Genie WIPX4VDVAF Manual de usuario

Quick Start Guide

Please read these instructions carefully before operating the unit

and keep for further reference.

4MP H.265 IP IR Vandal Dome

with 2.8-12mm Auto Focus

Lens and Facial Recognition

WIPX4VDVAF

Intro Section

Please read this instruction carefully before operating the product and keep it for further

reference. All examples and pictures used here are for reference only.

The contents of this manual are subject to change without notice.

CAUTION:

• If the product does not work properly, please contact your dealer or the nearest service

centre. Never attempt to disassemble the camera yourself. We shall not be responsible

for any problems caused by unauthorised repair or maintenance.

• Do not allow water or liquid into the camera while in use.

• When using the product, you must be in strict compliance with the electrical safety

regulations of the nation and region.

• When the product is mounted on wall or ceiling, the device needs to be ﬁrmly ﬁxed.

• Make sure the power supply voltage is correct before using the camera.

• Do not drop the camera or subject it to any physical shock.

• If cleaning, please use a clean soft cloth with a little neutral detergent to wipe it gently.

• Do not aim the camera at the sun or in any area where there is bright lighting.

• The device may be burned out by a laser beam, so when any laser equipment is in use,

make sure that the surface of the device will not be exposed to the laser beam.

• Do not place the camera in extremely hot, cold , dusty or damp locations, and do not

expose it to high electromagnetic radiation.

• To avoid heat accumulation, good ventilation is required for operating environment.

Contents

iii

1.0 Introduction..........................................................................................................4

1.1 Product Features...........................................................................................4

1.2 Product Dimensions.....................................................................................4

1.3 Contents ......................................................................................................4

1.4 Speciﬁcation ................................................................................................5

2.0 Overview..............................................................................................................7

3.0 Installation............................................................................................................9

3.1 Installing the Camera ...................................................................................9

3.2 Installing the Camera with a Junction Box..................................................10

4.0 Network Connection ...........................................................................................11

5.0 Camera Maintenance...........................................................................................12

The Genie WIPX4VDVAF is a 4MP IP IR vandal dome camera with a 2.8–12mm auto focus

lens. The camera features facial recognition when paired with any Genie AI NVR.

1.1 Product Features

• 4MP (2592×1520) H.265 full real time coding

• Maximum resolution: 2592 × 1520

• ICR auto switch, true day / night vision

• 30 ~ 50m IR night view distance

• Motorised zoom lens

• Supports image distortion correction

• 3D DNR, true WDR, HLC, BLC, Defog, NIR, Smart IR and ROI coding

• Built-in micro SD card slot up to 128GB

• DC12V/PoE power supply

• IP67 & IK10 ingress protection

• Supports three streams

• Intelligent analytics

• Supports remote monitoring by smart phones & tablet PCs with iOS and Android OS

• Onvif compliant

1.2 Product Dimensions

1.3 Contents

1.0 Introduction

Camera Quick Start Guide 4 Tapping Screws PA 4×25

CD Drill Template Plastic Plug x4

Rubber Plug L-Wrench CVBS & DC In Cables

141mm

100.2mm

Quick Start Guide 4MP H.265 IP IR Vandal Dome with 2.8-12mm Auto Focus Lens and Facial Recognition

1.4 Speciﬁcation

Camera

Image Sensor 1 / 3” CMOS

Image Size 2592 × 1520

Electronic Shutter 1 / 30 s ~ 1 / 100000 s

Iris Type DC Iris

Minimum Illumination 0.0038 Lux @ F1.4,AGC ON, 0 Lux with IR

0.0028 Lux @ F1.2,AGC ON, 0 Lux with IR

Lens 2.8~12mm @ F1.4, motorised

Lens Mount Φ14

Field of View Horizontal: 94.2°~29.8°, Vertical: 62.4°~17°, Diagonal: 102°~33.9°

Day & Night ICR

Wide Dynamic Range 120dB

BLC Yes

HLC Yes

Defog Yes

Digital NR 3D DNR

Angle Adjustment Pan: 0°~345°, Tilt:0°~77°, Rotation: 0°~345°


Video Compression Smart H.265 / H.265+ / H.265 / Smart H.264 / H.264+ / H.264

/ MJPEG

H.264 Compression

Standard Baseline Proﬁle / Main Proﬁle / High Proﬁle

Resolution 4MP (2592 × 1520), 2K (2560 × 1440), 3MP (2304 × 1296),

1080p (1920 × 1080), 720p (1280 × 720), D1, CIF, 480 × 240

Main Stream

4MP / 2K / 3MP / 1080p / 720p

(60Hz : 1 ~ 30fps, 50Hz: 1~25fps)

HFR mode: 1080p / 720p

(60Hz : 1 ~ 60fps, 50Hz: 1~50fps)

Sub Stream 720p / D1 / CIF / 480 × 240 (60Hz : 1 ~ 30fps, 50Hz: 1~25fps)

Third Stream D1 / CIF / 480 × 240 (60Hz : 1 ~ 30fps, 50Hz: 1~25fps)

Bit Rate 64 Kbps ~ 8 Mbps

Bit Rate Type VBR / CBR

Audio Compression G711A / U

Image Settings

ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic,

Sharpen, NR,etc. Adjustable through client software or web

browser

ROI Each ROI to be conﬁgured separately

Interface

Network RJ45

Video Output CVBS Output (BNC x 1)

Audio 1CH audio input, 1CH audio output, 1CH built-in MIC

Alarm 1CH alarm input, 1CH alarm output

Storage Built-in micro SD card slot, up to 128GB

Hardware Reset Yes

Quick Start Guide 4MP H.265 IP IR Vandal Dome with 2.8-12mm Auto Focus Lens and Facial Recognition

Functions

Remote Monitoring Web browsing, CMS remote control

Online Connection Supports simultaneous monitoring for up to 10 users. Supports

multi-stream real time transmission

Network Protocol UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP,

SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS

Interface Protocol Onvif compatible

Intelligent Analytics

Line crossing

Region entrance / exiting /intrusion (human / motor vehicle

/ non-motor vehicle classiﬁcation)

Line crossing human / motor vehicle / non-motor vehicle

counting scene change

Video blur and video colour cast detection

Face recognition and face capture

Storage Network remote storage, Micro SD card storage

Smart Alarm Motion detection, Sensor detection, SD card error, SD card

full, IP conﬂict, cable disconnection

General Function Watermark, IP address ﬁltering, video mask, heartbeat,

password protection, image distortion correction, etc.

PoE Yes, IEEE802.3af

IR Distance 30~50m

Others

Ingress Protection IP67 & IK10

Power Supply DC12V / PoE

Power Consumption < 8W

Operating Environment - 30 °C ~ 60 °C (-22 °F~140°F)

Humidity: Less than 95 % (Non-Condensing)

Dimensions 141 × 100.2 mm

Weight Approx. 0.93 Kg

1. Ethernet Connector

2. Audio Input (MIC)

3. Audio Output (HP)

4. CVBS Video Output

5. Alarm Input/Output

6. DC12V Power Connector

7. A: Zoom- (only available for type A),

B: Focus

8. A : Zoom+ (only available for type A),

B: Zoom

9. Micro SD Card Slot

10. Reset

11. DC in & CVBS Interface

2.0 Overview

Security Cap

Type A : Motorised Zoom Camera

Type B : Manual Zoom Camera

DC12V

Alarm Input: Join the grounding ends of the sensor and the camera and then connect

the signal cable of the sensor to the alarm input port of the camera.

Alarm Output: Loosen the screws in the alarm output port. Then insert the signal wires

of the alarm output devices into the port of COM and OPEN separately. Finally tighten

the screws. Some of the external alarm output devices need the power supply.

• If the PoE switch is used to power the camera, DC12V power supply is not required.

• It is recommended to install the security cap for outdoor installation.

Quick Start Guide 4MP H.265 IP IR Vandal Dome with 2.8-12mm Auto Focus Lens and Facial Recognition

1. Loosen the nut from the main element.

2. Run the network cable (without RJ 45 connector) through both elements. Then crimp

the cable with RJ 45 connector.

3. Connect the cable to the hermetic connector. Then tighten the nut and the main

cover.

Connecting Network Cable

3.1 Installing the Camera

Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight

of the camera. Please install the camera in and under a dry environment and place the

cover of the camera within 4 hours of removing it. Do not remove the protection ﬁlm until

ﬁnishing the installation.

1. Rotate the trim ring anti-clockwise to remove it from the camera.

2. Attach the drill template to the place where you want to ﬁx the camera and then drill

4 screw holes and 1 cable hole (if you want to route the cables through the ceiling)

according to the drill template.

3. Loosen the screws to open the lower dome.

4. Route and connect these cables. Then secure the camera to the ceiling or wall with the

screws provided.

5. Three-axis adjustment. Before adjustment, preview the image of the camera on a

monitor and then adjust the camera according to the ﬁgure below to get an optimum

angle.

3.0 Installation

Trim Ring

Lower Dome

Rubber Plug

Install it when routing the

cables through the ceiling.

Pan 0–345°

Tilt 0–77°

Rotation 0–345°

Hold it and rotate

Quick Start Guide 4MP H.265 IP IR Vandal Dome with 2.8-12mm Auto Focus Lens and Facial Recognition

6. Insert a micro SD card. After that, adjust Zoom or Focus to obtain an optimum image.

Before adjustment, view the image of the camera on a monitor. For Type A, press the T

or W button. For Type B, (a) push the IR light hood to the position, (b) remove the lens

cover, (c) adjust the Zoom and Focus, (d) install back the lens cover and move the IR

light hood back.

7. Install the lower dome back to the camera and ﬁx it with screws. Then put the trim ring

onto the lower dome and then rotate it clockwise until it is locked. Finally, remove the

protection ﬁlm softly.

3.2 Installing the Camera with a Junction Box

1. Fix the junction box to the wall with screws.

2. Rotate the trim ring anticlockwise to remove it from the camera and then loosen the

screws to open the lower dome.

3. Route and connect these cables (take side conduit cabling for example). Then fasten

the camera to the junction box with screws.

4. Insert a micro SD card. Then

adjust the view of angle and the

image.

5. Install the lower dome back to the camera and ﬁx it with screws. Then put the trim ring

onto the lower dome and then rotate it clockwise until it is locked. Finally, remove the

protection ﬁlm softly.

Lens Cover

Focus

Monitor

Zoom

Zoom-

Zoom+ IR Light Hood

Insert a Micro

SD card

Type A : Motorised Zoom Camera Type B : Manual Zoom Camera
