H3C SecPath AC2500 Manual de usuario

H3C SecPath AC2500 Power Module

User Manual

New H3C Technologies Co., Ltd.

http://www.h3c.com.hk

Document version: 6PW101-20170414

and its licensors

No part of this manual may be reproduced or transmitted in any form

or by any means without prior written consent of New H3C

Technologies Co., Ltd.

Trademarks

H3C, , H3CS, H3CIE, H3CNE, Aolynk, ,

H3Care, , IRF, NetPilot, Netflow, SecEngine, SecPath,

SecCenter, SecBlade, Comware, ITCMM and HUASAN are

trademarks of New H3C Technologies Co., Ltd.

All other trademarks that may be mentioned in this manual are the

property of their respective owners

Notice

The information in this document is subject to change without notice.

Every effort has been made in the preparation of this document to

ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute the warranty of

any kind, express or implied.

Environmental protection

This product has been designed to comply with the environmental

protection requirements. The storage, use, and disposal of this

product must meet the applicable national laws and regulations.

Obtaining documentation

To access the most up-to-date H3C product documentation, go to the

H3C website at http://www.h3c.com.hk

To obtain information about installation, configuration, and

maintenance, click http://www.h3c.com.hk/Technical_Documents

To obtain software version information such as release notes,

click http://www.h3c.com.hk/Software_Download

Technical support

[email protected]

http://www.h3c.com.hk

Documentation feedback

You can e-mail your comments about product documentation to

[email protected].

We appreciate your comments.

Contents

Overview ·················································· 1

Front panel ···································································· 2

LEDs············································································ 2

Technical specifications ··················································· 4

Power module configuration·············································· 5

Installing and removing the power module······· 6

Installing the power module··············································· 6

Installing the power module ·········································· 7

Connecting the power cord··········································10

Removing the power module············································11

Removing the power cord············································12

Removing the power module········································12

Overview

The AC2500 AC-input and DC-output power module provides a

maximum output of 2500 W. The available model is NSQM1AC2500.

It has the following features:

•It has protection against undervoltage input, overvoltage input,

overvoltage output, output short circuit, undercurrent output,

overcurrent output, and overtemperature.

•It is hot swappable. You can install and remove the power

module on an operating device.

•It can operate in N+1 or N+N redundancy. For more information,

see "Power module configuration."

NOTE:

The power module shuts down automatically when its

temperature exceeds the acceptable range. When the

temperature returns to the acceptable range, the power module

restarts automatically.

Front panel

Figure 1 Front panel

(1) Captive screw (2) Handle

(3) Power receptacle (4) Power output status LED (DC)

(5) Power input status LED (AC)

LEDs

The power module has two LEDs.

Table 1 LED description

LED Mark Color Description

Power

input

status

LED

Green Normal AC input.

Off

•No AC power input.

•Low AC input voltage. The

power module has entered

self-protection mode.

Power

output

status

LED

Green Normal DC output.

Red

•A DC output exception has

occurred, for example, output

short circuit, output overcurrent,

output overvoltage, input

undervoltage, or remote

shutdown. The power module

has entered self-protection

mode.

•No power is being input to the

power module. Other power

modules are supplying power to

the device.

Orange

The temperature of the power

module exceeds the acceptable

range. The power module has

entered self-protection mode.

NOTE:

fte

the circuit breaker of the power module is switched off, the

LEDs on the power module will remain on for a while. Make sure

the LEDs are off when you remove the power module.

Technical specifications

Table 2 Technical specifications

Item Specifications

Rated input voltage 100 to 240 VAC @50/60 Hz

Rated output voltage 12 VDC

Maximum input current 16 A

Maximum output current •208 A at 220 VAC

•100 A at 110 VAC

Maximum output power •1200 W at 110 VAC

•2500 W at 220 VAC

Dimensions (H × W × D) 41 × 102 × 391 mm (1.61 × 4.00 ×

15.36 in)

Ambient

temperature

Operating

temperature –10°C to +50°C (–14°F to

+122°F)

Storage

temperature –40°C to +85°C (–40°F to

+185°F)

Relative

humidity

Operating

humidity 30% to 95%, non-condensing

Storage

humidity 10% to 95%, non-condensing

Power module configuration

Follow these guidelines to configure power modules for a device:

•Determine the required number of power modules based on the

actual power consumption, the power module slot number, and

power redundancy design.

•Determine the power module redundancy design based on the

power source conditions.

{When two mains power inputs are provided, you can

configure the power modules in N+N redundancy. N+N must

be not greater than the total number of power module slots.

{When one mains power input is provided, you can configure

the power modules in N+1 or N+N redundancy. N+1 or N+N

must be not greater than the total number of power module

slots.

{For easy usage and maintenance, configure a circuit breaker

for each power input. The rated current of the circuit breaker

must be greater than 20 A.

Installing and removing the power

module

CAUTION:

Do not install the AC2500 power module and other types of

power modules on the same device.

The power module slots are either vertically or horizontally oriented,

depending on the device model. The power module installation and

removal procedure is similar for vertical and horizontal power module

slots. The figures in this section are for illustration only.

Installing the power module

To avoid bodily injury and device damage, follow the procedure

in Figure 2 to install the power module.
