HERO SPLENDOR+ PROGRAMMED FI Manual de usuario
PREFACE
Your Authorised Hero MotoCorp dealer will be glad to provide further information or
assistance and is equipped to handle your future service needs.
Thank you for selecting a Hero MotoCorp SPLENDOR+ PROGRAMMED FI. We wish
you many miles of continued riding pleasure in the years ahead.
We, at Hero MotoCorp, are committed to demonstrate excellence in our environment
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve environment
compatibility, comply with all applicable legislation including environment legislation and
strengthen the green supply chain.
Your vehicle is conforming to latest (Bharat stage-VI norms) regulation for emission, safety &
noise levels. We are also using non asbestos brake shoes/pads and engine gaskets which are
environment friendly in nature.
This vehicle is fitted with a lighting feature known as “Automatic Headlamp ON”. The feature
is mandated for all 2 Wheelers by Ministry of Road Transport & Highways (Government of
India) vide notification GSR 188 (E) dated 22nd February 2016. This feature helps in
conspicuity for improving rider safety. The headlamp of this vehicle will always be lit ON when
the engine gets ON.
This booklet is your guide to the basic operation and maintenance of your new Hero
MotoCorp SPLENDOR+ PROGRAMMED FI. Please take time to read it carefully. As with
any fine machine, proper care and maintenance are essential for trouble-free operation and
optimum performance.
Let us make this world a safer, healthier and more environment friendly place.
Hero MotoCorp Ltd RESERVES THE RIGHT TO MAKE CHANGES IN ITS
CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR INCURRING ANY
OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO REPRODUCE ANY
PART OF THIS PUBLICATION WITHOUT OBTAINING PRIOR WRITTEN
PERMISSION FROM Hero MotoCorp Ltd.
ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION AVAILABLE
AT THE TIME OF ITS PRINTING APPROVAL, AND THE ACCURACY OR
CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR GUARANTEED.
NOTE
ACCESSORIES SHOWN MAY NOT BE THE PART OF STANDARD FITMENT. IT
IS OUR ENDEAVOUR TO CONSTANTLY IMPROVE OUR PRODUCTS. THIS
COULD LEAD TO CHANGE IN PRODUCT SPECIFICATIONS WITHOUT
NOTICE. Hero MotoCorp Ltd ‘SPLENDOR+ PROGRAMMED FI’ COMPLIES
WITH THE LATEST EMISSION NORMS.
Pg. No.Pg. No.
CONTENTS
Pg. No.
VEHICLE IDENTIFICATION 1
VEHICLE VIEWS 2
VEHICLE SPECIFICATION 5
ACCESSORIES & MODIFICATIONS 7
ANTI-THEFT TIPS 7
VEHICLE SAFETY 8
•Important safety information 8
•Protective apparel 9
SAFE RIDING TIPS 10
TIPS FOR HEALTHY ENVIRONMENT 11
PARTS FUNCTION 12
•Ignition switch 12
MAINTENANCE 25
i3s (IDLE STOP START SYSTEM) 16
FEATURES 14
PARKING/UTILITY BOX 24
USB CHARGER 19
TOOL KIT/FIRST AID KIT 24
RIDING/BRAKING 22
CLEANING AND WASHING OF VEHICLE 25
STARTING THE ENGINE 21
PRE-RIDE INSPECTION 20
FUEL TANK 18
SIDE STAND INDICATOR/SWITCH 18
•Instruments & Indicators 13
HANDLEBAR SWITCHES CONTROLS 14
DRIVE CHAIN SLACKNESS 38
OIL FILTER SCREEN & CENTRIFUGAL FILTER 32
SUSPENSION 44
MAIN/SIDE STAND LUBRICATION 46
AIR CLEANER 33
FUSE REPLACEMENT 51
SAFETY PRECAUTION 26
MAINTENANCE SCHEDULE 27
SPARK PLUG INSPECTION 30
CLUTCH LEVER FREE PLAY 36
ENGINE OIL 31
VALVE CLEARANCE ADJUSTMENT 35
THROTTLE OPERATION 37
DRIVE CHAIN SLIDER INSPECTION 40
BRAKES 41
WHEEL 44
TUBELESS TYRES 47
NUTS, BOLTS & FASTENERS 50
BATTERY 50
STOP LAMP SWITCH 52
HEADLAMP FOCUS ADJUSTMENT 53
CATALYTIC CONVERTER 53
EVAPORATIVE EMISSION CONTROL SYSTEM 54
POLISHING OF VEHICLE 54
BASIC TROUBLESHOOTING 55
ROAD SIGNS 57
WARRANTY
HERO GENUINE PARTS
ZONAL/REGIONAL/AREA OFFICES
1
1. During registration of the vehicle.
VIN and Engine No. may be required:
2. For dealing with legal & insurance departments.
HA11ED#
#######
MBLHAW12#########
VIN: MBLHAW12#########
MBL HAW12 # # # #####
Manufacturer
code Vehicle
Description Model Year Plant
Code Month of
Manufacturing Production
Serial Number
#
Check
Digit
Engine No.: HA11ED########
HA11EY # # # #####
Engine
Description Year of
Manufacturing Assembly Plant Month of
Manufacturing Serial Number
VIN Engine
Variants
Model: SPLENDOR+ PROGRAMMED FI
Electric Start/Drum/Cast Wheel/i3s
HA11ED
HAW12
VEHICLE IDENTIFICATION
Engine No.
Location: Stamped on the lower side of the
left crankcase.
Location: Stamped on the right side of the
steering head tube.
Vehicle Identification Number (VIN)
Electric Start/Drum/Cast Wheel
HA11EV
HAW11
Kick Start/Drum/Cast Wheel
HA11ET
HAC05
Electric Start/Drum/Cast Wheel/i3s
HA11EY
HAW12
(1) Turn signal indicator
(4) Turn signal lamp switch
(2) Side stand indicator
(3) Horn switch
(5) Clutch lever
(6) Rear view mirror
(10) i3s indicator
(9) Speedometer
(11) Neutral indicator
(8) Odometer
(7) Headlamp dimmer switch
(14) High beam indicator
(15) i3s switch
(21) Leg guard
(13) Fuel gauge
(12) Programmed FI malfunction indicator
lamp (MIL)
(16) Front brake lever
(17) Throttle grip
(18) Electric starter switch
(19) Ignition switch with steering lock
(20) Fuel tank lid
TOP VIEW
3
5
6
17
16
21
18
2
VEHICLE VIEWS
4
1
2
10 11 13
19
*Accessories and features shown may not be part of standard fitment.
8 9 14 15
12
20
7
LEFT SIDE VIEW
6
145
3
11
(7) Saree guard with
women pillion step
(8) Rear reflex reflector
(9) Rear turn signal lamp
(10) Tail/stop lamp
(11) Rear carrier
(1) Gearshift pedal
(2) Side stand switch
(3) Main stand
(4) Side stand
(5) Pillion footrest
(6) Left side cover
( 2)1 ECU (inside)
(14) USB charger
(15) Front turn signal lamp
(16) Side reflex reflector
(13) Throttle body
3
7
10
15
*Accessories and features shown may not be part of standard fitment.
13 12
8
16
14
2
9
(7) Oil level dipstick
(10) Headlamp
(6) Rear brake pedal
(8) Utility box
(9) Front suspension
(12) Fuel tank
(11) Front visor
(13) Seat
(14) Rear shock absorber
(15) Exhaust muffler
RIGHT SIDE VIEW
(2) Battery compartment (Inside)
(1) Pillion footrest
(3) Kick starter pedal
(4) Rider footrest
(5) Starter motor
10
11
23
*Accessories and features shown may not be part of standard fitment.
1
4
5
9
8
9
12
13
15
47
14
SPECIFICATIONSITEM
Dimensions
Overall length 2000 mm
Overall width 720 mm
Overall height 1052 mm
Wheelbase 1236 mm
Saddle height 785 mm
Ground clearance 165 mm
Engine oil 1 litres at disassembly and 0.85 litre at draining
Weight
Capacities
Maximum power 5.9 kW @ 8000 r/min
Maximum torque 0.82 kgf-m (8.05 N-m) @ 6000 r/min
Bore and stroke 50.0x49.5 mm
Displacement 97.2 cc
Engine
Spark plug gap 0.6-0.7 mm
Idle speed 1400 100 r/min± in hot condition
Front suspension Telescopic hydraulic shock absorbers
Valve clearance 0.10 mm
0.10 mm
Intake
Exhaust
Chassis and suspension
Rear suspension Swing arm with 5 step adjustable hydraulic shock
absorbers
5
Compression ratio 9.9:1
VEHICLE SPECIFICATION
Spark plug NGK-CR7HSA, BOSCH-UR4AC,
Federal Mogul-P-RZ9HC
Caster angle 26°
Fuel tank 9 .8 litres
Trail length 80 mm
Kerb weight 112 kg
Side stand indicator LED
Hi beam indicator 12V-1.7W
Alternator 125 W @ 5000 r/min
Neutral indicator 12V-1.7W
Headlamp (High/Low) 12V-35/35W (Halogen Bulb**MFR)
Tail/Stop lamp 12V-5/10W-**MFR
Meter illumination 12V-1.7Wx2
rd
31.238 (26/21)
th
40.958 (23/24)
1.706 (29/17)
nd
2
Electricals
SPECIFICATIONSITEM
Brakes
Internal expanding shoe type, 130 mm
Internal expanding shoe type, 130 mm
(Integrated braking system)
Front
Rear
st
Gear ratio, 1 3.182 (35/11)
Final reduction 3.143 (44/14)
Primary reduction 3.722 (67/18)
Transmission
Tyre size Front
Rear
80/100-18M/C 47P (Tubeless tyre)
80/100-18M/C 54P (Tubeless tyre)
Turn signal lamp 12V-10Wx4 **MFR
Turn signal indicator 12V-3.0Wx2
6
* MF stands for Maintenance Free
** MFR stands for Multi-Focal Reflector
i3s indicator LED
VEHICLE SPECIFICATION
Programmed-Fi Malfunction indicator lamp (MIL) LED
Fuse 15A,10A (Circuit fuse) & 15A, 10A (Spare fuse)
Fuse box (1)
Fuse box (2) 10A (Circuit fuse) & 10A (Spare fuse)
Position lamp 12V-3W
Battery *MF Battery12V-3Ah/ETZ-4
ACCESSORIES & MODIFICATIONS
Modifying your vehicle or using non-Hero
MotoCorp accessories can make your vehicle
unsafe. Before you consider making any
modifications or adding an accessory, be sure
to read the following information.
operation. Such changes could seriously
impair your vehicle's handling, stability and
braking, making it unsafe to ride. Removing or
modifying your lamps, mufflers, emission
control system or other equipment can also
make your vehicle illegal.
•Use an additional anti-theft device of good
quality.
•Never park your vehicle in an isolated area.
Park as far as possible in a designated area.
•Always lock the steering and never leave the
key in the ignition switch. This sounds
simple but people do forget.
•Park your vehicle in a locked garage
whenever possible.
•Be sure the registration information for your
vehicle is accurate and correct.
ANTI-THEFT TIPS
•Enter your name, address and phone
number in this Owner's Manual and keep it
in your vehicle at all times. Many times
stolen vehicles are identified by information
in the Owner's Manuals that are still with
them.
NAME: _____________________________________________
_______________________________________________________
ADDRESS: _______________________________________
_______________________________________________________
_______________________________________________________
PHONE NO : _____________________________________
Modifications
Accessories
•Make sure that the accessory does not
obscure any lamps, reduce ground
clearance, limit suspension travel or steering
travel, affect your riding position or interfere
with operating any controls.
•Be sure electrical equipment does not
exceed the 's electrical system vehicle
capacity (page 6). A blown fuse can cause a
loss of lights.
•Do not pull a trailer or sidecar with your
vehicle. This vehicle was not designed for
these attachments, and their use can
seriously impair your vehicle's handling.
We strongly advise you not to remove any
original equipment or modify your vehicle in
any way that would change its design or
•Follow all instructions in this owner's manual
regarding accessories and modifications.
•Improper accessories or modifications can
cause a crash in which you can be seriously
hurt or killed.
WARNING
!!
7
Tabla de contenidos
Otros manuales de Motocicleta de HERO
HERO
HERO SPLENDOR iSMART+ Manual de usuario
HERO
HERO XTREME 160R 4V Manual de usuario
HERO
HERO Achiever Manual de usuario
HERO
HERO HUNK Manual de usuario
HERO
HERO MAESTRO EDGE 125 PROGRAMMED FI Manual de usuario
HERO
HERO XPULSE 200T PROGRAMMED FI Manual de usuario
HERO
HERO MotoCorp XPULSE 200 Manual de usuario
HERO
HERO MAESTRO Manual de usuario
HERO
HERO SPLENDOR PRO Manual de usuario
HERO
HERO Passion Pro Manual de usuario
HERO
HERO PLEASURE Manual de usuario
HERO
HERO HF-DAWN Manual de usuario
HERO
HERO GLAMOUR XTEC PROGRAMMED FI Manual de usuario
HERO
HERO Splendor Pro CLASSIC Manual de usuario
HERO
HERO IGNITOR Manual de usuario
HERO
HERO Karizma ZMR Manual de usuario
HERO
HERO DUET Manual de usuario
HERO
HERO HUNK 150R Manual de usuario
HERO
HERO HF 100 Manual de usuario
HERO
HERO PASSION PRO PROGRAMMED FI Manual de usuario
Manuales populares de Motocicleta de otras marcas
MOTO GUZZI
MOTO GUZZI QUOTA 1100 ES Manual de usuario
APRILIA
APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manual de usuario
Yamaha
Yamaha 2006 YZF-R1V Manual de usuario
KTM
KTM Freeride E-XC 2021 Manual de usuario
Fantic
Fantic Enduro 125 Manual de usuario
Ducati
Ducati Supersport 750 desmodue Manual de usuario
