PREFACE

We, at Hero MotoCorp, are committed to demonstrate excellence in our environment

performance on a continual basis, as an intrinsic element of our corporate philosophy. To

achieve this we commit ourselves to continue product innovations to improve

environment compatibility, comply with all applicable legislation including

environment legislation and strengthen the green supply chain.

This booklet is your guide to the basic operation and maintenance of your new Hero

MotoCorp Passion PRO TR. Please take time to read it carefully. As with any fine

machine, proper care and maintenance are essential for trouble-free operation and

optimum performance.

Your motorcycle is conforming to latest (Bharat Stage-III norms) regulation for

emission, safety & noise levels. We are also using non asbestos brake shoes / pads and

engine gaskets which are environment friendly in nature.

Thank you for selecting a Hero MotoCorp Passion PRO TR. We wish you many miles of

continued riding pleasure in the years ahead.

Your Authorised Hero MotoCorp dealer will be glad to provide further information or

assistance and is equipped to handle your future service needs.

Let us make this world a safer, healthier and more environment friendly place.

ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,

SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S

MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION

AVAILABLE AT THE TIME OF ITS PRINTING APPROVAL, AND THE

ACCURACY OR CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR

GUARANTEED. Hero MotoCorp Limited. RESERVES THE RIGHT TO MAKE

CHANGES IN ITS CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR

INCURRING ANY OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO

REPRODUCE ANY PART OF THIS PUBLICATION WITHOUT OBTAINING

PRIOR WRITTEN PERMISSION FROM Hero MotoCorp Limited.

NOTE

UTILITY BOX

ANTI THEFT TIPS

SAFETY PRECAUTIONS 28

ACCESSORIES AND MODIFICATIONS

FUEL GAUGE / ODOMETER / TRIP METER

SERVICE REMINDER INDICATOR

FUEL VALVE

SIDE STAND INDICATOR/ SIDE STAND SWITCH 15

/ PARKING

STEERING LOCK / SEAT LOCK

ENGINE OIL/ENGINE OIL TOP UP PROCESS

OIL FILTER SCREEN & CENTRIFUGAL FILTER 31

STOP LAMP SWITCH

SIDE STAND

HEADLAMP ADJUSTMENT

THROTTLE CONTROLLED IGNITION SYSTEM

BRAKE PAD WEAR (FRONT BRAKE)

BRAKE WEAR INDICATOR (REAR BRAKE)

FUSE REPLACEMENT

HERO GENUINE PARTS

MBLXXXXBAYZXYYYYY

XXXXENY

ZXYYYYY

Model Code :

Model Engine

VIN

MBLXXXXBAYZXYYYYY

MBL

Manufacturer

Code

XXXXBA

Vehicle

Description

Year of

Mfg.

Assembly

Plant

Month of

Mfg.

YYYYY

Serial

Number

XXXXEN

Engine

Description

Year of

Mfg.

Assembly

Plant

Month of

Mfg.

YYYYY

Serial

Number

XXXXENYZXYYYYY

BA EN

Passion PRO TR (Cast wheel/Electric start/Disc)

Vehicle Identification Number (VIN)

VIN

119 kg

12.8 litres

1.0 litre (usable)

1980 mm

1085 mm

840 mm

1235 mm

165 mm

795 mmSaddle Height

1.05 litres at disassembly

0.85 litre at draining

9.0 :1

0.6 - 0.7 mm

IN : 0.10 mm EX : 0.10 mm

5.74 kW (7.8 Ps) @ 7500 r/min

97.2 cc

162-165 ml

PRODUCT SPECIFICATION

ITEM SPECIFICATIONS

DIMENSIONS

WEIGHT

CAPACITIES

ENGINE

NGK-CR7HSA, BOSCH-UR4AC,

Champion-PRZ 9 HC (Federal Mogul)

Maximum Power

Maximum Torque 0.82 kgf-m (8.04 N-m) @ 4500 r/min

r/min

Front Suspension Telescopic Hydraulic Shock Absorbers

Rear Suspension

Swing Arm with 5 step adjustable Hydraulic Shock Absorber

2.75 x 18 - 6 PR / 50L

3.00 x 18 - 6 PR / 52P

3.722 (67/18)

3.143 (44/14)

3.181 (35/11)

1.706 (29/17)

1.238 (26/21)

0.958 (23/24)

Rear Wheel

Cast Wheel

Trail length 85 mm

Disc Type Dia 240 mm

Front Wheel

10 A / 15 A

Electric start

Position lamp 12V 3.0W

115 W

** MF stands for Maintenance Free

12V 35/35W Trapezoidal Halogen Bulb -MFR*

Head lamp (High/Low)

12V 5/10W, 12V 10W (Twin Bulb) MFR*

Tail/Stop lamp

(Amber bulb) with clear lens-MFR*

Turn signal lamp

ITEM SPECIFICATIONS

CHASSIS AND SUSPENSION

POWER TRANSMISSION

ELECTRICAL

FUSE

**MF Battery, MF-4:12V 3 Ah

L.E.D.

12V 1.12W

L.E.D.

Side Stand Indicator

3. While riding, sit in a comfortable posi-

tion with your legs close to fuel tank.

8. Give way to others on the road and sig-

nal before you make a turn.

2. Always wear a helmet (ISI marked)

with chin strap securely fastened and

insist on a helmet for your pillion rider.

4. Ride defensively and at a steady speed

(between 40-50 km/hr).

7. During night time, dip headlamps of

your motorcycle for oncoming traffic,

or when following another vehicle.

11. Get your motorcycle serviced regularly

by the Authorised Hero MotoCorp

workshop.

1. Always conduct simple pre-ride

inspection (page 22).

6. Respect road signs and obey traffic rules

for your own safety and that of others on

the road (pages 57 & 58).

9. To make yourself more visible, wear

bright reflective clothing that fits well.

5. For stopping motorcycle, use both

brakes simultaneously, keeping throttle

in the close position.

Do's:

10. Take care of loose / hanging clothes

while solo / pillion riding.

motorcycle.

SAFE RIDING TIPS

muffler.

Modifying your motorcycle or using non-

Hero MotoCorp accessories can make

your motorcycle unsafe. Before you

consider making any modifications or

adding an accessory, be sure to read the

following information.

Improper accessories or modifications

can cause a crash in which you can be

seriously hurt or killed.

Follow all instructions in this owner's

manual regarding accessories and

modifications.

• Make sure that the accessory does not

obscure any lamps, reduce ground

clearance, limit suspension travel or

steering travel, affect your riding

position or interfere with operating any

controls.

• Be sure electrical equipment does not

exceed the motorcycle's electrical

system capacity (page 3). A blown fuse

can cause a loss of lights.

Modifications

We strongly advise you not to remove

any original equipment or modify your

motorcycle in any way that would

change its design or operation. Such

changes could seriously impair your

motorcycle's handling, stability and

braking, making it unsafe to ride.

• Do not pull a trailer or sidecar with

your motorcycle. This motorcycle was

not designed for these attachments,

and their use can seriously impair your

motorcycle's handling.

Removing or modifying your lamps,

mufflers, emission control system or

other equipment can also make your

motorcycle illegal.

Accessories

ACCESSORIES & MODIFICATIONS

Regular Servicing: Get your motorcycle serviced at an Authorised Hero MotoCorp

workshop, as per the service schedule, for an optimum performance and keep the

emission level under check.

Genuine Engine Oil: Use Hero 4T Plus SAE 10W 30 SL grade (JASO MA2) engine

oil recommended by Hero MotoCorp and make sure you change it every 6000 kms.

(with top up every 3000 kilometres) to keep the engine fit and environment healthy.

The following tips shall ensure a healthy motorcycle, healthy environment, and a healthy you.

Genuine Spares: Always insist on Hero MotoCorp genuine parts as spurious or

incompatible spares and accessories can upset or deteriorate your motorcycle’s

running condition.

& fuel efficiency.

Noise Pollution : Noise beyond a certain decibel is pollution. Whether it is from

horns or defective mufflers, excessive noise will cause headaches and discomfort.

Emission Pollution : Get emission of your motorcycle checked by Aurhorised

agencies atleast once every 3 months or as notified by the government from time to

time.

Fuel saving & reduce pollution : Switch "OFF" the engine while waiting at traffic

signal points to save fuel and reduce pollution, if the waiting period is long.

TIPS FOR HEALTHY ENVIRONMENT

711

(7) Dimmer switch

(11) Speedometer

(5) Passing switch

(10) High beam indicator

(1) Horn switch

(2) Turn signal switch

(9) Neutral indicator

(6) Rear view mirror

(3) Clutch lever

(8) Side stand indicator

(4) Headlamp switch

(12) Turn signal indicator

(13) LCD panel

(14) Reset button

(15) Master cylinder

(17) Throttle grip

(19) Ignition switch with steering lock

(20) Fuel tank cap

(18) Electric starter switch

(16) Front brake lever

(21) Leg guard

141312

8 9 10

DESCRIPTION
