Genie WIP2BVLG Manual de usuario
Quick Start Guide
Please read these instructions carefully before operating the unit
and keep for further reference.
2MP IP Lite IR Varifocal Bullet
Camera with 2.8-12mm Lens
WIP2BVLG
ii
Intro Section
Please read this instruction carefully before operating the product and keep it for further
reference. All examples and pictures used here are for reference only.
The contents of this manual are subject to change without notice.
CAUTION:
• If the product does not work properly, please contact your dealer or the nearest service
centre. Never attempt to disassemble the camera yourself. We shall not be responsible
for any problems caused by unauthorised repair or maintenance.
• Do not allow water or liquid into the camera while in use.
• When using the product, you must be in strict compliance with the electrical safety
regulations of the nation and region.
• When the product is mounted on wall or ceiling, the device needs to be firmly fixed.
• Make sure the power supply voltage is correct before using the camera.
• Do not drop the camera or subject it to any physical shock.
• If cleaning, please use a clean soft cloth with a little neutral detergent to wipe it gently.
• Do not aim the camera at the sun or in any area where there is bright lighting.
• The device may be burned out by a laser beam, so when any laser equipment is in use,
make sure that the surface of the device will not be exposed to the laser beam.
• Do not place the camera in extremely hot, cold , dusty or damp locations, and do not
expose it to high electromagnetic radiation.
• To avoid heat accumulation, good ventilation is required for operating environment.
Contents
iii
1.0 Introduction..........................................................................................................4
1.1 Product Features...........................................................................................4
1.2 Product Dimensions.....................................................................................4
1.3 Contents ......................................................................................................4
1.4 Specification ................................................................................................5
2.0 Overview..............................................................................................................6
3.0 Installation............................................................................................................7
4.0 Network Connection ...........................................................................................9
4
The Genie WIP2BVLG is an IP IR varifocal bullet camera with a 2.8–12mm lens and 20-
30m IR distance in ideal conditions. The camera has 1080p full real time coding as well as
remote monitoring in a grey finish.
1.1 Product Features
• 1080p full real time coding
• 20–30m IR distance (In ideal conditions)
• 2.8–12mm megapixel lens
• 3D DNR
• Digital WDR
• True day / night
• MIC / Line in G.711A / U Audio Codec
• IP and MAC address filtering
• Configuration backup
• Alarm image size dependent on set stream resolution
• RTSP streaming with or without authentication
• Mirror and flip image
• Multiple privacy masking
• Remote monitoring
• Supports smart phones and tablets
1.2 Product Dimensions
1.3 Contents
1.0 Introduction
284mm 109mm
Camera Quick Start Guide 4 Tapping Screws PA 4×25
1 Machine Screw PWM3×5
CD Drill Template Plastic Plug x4 L-Wrench
Rubber Plug
Quick Start Guide 2MP IP Lite IR Varifocal Bullet Camera with 2.8-12mm Lens
5
1.4 Specification
Camera
Image Sensor 1/3” CMOS
Image Size 1920 × 1080
Electronic Shutter 1/25s ~ 1/100,000s
Effective Pixels 752 (H) x 582 (V)
Minimum Illumination 0 Lux (IR LED On)
Lens 2.8 ~ 12mm
Video Format PAL / NTSC
Wide Dynamic Range Yes
3D DNR Yes
Video Compression H.264
Resolution 1080p (1920 × 1080), 720p (1280 × 720), VGA (640 × 480),
QVGA (320 × 240)
Multi-Stream
1920 × 1080 (1–30fps), 1280 × 720 (1–30fps),
1280 × 720 (1–10fps), 640 × 480 (1–30fps),
320 × 240 (1–30fps)
Bit Rate 64Kbps ~ 4Mbps
Encode Mode VBR / CBR
Audio Compression G711A
Quality Five levels under VBR, Freely
adjustable under CBR
Image Settings
Saturation, Brightness, Contrast, etc
(Adjustable through client software or
web browser)
Functions
Remote Monitoring IE browsing, CMS remote control
Online Connection
Supports simultaneous monitoring for
up to 4 Users. Supports multi-stream
real time transmission
Protocol TCP/IP, UDP, DHCP, NTP, RTSP, PPPoE,
DDNS, SMTP, FTP
Day & Night ICR
Smart Alarm Motion alarm
IR Distance Up to 25m (In ideal conditions)
Interface Network RJ45
Audio One way audio (MIC in x1)
Others
Ingress Protection IP66
Power Supply DC12V / PoE
Operating Environment Temperature: -40°C ~ 50°C,
Humidity: 10% ~ 90%
Dimensions 109 × 284 mm
Weight 1115g
6
1. Sunshield
2. Bracket
3. Mounting Base
2.0 Overview
Security Cap
DC12V
It is recommended to install the security cap for outdoor installation.
If the PoE switch is used, the DC12V power supply is not required.
4. Network Cable
5. MIC In Cable
6. Power Cable
1. Loosen the nut from the main element.
2. Run the network cable (without RJ 45 connector) through both elements. Then crimp
the cable with RJ 45 connector.
3. Connect the cable to the hermetic connector. Then tighten the nut and the main
cover.
Connecting Network Cable
7
Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight
of the camera. Please install the camera in and under a dry environment and place the
cover of the camera within 4 hours of removing it.
1. Drill the screw holes and the cable hole (if you want to route through the ceiling) on the
wall or ceiling according to the drill template.
2. Route and connect the cables.
3. Secure the mounting base with camera to the wall with the screws provided.
4. Bracket adjustment. Before adjustment, preview the image of the camera on a monitor
and then loosen the fixed screws to adjust the view angle of the camera.
3.0 Installation
Rubber Plug
Fixed Screws
360° Pan
90° Tilt
360° Rotation
Quick Start Guide 2MP IP Lite IR Varifocal Bullet Camera with 2.8-12mm Lens
8
5. Focus and zoom adjustment (If the model you get is prime lens, please skip this step).
Remove the lens cover and then adjust the focus and zoom screws to get a clear
image. Finally, tighten these two screws and the lens cover.
6. Remove the protection film softly to finish the installation.
Lens Cover
Zoom
Focus
9
Access the Camera through the IP Tool
1. Make sure that the camera and the PC are well connected via LAN.
2. Find the IP-Tool from the CD and then install it in the computer. After that, run the IP
Tool as shown below.
3. Modify the IP address. The default IP address of this camera is 192.168.226.201. Click the
information of the camera listed in the above table to show the network information
on the right hand. Modify the IP address and gateway of the camera and make sure its
network address is in the same local network segment as that of the computer. Please
modify the IP address of your device according to the practical situation.
4. Double-click the camera listed in the IP-Tool or manually enter the IP address in
the address bar of the web browser to connect IP-CAM. Then follow directions to
download and install the plugin. Enter the username and password in the login
interface. The default username is admin; the default password is 123456.
4.0 Network Connection
For example, the IP address of your computer is 192.168.1.4. So the IP address of the
camera shall be changed to 192.168.1.X and the gateway shall be changed to 192.168.1.1.
After modification, please enter the password of the administrator and click “Modify”
button to modify the settings. The default password of the administrator is “123456”.
Quick Start Guide 2MP IP Lite IR Varifocal Bullet Camera with 2.8-12mm Lens
10
Direct Access Through IE
The default network settings are as shown below:
IP address: 192.168.226.201
Subnet Mask: 255.255.255.0
Gateway: 192.168.226.1
HTTP: 80
Data Port: 9008
You can use the above default settings when you log into the camera for the first time.
1. Set the IP address of the PC and make sure the network segment should be as the
same as the default settings of IP-CAM. Open the network and share center. Click
“Local Area Connection” to pop up the following window. Select “Properties” and then
select Internet protocol according to the actual situation (for example: IPv4). Next, click
“Properties” button to set the network of the PC.
2. Open the IE browser and input the default address of IP-CAM and confirm. The IE
browser will download Active X control automatically.
3. After the Active X control is downloaded, the login dialog box will pop up.
4. Input the default username and password and then enter to view.
