Gefen EXT-DP-CAT7 Manual de usuario
®
DisplayPort
Extender
over CAT-7
EXT-DP-CAT7
User Manual
www.gefen.com
ASKING FOR ASSISTANCE
Rev A2
Technical Support:
Telephone (818)772-9100
(800)545-6900
Fax (818)772-9120
Technical Support Hours:
8:00AMto5:00PMMondaythroughFriday,PacicTime
Write To:
Gefen,LLC.
c/oCustomerService
20600NordhoffSt
Chatsworth,CA91311
www.gefen.com
Notice
Gefen,LLCreservestherighttomakechangesinthehardware,packaging,andany
accompanyingdocumentationwithoutpriorwrittennotice.
DisplayPort Extender over CAT-7 isatrademarkofGefen,LLC
©2013Gefen,LLC.Allrightsreserved.
Alltrademarksarethepropertyoftheirrespectiveowners.
CONTENTS
INTRODUCTION....................................................................................................................1
OperatingNotes..............................................................................................................2
Features..........................................................................................................................3
PackageIncludes............................................................................................................3
SenderUnitLayout.........................................................................................................4
SenderUnitDescriptions................................................................................................5
ReceiverUnitLayout.......................................................................................................6
ReceiverUnitDescriptions..............................................................................................7
CONNECTING THE DISPLAYPORT EXTENDER OVER CAT-7...........................................8
Connections....................................................................................................................8
WiringDiagram...............................................................................................................8
OPERATING THE DISPLAYPORT EXTENDER OVER CAT-7..............................................9
LEDIndicators................................................................................................................9
DIPSwitchConguration..............................................................................................10
HPDButton...................................................................................................................11
AdjustingtheSignalQuality..........................................................................................12
CABLE TERMINATION........................................................................................................13
SURFACE MOUNTING INSTRUCTIONS............................................................................14
SPECIFICATIONS................................................................................................................15
WARRANTY..........................................................................................................................16
1
INTRODUCTION
CongratulationsonyourpurchaseoftheDisplayPortExtenderoverCAT-7.Yourcomplete
satisfactionisveryimportanttous.
About Gefen
Wespecializeintotalintegrationforyourhometheater,whilealsofocusingongoingabove
andbeyondcustomerexpectationstoensureyougetthemostfromyourhardware.We
inviteyoutoexploreourdistinctproductline.Pleasevisithttp://www.gefen.comforthe
latestofferingsinHigh-Denitionsignalsolutionsorcallusbetweenthehoursof8:00am
and5:00pmMonday-Friday,PacicStandardTimeforassistancewithyourA/Vneeds.
We’llbehappytoassistyou.
The Gefen DisplayPort Extender over CAT-7
TheDisplayPortExtenderoverCAT-7allowstheinstallationofaHDTVdisplayupto100
feet(30meters)awayfromaDisplayPortsourceusingtwoCAT-7cables.Resolutionsup
to1920x1200(WUXGA)or1080pFullHDwhenusingasingleCAT-7cable,andupto
2560x1600(WQXGA)whenusingtwocables,canbesupported.TheReceiverunitis
poweredbytherstCAT-7cablethatextendstheDisplayPortsignalfromtheSenderunit,
eliminatingtheneedforanexternalpowersupplyontheReceiverunit.
How It Works
ConnecttheSenderunittotheDisplayPortsourceusingtheincludedDisplayPortcable.
ConnecttheReceiverunittotheHDTVdisplayusinganotherDisplayPortcable.
ConnecttheSenderunittotheReceiverunitusingoneortwoCAT-7cables,depending
onthemaximumrequiredvideoresolution.Connecttheincludedlockingpowersupplyto
theSenderunitandanavailableelectricoutlet.TheReceiverunitispoweredbytheLink
1CAT-7cableanddoesnotrequireanexternalpowersupply.Turnonthepowertothe
sourceandthedisplay.
2
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE DISPLAYPORT EXTENDER OVER CAT-7
• CAT-7cablesshouldnotexceed100feet(30meters).
• Resolutionsupto1920x1200(WUXGA)or1080pFullHDaresupported
whenusingasingleCAT-7cable.TwoCAT-7cablesmustbeusedtosupport
2560x1600(WQXGA).
INTRODUCTION
INTRODUCTION
3
Features
• ExtendsDisplayPortupto100feet(30meters)
• Supportsresolutionsupto2560x1600overtwoCAT-7cables,andupto
1920x1200or1080pFullHDoveroneCAT-7cable
• SupportsDisplayPort1.1a
• 16-positionEQrotaryswitchtocompensateforcableskew
• HPDAuto-Calibrationbutton
• Pre-emphasisswitch
• Drivelevelswitch
• Boostlevelswitches
• PowerOnandLinkindicators
• Lockingpowersupply
• Surface-mountable
Package Includes
• (1)DisplayPortExtenderoverCAT-7(Senderunit)
• (1)DisplayPortExtenderoverCAT-7(Receiverunit)
• (1)6ft.DisplayPortcable(M-M)
• (1)5VDCpowersupply
• (1)QuickStartGuide
Sender Unit Layout
4
INTRODUCTION
1
4 5
31 2
Back
Front
Top
Sender Unit Descriptions
1 5VDC
Connecttheincluded5VDClockingpowersupplytothisconnectorandplugtheAC
powercordintoanavailableelectricaloutlet.Onlyusethepowersupplyshippedwith
thisunit.
2 DPIn
ConnectaHi-DefsourcetothisportusingaDisplayPortcable.
3 Power
ThisLEDindicatorwillglowbrightbluewhentheunitispowered.
4 Link1
ConnectaCAT-7cableupto100feet(30meters)fromthisjacktotheLink1jack
ontheReceiverunit.
5 Link2
ConnectaCAT-7cableupto100feet(30meters)fromthisjacktotheLink2jack
ontheReceiverunit.
5
INTRODUCTION
6
INTRODUCTION
Receiver Unit Layout
5 6
3 41 2
Back
Front
Top
