CLASSIC Manual de usuario

HERO

HERO GLAMOUR PROGRAMMED FI Manual de usuario

HERO

HERO SPLENDOR+ Manual de usuario

HERO

HERO HF-DELUXE PROGRAMMED FI Manual de usuario

HERO

HERO PLEASURE Manual de usuario

HERO

HERO Super Splendor Manual de usuario

HERO

HERO Splendor iSmart 110 Manual de usuario

HERO

HERO SPLENDOR+ PROGRAMMED FI Manual de usuario

HERO

HERO Achiever Manual de usuario

HERO

HERO SPLENDOR iSMART+ Manual de usuario

HERO

HERO IGNITOR TECHNO Manual de usuario

HERO

HERO HUNK 150R Manual de usuario

HERO

HERO MotoCorp XPULSE 200T Manual de usuario

HERO

HERO Passion Xpro Manual de usuario

HERO

HERO MAESTRO EDGE Manual de usuario

HERO

HERO Passion Pro Manual de usuario

Manuales populares de Motocicleta de otras marcas

OHVALE

OHVALE GP-0 Manual de lista de piezas

Yamaha

Yamaha Star XV19CTSZ 2009 Manual de usuario

KTM

KTM 350 XCF-W USA Manual de usuario

HYOSUNG

HYOSUNG ST7 Manual de usuario

Husqvarna

Husqvarna FC 250 2016 Manual de usuario

Ducati

Ducati SCRAMBLER 800 Manual de instrucciones

MOTO GUZZI

MOTO GUZZI QUOTA 1100 ES Manual de usuario

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manual de usuario

Yamaha

Yamaha 2006 YZF-R1V Manual de usuario

KTM

KTM Freeride E-XC 2021 Manual de usuario

Fantic

Fantic Enduro 125 Manual de usuario

Ducati

Ducati Supersport 750 desmodue Manual de usuario

MV Agusta

MV Agusta 2008 F4 312RR 1078 Manual de instrucciones

Yamaha

Yamaha XVS650A Manual de usuario

Yamaha

Yamaha YZF-R6T(C) Manual

Ducati

Ducati 748 monoposto strada Manual de usuario

ATK

ATK 1988 250 Manual de usuario

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Manual de usuario
