HBM T10FM Manual de usuario

A0894-5.2 en

Torque flange

T10FM

Mounting instructions

T10FM

A0894-5.2 en HBM

Contents Page

Contents

Safety instructions 5..............................................

1 Scope of supply 9.............................................

2 Application 9..................................................

3 Structure and mode of operation 10..............................

4 Mechanical installation 11.......................................

4.1 Conditions on site 12........................................

4.2 Installation orientation 12....................................

4.3 Installation options 12.......................................

4.3.1 Installation without dismantling the antenna ring 13.......

4.3.2 Installation with subsequent stator mounting 14...........

4.4 Preparing for the rotor mounting 15...........................

4.5 Mounting the rotor 17.......................................

4.6 Installing the stator 20.......................................

4.7 Installing the clamp fixture 22................................

4.8 Fitting the slotted disc (speed measuring system) 24............

4.9 Aligning the stator (speed measuring system) 25................

5 Electrical connection 27.........................................

5.1 General information 27......................................

5.2 Shielding design 27.........................................

5.3 Connector pin assignment 28................................

5.4 Supply voltage 30..........................................

6 Calibration signal 31............................................

7 Settings 32.....................................................

7.1 Torque output signal 32......................................

7.2 Setting up the zero point 33..................................

7.3 Functional testing 34........................................

7.3.1 Power transmission 34................................

7.3.2 Aligning the speed module 34..........................

7.4 Setting the pulse count 35...................................

7.5 Vibration suppression (hysteresis) 36..........................

7.6 Form of speed output signal 36...............................

7.7 Type of speed output signal 38...............................

8 Loading capacity 39.............................................

8.1 Measuring dynamic torque 39................................

T10FM

A0894-5.2 enHBM

9 Maintenance 41.................................................

9.1 Speed module maintenance 41...............................

10 Dimensions 42.................................................

10.1 Dimensions without speed measuring system 42................

10.2 Dimensions with speed measuring system 43..................

10.3 Mounting dimensions 44.....................................

11 Order numbers, accessories 45..................................

12 Specifications 46...............................................

13 Supplementary technical information 52..........................

13.1 Output signals 52...........................................

13.1.1 Output MD torque (connector 1) 52.....................

13.1.2 Output N Speed (connector 2) 53.......................

13.1.3 Output speed, double frequency, stat. direction of

rotation signal 54.....................................

13.2 Axial and radial run‐out tolerances 55.........................

13.3 Additional mechanical data 55................................

T10FM

A0894-5.2 en HBM

Safety instructions

Designated use

The T10FM torque flange is used exclusively for torque and rotation speed

measurement tasks, and directly associated control and regulatory tasks. Use

for any additional purpose shall be deemed to be not as intended.

In the interests of safety, the transducer should only be operated as described

in the Operating Manual. It is also essential to comply with the legal and

safety requirements for the application concerned during use. The same

applies to the use of accessories.

The transducer is not a safety element within the meaning of its designated

use. Proper and safe operation of this transducer requires proper

transportation, correct storage, assembly and mounting, and careful

operation.

General dangers of failing to follow the safety instructions

The transducer corresponds to the state of the art and is failsafe. The

transducer can give rise to remaining dangers if it is inappropriately installed

and operated by untrained personnel.

Everyone involved with mounting, starting up, maintaining, or repairing the

transducer must have read and understood the Operating Manual and in

particular the technical safety instructions.

Residual dangers

The scope of supply and performance of the transducer covers only a small

area of torque measurement technology. In addition, equipment planners,

installers and operators should plan, implement and respond to the safety

engineering considerations of torque measurement technology in such a way

as to minimize remaining dangers. On‐site regulations must be complied with

at all times. Reference must be made to remaining dangers connected with

torque measurement technology.

T10FM

A0894-5.2 enHBM

The following symbols are used in this Operating Manual to point out

remaining dangers:

Symbol: DANGER

Meaning: Maximum danger level

Warns of an imminently dangerous situation in which failure to comply with

safety requirements will result in death or serious physical injury.

Symbol: WARNING

Meaning: Dangerous situation

Warns of a potentially dangerous situation in which failure to comply with

safety requirements can result in death or serious physical injury.

Symbol: ATTENTION

Meaning: Possibly dangerous situation

Warns of a potentially dangerous situation in which failure to comply with

safety requirements could result in damage to property or some form of

physical injury.

Symbols for application and disposal instructions, as well as useful

information:

Means that important information about the product or its handling is being

provided.

Symbol:

Meaning: CE mark

The CE mark enables the manufacturer to guarantee that the product

complies with the requirements of the relevant EC directives (the Declaration

of Conformity can be found at http://www.hbm.com/hbmdoc).

T10FM

A0894-5.2 en HBM

Symbol:

Meaning: Statutory waste disposal mark

In accordance with national and local environmental protection and material

recovery and recycling regulations, old devices that can no longer be used

must be disposed of separately and not with normal household garbage.

If you need more information about waste disposal, please contact your local

authorities or the dealer from whom you purchased the product.

Conversions and modifications

The transducer must not be modified from the design or safety engineering

point of view except with our express agreement. Any modification shall

exclude all liability on our part for any damage resulting therefrom.

Qualified personnel

The transducer must only be installed and used by qualified personnel, strictly

in accordance with the specifications and with safety requirements and

regulations. It is also essential to comply with the legal and safety

requirements for the application concerned during use. The same applies to

the use of accessories.

Qualified personnel means persons entrusted with siting, mounting, starting

up and operating the product who possess the appropriate qualifications for

their function.

T10FM

A0894-5.2 enHBM

Accident prevention

According to the prevailing accident prevention regulations, once the torque

flange has been mounted, a covering agent or cladding has to be fitted as

follows:

The cover or cladding must not be free to rotate.

The cover or cladding should avoid squeezing or shearing and provide

protection against parts that might come loose.

Covers and cladding must be positioned at a suitable distance or be

arranged so that there is no access to any moving parts within.

Covers and cladding must also be attached if the moving parts of the

torque flange are installed outside peoples' movement and operating

range.

The only permitted exceptions to the above requirements are if the various

parts and assemblies of the machine are already fully protected by the design

of the machine or by existing safety precautions.

Warranty

In the case of complaints, a warranty can only be given if the torque flange is

returned in the original packaging.

T10FM

A0894-5.2 en HBM

1 Scope of supply

Rotor

Stator

Mounting instructions

Test record

Optional: Speed kit (slotted disc, screwdriver, screw locking device,

screws)

2 Application

The T10FM torque flanges record static and dynamic torque on stationary or

rotating shafts and determine the speed, specifying the direction of rotation.

Test beds can be extremely compact because of their extremely short

construction. They therefore offer a very wide range of applications.

In addition to conventional test‐bench engineering (engine, roll and

transmission test benches), new solutions are possible for torque

measurements partly integrated in the machines.

Thanks to the bearing‐free design and the contactless transmission of

excitation voltage and measured values, the torque measuring system of

torque flanges requires no maintenance. Thus there are no friction or bearings

heating effects.

The torque flanges are supplied for nominal (rated) torques from 15 kNm to

80 kNm. Depending on the nominal torque, maximum speeds of up to 6000

min-1 are permissible.

T10FM torque flanges are reliably protected against electromagnetic

interference. They have been tested with regard to EMC according to the

relevant European standards, and carry the CE mark.

T10FM

A0894-5.2 enHBM

3 Structure and mode of operation

The torque flange consist of two separate parts: the rotor and the stator. The

stator comprises an antenna ring and a housing.

Strain gauges (SGs) are mounted on the rotor. The rotor electronics for

transmitting the bridge excitation voltage and the measurement signal are

located centrally in the flange. The coils for the non‐contact transmission of

excitation voltage and measurement signal are located on the rotor's outer

circumference. The signals are sent and received by a separable antenna

ring. The antenna ring is mounted on a housing that includes the electronic

system for voltage adaptation and signal conditioning.

Connectors for the torque signal, the voltage supply and the speed signal

(option) are located on the stator. The antenna ring should be mounted

concentrically around the rotor (see Chapter 4).

In the case of the speed measuring system option, the speed sensor is

mounted on the stator, the customer attaches the associated slotted disc on

the rotor. The optical speed measurement works on the infrared transmitted

light principle.

Stator

Antenna segments

Rotor

Housing

Speed sensor (option)

Flange B

Flange A

Fig.3.1: Mechanical structure, exploded view

Otros manuales para T10FM

Tabla de contenidos

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
