Heath Zenith 7797 Manual de usuario

Wireless Push Button

Accessory

Model

Wireless

push

button

Wireless

push

button

Hardware

pack

7797 ✔ ✔

7393 ✔ ✔

The Heath®Zenith wireless push button accessory works with any Heath®Zenith

wireless chime. This package includes:

Style of push button may vary from illustration.

Note: All

illustrations show model 7797. The instructions are the

same for all models.

Helpful Videos – www.hzsupport.com Helpful Answers – 1-800-858-8501

Figure 1

WARNING:To prevent possible SERIOUS INJURY or DEATH:

• NEVER allow small children near batteries.

• If battery is swallowed, immediately notify doctor.

Figure 2

1 2 3 4 5 6 7 8

TUNE – HOLD

1 SECOND.

SYNC – HOLD

3 SECONDS.

RESET – HOLD

10 SECONDS.

MODEL: WL-4B

1 – MODE

2 – TUNE

3x - “C” TYPE BATTERIES

TYPE “C”

1 2

1. Remove orange battery tab from push button. Remove

back of case by pushing in tab on bottom with a small

screwdriver (see Figure 1). Remove orange battery tab.

2. Determine chime type. Look at the chime and determine

which type of chime will be connected to the push button

(see Figure 2).

• Chime < A > (2 Switches): The chime has only two

switches.

• Chime < B > (1 Button):The chime has a multi-function

button (“Tune/Sync/Reset” or “Sync/Reset”).

• Chime < C > (7 or 8 Jumpers or Switches):The chime

has a row of 7 or 8 jumpers or switches.

Helpful Videos – www.hzsupport.com Helpful Answers – 1-800-858-8501

Continued

3. Sync the push button and chime.

Syncing Chime < A >

Step A1 (see Figure 3)

• If the chime is plugged in, unplug the chime.

• Set chime switch 1 to the ON position. If the chime was

unplugged, plug chime into wall outlet.

Step A2

• Remove battery from push button. Wait 30 seconds.

• Install battery in push button.

• Within 1 minute of installing battery, press and hold the

push button for 5 to 7 seconds.

• Press the push button to conﬁrm sync. If chime sounds,

sync is complete.

• Go to step 4.

Syncing Chime < B >

Step B1 (see Figure 4)

• Press and hold the button on the chime until the chime

sounds a “Beep-Beep”.

• Press the push button within 60 seconds. The chime

will sound a “Beep-Beep” tone to indicate the push

button is synced.

• Press the push button to conﬁrm sync. If chime sounds,

sync is complete.

• Go to step 4.

Syncing Chime < C >

Step C1 (see Figure 5)

• Remove all jumpers from positions 1 through 7 on the

chime and place jumpers only on positions 1 and 2, or

set switches 1 and 2 to the ON position and switches

3 through 7 to the OFF position.

Figure 3

Chime

Setting ON

1 2

Figure 4

60 Sec.

Figure 5

Chime Setting

1 2 3 4 5 6 7 8

TYPE “C”

1 2 3 4 5 6 7 8

Helpful Videos – www.hzsupport.com Helpful Answers – 1-800-858-8501

Figure 6

• Remove battery from push button. Wait 30 seconds.

• Install battery in push button.

• Within 1 minute of installing battery, press and hold the

push button for 5 to 7 seconds.

• Press the push button to conﬁrm sync. If chime sounds,

sync is complete.

• Go to step 4.

4. Test range. Temporarily position push button where you

want it mounted. Press push button to verify chime and

push button work properly. If chime does not sound, see

Troubleshooting.

5. Mount push button. Use either screws or double sided

tape to mount push button.

• Screw Mounting: To mount with screws, remove

back of case by pushing in tab on bottom with a small

screwdriver (see Figure 1). Note: Remove material in

screw holes (if needed) before mounting with screws.

Attach back of case to door jamb or wall (see Figure

6). Snap front of push button on.

• Tape Mounting: When attaching push button using

double sided tape, make sure the surface of the door

jamb or wall is clean.

6. Battery replacement. Make sure batteries are installed

according to the diagram inside the push button.

IMPORTANT: Properly dispose of drained batteries.

Battery

Model

7797

Model

7393

Type A23 12V ✔

Type 2032 3V ✔

Helpful Videos – www.hzsupport.com Helpful Answers – 1-800-858-8501

Push Button Chime < A > 2-Sounds

Chime

3-Sounds

Chime

Jumper - ON Switch 2 - ON Ding Ding

Jumper - OFF Switch 2 - ON Ding-Dong Ding-Dong

Jumper - OFF Switch 2 - OFF Ding-Dong Ding-Dong

Jumper - ON Switch 2 - OFF Ding Westminster

Tune Setting Table – Chime < A > and Push Button Settings*

*For musical chimes, refer to the chime manual when selecting tune.

Tune Settings

Wireless chimes have different selectable tunes: Ding (one note tune) and Ding-Dong

(two note tune). Some models include Westminster (eight note tune) or musical

tunes. The factory setting is for the Ding-Dong (or Westminster if applicable) tune.

This tune can be changed by following the instructions in the Tune Setting Table.

Continued

Helpful Videos – www.hzsupport.com Helpful Answers – 1-800-858-8501

Push Button Chime < C > 2-Sounds

Chime

3-Sounds

Chime

Jumper - ON Jumper 8 or

Switch 8 - OFF

Ding Ding

Jumper - OFF Jumper 8 or

Switch 8 - OFF

Ding-Dong Ding-Dong

Jumper - OFF Jumper 8 or

Switch 8 - ON

Ding-Dong Westminster

Jumper - ON Jumper 8 or

Switch 8 - ON

Ding Ding

Tune Setting Table – Chime < C > and Push Button Settings*

*For musical chimes, refer to the chime manual when selecting tune.

Push Button Chime < B > 2-Sounds

Chime

3-Sounds

Chime

Jumper - ON ——— Ding Ding

Jumper - OFF Push button on

chime to select

tune

Ding-Dong Ding-Dong or

Westminster

Tune Setting Table – Chime < B > and Push Button Settings*

*For musical chimes, refer to the chime manual when selecting tune.

Helpful Videos – www.hzsupport.com Helpful Answers – 1-800-858-8501

Troubleshooting

1. PROBLEM:Chime does not sound or rang one time and quit.

A. POSSIBLE CAUSE: Batteries not installed correctly.

A. CORRECTIVE ACTION:Make sure batteries are installed according to

the diagram inside the push button and chime (if applicable).

B. POSSIBLE CAUSE: Batteries are dead.

B. CORRECTIVE ACTION:Check charge of push button and chime batteries

(if applicable) and replace if necessary.

C. POSSIBLE CAUSE: Push button and chime are not synced.

C. CORRECTIVE ACTION: Follow steps 2 and 3, page 2, to sync.

2. PROBLEM:

Batteries seem okay, but the chime does not work after installation.

A. POSSIBLE CAUSE:Chime or push button is mounted on metal or near

metal studs. Note: Metal reduces transmission range.

A. CORRECTIVE ACTION:Use 1/4 in. to 1/2 in. (6 to 13 mm) wood shims

to move chime or push button away from metal surface.

B. POSSIBLE CAUSE:Chime is mounted near concrete ﬂoor or wall. Note:

Concrete may reduce range.

B. CORRECTIVE ACTION: Move chime away from concrete surface.

C. POSSIBLE CAUSE: Chime and push button are installed too far apart.

C. CORRECTIVE ACTION: Locate chime closer to push button.

Note: The range of the wireless chime can vary with location, temperature, and

battery condition.

Helpful Videos – www.hzsupport.com Helpful Answers – 1-800-858-8501

Please contact us for assistance

before returning product to the

store or to HeathCo LLC.

If you experience a problem, follow this

guide.You may also contact us between

8:00 AM to 5:00 PM CST (M-F).

When contacting Technical Service,

please include the following informa-

tion: Name, Street Address, Daytime

Phone Number, Email Address, Model

Number, Date of Purchase, Place of

Purchase, Product Issue, and DATED

SALES RECEIPT FOR WARRANTY

REQUESTS.

Technical Service

No Service Parts Available for this

Product

HeathCo LLC

2445 Nashville Road

Bowling Green, KY 42101, USA

ATTN: Technical Service

Internet: www.hzsupport.com

Phone: 1-800-858-8501 (English Only)

Fax: 1-800-846-8500

Regulatory Information

This device complies with Part 15 of the FCC Rules and RSS-210 of Industry Canada.

Operation is subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

The user is cautioned that changes or modiﬁcations not expressly approved by

the party responsible for regulatory compliance could void the user’s authority to

operate the equipment.

Helpful Videos – www.hzsupport.com Helpful Answers – 1-800-858-8501

HeathCo LLC reserves the right to discontinue and to change speciﬁcations at any

time without notice without incurring any obligation to incorporate new features in

previously sold products.

ONE YEAR LIMITED WARRANTY

This is a “Limited Warranty” which gives you speciﬁc legal rights. You may

also have other rights which vary from state to state or province to province.

For a period of one year from the date of purchase, any malfunction caused by

factory defective parts or workmanship will be corrected at no charge to you.

Not Covered - Repair service, adjustment and calibration due to misuse,

abuse or negligence, light bulbs, batteries, and other expendable items are not

covered by this warranty. Unauthorized service or modiﬁcation of the product or

of any furnished component will void this warranty in its entirety.This warranty

does not include reimbursement for inconvenience, installation, setup time,

loss of use, unauthorized service, or return shipping charges.

This warranty covers only HeathCo LLC assembled products and is not

extended to other equipment and components that a customer uses in con-

junction with our products.

THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY, REPRESENTATION

OR CONDITION OF MERCHANT ABILITY ORTHATTHE PRODUCTS ARE FIT

FOR ANY PARTICULAR PURPOSE OR USE, AND SPECIFICALLY IN LIEU OF

ALL SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

REPAIR OR REPLACEMENT SHALL BE THE SOLE REMEDY OF THE CUS-

TOMER AND THERE SHALL BE NO LIABILITY ON THE PART OF HEATHCO

LLC FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL

DAMAGES, INCLUDING BUT NOT LIMITED TO ANY LOSS OF BUSINESS

OR PROFITS, WHETHER OR NOT FORESEEABLE. Some states or prov-

inces do not allow the exclusion or limitation of incidental or consequential

damages, so the above limitation or exclusion may not apply to you.

Please keep your dated sales receipt, it is required for all warranty

requests.

Vídeos prácticos – www.hzsupport.com Respuestas prácticas – 1-800-858-8501

Accesorio de pulsador

inalámbrico

El pulsador inalámbrico Heath®Zenith funciona con cualquier campana inalámbrica

Heath®Zenith. Este paquete tiene:

Modelo

Pulsador

inalámbrico

Pulsador

inalámbrico

Paquete de

ferretería

7797 ✔ ✔

7393 ✔ ✔

El estilo del pulsador puede variar de la ilustración. Nota: Todas

las ilustraciones muestran el modelo 7797. Las instrucciones

son las mismas para todos los modelos.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Accesorios de Heath Zenith

Heath Zenith

Heath Zenith Wireless Push Button Accessory 598-1151-02 Manual de usuario

Heath Zenith

Heath Zenith Wireless Mechanical Chime 598-1123-02 Manual de usuario

Heath Zenith

Heath Zenith 7750 Manual de usuario

Heath Zenith

Heath Zenith Hardwired Electronic Chime 598-1113-05 Manual de usuario

Heath Zenith

Heath Zenith Motion Sensor Entryway Light SL-5610/15 Manual de usuario

Heath Zenith

Heath Zenith Notifi Elite Manual de usuario

Heath Zenith

Heath Zenith 5867 Manual de servicio

Heath Zenith

Heath Zenith 7868 Manual de usuario

Heath Zenith

Heath Zenith 595-5707-06 Manual de usuario

Heath Zenith

Heath Zenith DUAL BRITE SL-5597 Manual de usuario

Heath Zenith

Heath Zenith 121AC Manual de usuario

Heath Zenith

Heath Zenith Decorative Wireless Chime 6180 Manual de usuario

Heath Zenith

Heath Zenith 598-1215-01 Manual de usuario

Heath Zenith

Heath Zenith Wireless Chime TR-0095-RX Manual de usuario

Heath Zenith

Heath Zenith SL-6153 Manual de usuario

Heath Zenith

Heath Zenith Wireless Dual Push Button Accessory SL-6200 Manual de usuario

Heath Zenith

Heath Zenith DualBrite 5716 Manual de usuario

Heath Zenith

Heath Zenith SL-6164 Manual de usuario

Heath Zenith

Heath Zenith Weatherproof Long Range Wireless Chime with Chime Extender... Manual de usuario

Heath Zenith

Heath Zenith Single Entrance Chime 23/M Manual de usuario

Heath Zenith

Heath Zenith Wireless Chime 6153/62/71/72 Manual de usuario

Heath Zenith

Heath Zenith DualBrite Manual de usuario

Heath Zenith

Heath Zenith 7307 Manual de usuario

Heath Zenith

Heath Zenith 7306 Manual de usuario

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario
