Hand Held Products 3800PDF Manual de usuario

The 3800PDF model delivers fast and accurate

reading of PDF417 codes as well as all standard

linear symbologies. The specially designed hard-

ware and firmware are optimized for exceptional

PDF417 performance in all types of scanning

applications. PDF417 reading is accomplished by

sweeping the scanner up or down over the code,

quickly gathering, decoding, and outputting the data

to the host system. The scanner ticks while collecting

data, providing instant user feedback on perfor-

mance. All symbologies are automatically discrimi-

nated with no reduction in decoding speed.

The 3800PDF is a high performance, handheld bar

code scanner. The 3800PDF uses linear imaging

technology to set a new standard for handheld

scanners by combining a bright, sharp aiming line

with high resolution imaging to deliver exceptional

reading performance.

Each decoded output scanner has the capability to

connect as a keyboard wedge, use the serial port,

output non decoded laser compatible signals, or

operate in wand emulation mode. The 3800PDF

connects to all popular PCs, Apple MAC, USB, and

portable data terminals. A non decoded mode can

be used with external wedge decoders and portable

terminals or other devices with decoding capability.

Standard cables are used to reduce replacement

expense.

The 3800PDF is excellent in handheld scanning

applications, such as retail point of sale and in-store

inventory. It operates from a tabletop holder in

manual trigger mode, or may be placed in an

adjustable stand for automated operation. The

3800PDF can be used indoors or outside in bright

sunlight. Typical applications are retail point of sale,

in-store inventory, document management, transac-

tion processing of bar coded receipts, payment

counter, outdoor sales kiosks, and reading of vehicle

registrations.

PDF Decoding - Fast, accurate, economical PDF reading

using an innovative feedback design.

Bright, Sharp and Focused Aiming Line - Easy to aim and

scan codes in any lighting condition from darkness to full

sunlight, tightly stacked bar code sheets, or small, high

resolution labels.

Solid, Rugged Design - No moving parts inside and solid

construction outside deliver years of reliable service in

demanding work environments.

Modern Design - Attractive styling compliments most

existing POS environments, while user comfort is enhanced

by the smooth handle curves, soft molded grip area, and

comfortable trigger.

Powerful, Flexible Architecture - Connects and interfaces to

all major PCs and terminals easily and quickly with

Windowsâbased programming tools or bar code

programming menus.

Increased Reading Distances - Easily covers the full range

of handheld scanning uses in point of sale and general

purpose scanning applications.

Real World Reading Performance - Accommodates printer

induced bar space variation, faded labels, short quiet zones,

low contrast codes, dot matrix printing, and multipart forms

with higher resolution, better optics, and improved decoding

algorithms.

5 Year Warranty

3800PDF

Handheld Linear Imager for PDF417

Features

Now with RSS

Worldwide Offices

ffices Serving North America

kaneateles Falls, NY

el: +1 315 685 8945

r, in North America: +1 800 582 4263

apresales@handheld.com

harlotte, NC

el: +1 704 998 3998

r, in North America: +1 800 582 4263

apresales@handheld.com

ffices Serving Europe,

Middle East, and Africa

Europe

Tel: +31 (0) 40 29 01 600

eupresales@handheld.com

United Kingdom

Tel: +44 (0) 1 925 240055

eupresales@handheld.com

Italy

Tel: +39 (0) 2 67 100752

eupresales@handheld.com

France

Tel: +33 (0) 1 41 158220

eupresales@handheld.com

Germany

Tel: +49 (0) 7 477 151377

eupresales@handheld.com

Spain

Tel: +34 93 228 78 68

eupresales@handheld.com

Offices Serving Asia and the

Pacific Rim

Hong Kong

Tel: +852 2511 3050

appresales@handheld.com

Japan

Tel: +813 5770 6312

appresales@handheld.com

Shanghai

Tel: +86 21 6361 3818

appresales@handheld.com

Offices Serving Latin America

Naples, Florida

Tel: +1 239 263 7600

lapresales@handheld.com

São Paulo

Tel: +55 11 2178 0500

lapresales@handheld.com

Rio De Janeiro

Tel: +55 21 2178 0500

lapresales@handheld.com

Mexico

Tel: +52 55 5203 2100

lapresales@handheld.com

eb Site Address www.handheld.com

Due to Hand H

eld Products’ continuing product improvement programs, specifications and features herein are subject to change without notice.

Performance

Illumination: 630 NM Visible Red LED

ReceivingDevice: 3648elementlinear imager

PDF417BarCodes3:1 Aspect Ratio

ReadingDistance 10 mil 15 mil

Minimum 3 in. 3 in.

7.6 cm 7.6 cm

Maximum 4.5 in. 5 in.

11.4 cm 12.7 cm

SkewAngle: +55o

Pitch Angle: +55o

HorizontalVelocity: 2 in. (5.1 cm) per second

MinimumReflectance

Difference: 40%

ScanRate: Programmable to 270 scans per second

DecodeRate: Up to 270 decodes per second

Mechanical/Electrical

Dimensions

Length: 5.3 in. (13.5 cm)

Height 6 in. (15.2 cm)

Width: 3.1 in. (7.9 cm)

Weight: 6.3 oz. (179.2 g)

Housing: Polycarbonate/ABS blend, UL 94V0

PowerRequirements: 5Vdc + 10% at scanner

Current Draw: Scanning Standby In-Rush

@270 s/s 275mA 125mA 300mA

@67 s/s 150mA 125mA 300mA

PowerSupply

NoiseRejection: Maximum 100mV peak to peak, 10 to 100 kHz

Environmental

Temperature

Operating: +32oF to +122oF (0oC to +50oC)

Storage: -4oF to 140oF (-20oC to +60oC)

Humidity: 0 to 95%

MechanicalShock: Operational after 50 drops from 5 ft. (1.53 m) to concrete

AmbientIllumination: 0 - 70,000 lux

ESDProtection: Functional after 15kV discharge

Vibration: Withstands 5G peak from 20 to 300 Hz

Agency: FCC Class B, CE EMC Class B, CE Low Voltage Directive, IEC60825-1 LED Safety: Class 1, UL, cUL listed, TÜV

MTBF: per MIL-HDBK-217F Ground Benign exceeds 100,000 hours

Symbologies: PDF417, Codabar, Code 3 of 9 including PARAF, Interleaved 2 of 5, Code 2 of 5, Matrix 2 of 5, Code 11, Code 93, Code 128, UPC,

EAN/JAN, China Postal Code, RSS.

Interfaces: All popular PCs and terminals via keyboard wedge, keyboard

replacement/direct connect, Apple ADB, USB, TTL Level Serial Wedge,

TTL level RS-232, wand emulation mode, and includes (HHLC)

non decoded laser compatible output.

Warranty: Five year factory warranty.

3800PDF Specifications
