Gefen EXT-DVIKVM-ELR Manual de usuario
®
DVIKVM
Extra Long Range
Extender
Over One CAT5
EXT-DVIKVM-ELR
User Manual
www.gefen.com
ASKING FOR ASSISTANCE
Rev A1
29.81
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
Notice
Gefen LLC reserves the right to make changes in the hardware, packaging and
any accompanying documentation without prior written notice.
DVIKVM Extra Long Range Extender Over One CAT5
is a trademark of Gefen LLC
© 2011 Gefen LLC, All Rights Reserved.
All trademarks are the property of their respective owners.
CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Sender Unit Layout
5 Sender Unit Descriptions
6 Receiver Unit Layout
7 Receiver Unit Descriptions
8 Connecting the DVIKVM Extra Long Range Extender Over One CAT5
8 Wiring Diagram
9 DIP Switch Configuration
11 Network Cable Wiring Diagram
12 Rack Tray Installation
13 Troubleshooting
14 Glossary
21 Specifications
22 Warranty
1
Congratulations on your purchase of the Gefen DVIKVM Extra Long Range Ex-
tender Over One CAT5. Your complete satisfaction is very important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions
that harness integration, extension, distribution and conversion technologies.
Gefen’s reliable, plug-and-play products supplement cross-platform computer
systems, professional audio/video environments and HDTV systems of all sizes
with hard-working solutions that are easy to install and simple to operate.
The Gefen DVIKVM Extra Long Range Extender Over One CAT5
The DVIKVM Extra Long Range Extender Over One CAT5 extends any DVI and
USB source to a monitor, touch screen display, or other digital signage applica-
tion over a distance up to 330 feet (100 meters) using one Cat-5 cable. USB 2.0
data rates up to 100 Mbps are supported in addition to backward-compatibility
with USB 1.1. The Receiver Unit allows the connections of up to three (3) USB
devices, providing access to printers, scanners, cameras, external storage me-
dia, digital signage, and automated control systems. This product uses Gefen
ELR technology, allowing DVI and USB signals to travel along the same Cat-5
cable, reducing cabling costs and providing easier installation.
How It Works
Place the DVIKVM Extra Long Range Extender Over One CAT5 Sender Unit next
to the DVI source. Use the included DVI cable to connect the computer or other
DVI source to the Sender Unit. Use the supplied USB cable to connect the USB
host (source) device to the USB port on the Sender Unit. Connect the Receiver
Unit to the monitor or digital signage display with a DVI cable. Connect the USB
devices to the Receiver Unit. Use one Cat-5 cable, up to 330 feet (100 meters),
to connect the Sender Unit to the Receiver Unit. Connect the included locking
power supplies to the Sender Unit and Receiver Unit, and then connect both
power cords to available electrical outlets.
INTRODUCTION
2
OPERATION NOTES
PLEASE READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE DVIKVM EXTRA LONG RANGE EXTENDER OVER
ONE CAT5
• Cat-5 or Cat-6 cables should not exceed 330 feet (100 meters).
• Shielded (STP) Cat-5 or Cat-6 is recommended. However, un-shielded
(UTP) Cat-5 or Cat-6 is acceptable.
NOTE: The shielded cable has an advantage by providing immunity to
Electromagnetic Interference (EMI), cell phones and A/C motors.
• The Gefen DVIKVM Extra Long Range Extender Over One CAT5 features
the ability to generate compatible EDID and Hot Plug signals when working
with different brands of source devices and monitors.
• This product supports HDCP with HDMI sources.
• Dual-link resolutions are not supported.
3
FEATURES
Features
• Supports DVI resolutions up to 1920x1200 @ 60 Hz or 1080p at 330 feet
(100 meters)
• Extends USB 2.0 up to 330 feet (100 meters)
• Digital signal transmission over Cat-5 cable for zero signal loss
• Supports USB 2.0
• Backward-compatible with USB 1.1 devices
• Field Upgradeable via USB mini-jack
• Works with PC and Mac computers
• Locking Power Supplies
• Rack-mountable
Applications
• Ideal for digital signage applications
• Extension of KVM workstations
Package Includes
(1) Gefen DVIKVM Extra Long Range Extender Over One CAT5 - Sender Unit
(1) Gefen DVIKVM Extra Long Range Extender Over One CAT5 - Receiver Unit
(1) 6 ft. DVI Cable (M-M)
(1) 6 ft. USB cable (A-B)
(2) 5V DC Locking Power Supplies
(1) Set of rack ears
(1) User Manual
4
SENDER UNIT LAYOUT
Back
Front
2 3 41
6 7 8 95
5
SENDER UNIT DESCRIPTIONS
1 Power Indicator
This LED will turn bright blue once the included 5V DC locking power supply
has been properly connected to the unit and the locking power supply has been
connected to an available electrical outlet.
2 Link Indicator
This LED glows bright blue when the Sender Unit and Receiver Unit are
connected using Cat-5 / Cat-6 cable.
3 USB Indicator
This LED glows bright blue when a USB source is connected to the Sender Unt.
4 DVI Indicator
This LED flashes on (bright blue) and off when a DVI video source is connected
to the Sender Unit. The Sender Unit and Receiver Unit must also be connected
using a Cat-5 / Cat-6 cable.
5 Service Port
Mini-USB service port used for upgrading the firmware.
6 Link
Connects the Sender Unit to the Receiver Unit using Cat-5 / Cat-6 cable.
7 DVI In
Connect a DVI cable from the computer to this DVI-I connector.
8 USB In
Connects the Sender Unit to the network using an Ethernet cable.
9 5 V DC Locking Power Connector
Connect the included 5 V DC locking power supply to this connector.
6
RECEIVER UNIT LAYOUT
Back
Front
2 3 41
5 6 7 8 9
7
RECEIVER UNIT DESCRIPTIONS
1 Power Indicator
This LED will turn bright blue once the included 5V DC locking power supply
has been properly connected to the unit and the locking power supply has been
connected to an available electrical outlet.
2 Link Indicator
This LED glows bright blue when the Sender Unit and Receiver Unit are
connected using Cat-5 / Cat-6 cable.
3 USB Indicator
This LED glows bright blue when a USB source is connected to the Receiver
Unt.
4 DVI Indicator
This LED flashes on (bright blue) and off when a DVI display is connected to
the Receiver Unit. The Sender Unit and Receiver Unit must also be connected
using a Cat-5 / Cat-6 cable.
5 Service Port
Mini-USB service port used for upgrading the firmware.
6 Link
Connects the Receiver Unit to the Sender Unit using Cat-5 / Cat-6 cable.
7 DVI Out
Connect a DVI display to this DVI-I connector.
8 USB Input Ports (1 - 3)
Connect USB devices to these ports.
9 5 V DC Locking Power Connector
Connect the included 5 V DC locking power supply to this connector.
