BA300

Battery Alarm

Commissioning Instructions

For use with Substation and Telecontrol Batteries

Publication reference: BA300/EN/CI/GE

Commissioning Instructions

Battery Alarm 300

for use with Substation and

Telecontrol Batteries

HANDLING OF ELECTRONIC EQUIPMENT

A person's normal movements can easily generate electrostatic potentials of several thousand

volts. Discharge of these voltages into semiconductor deviceswhen handling electronic circuits

can cause serious damage, which often may not be immediately apparent but the reliability of the

circuit will have been reduced.

The electronic circuits of General Electric products are immune to the relevant levels of

electrostatic discharge when housed in their cases. Do not expose them to the risk of damage by

withdrawing modules unnecessarily.

Each module incorporates the highest practicable protection for its semiconductor devices.

However, if it becomes necessary to withdraw a module, the following precautions should be

taken to preserve the high reliability and long life for which the equipment has been designed and

manufactured.

1. Before removing a module, ensure that you are at the same electrostatic potential as the

equipment by touching the case.

2. Handle the module by its front-plate, frame, or edges of the printed circuit board. Avoid

touching the electronic components, printed circuit track or connectors.

3. Do not pass the module to any person without first ensuring that you are both at the

same electrostatic potential. Shaking hands achieves equipotential.

4. Place the module on an antistatic surface, or on a conducting surface which is at the

same potential as you.

5. Store or transport the module in a conductive bag.

More information on safe working procedures for all electronic equipment can be found in

BS5783 and IEC 60147-0F.

If you are making measurements on the internal electronic circuitry of equipment in service, it is

preferable that you are earthed to the case with a conductive wrist strap.

Wrist straps should have a resistance to ground between 500k – 10M ohms. If a wrist strap is not

available, you should maintain regular contact with the case to prevent the build up of static.

Instrumentation which may be used for making measurements should be earthed to the case

whenever possible.

General Electric strongly recommends that detailed investigations on the electronic circuitry, or

modification work, should be carried out in a Special Handling Area such as described in

BS5783 or IEC 60147-0F.

Page 4

SAFETY SECTION

This Safety Section should be read before commencing any work on the

equipment.

Health and safety

The information in the Safety Section of this manual is intended to ensure that

products are properly installed and handled in order to maintain them in a safe

condition. It is assumed that everyone who will be associated with the equipment

will be familiar with the contents of the Safety Section.

Explanation of symbols and labels

The meaning of symbols and labels which may be used on the equipment or in the

product documentation, is given below.

Caution: refer to product documentation Caution: risk of electric shock

Protective/safety *earth terminal

Functional *earth terminal. Note: this symbol may also be

used for a protective/safety earth terminal if that terminal is

part of a terminal block or sub assembly eg. power supply.

*Note: The term earth used throughout the product documentation is the direct

equivalent of the North American term ‘ground’.

Installing, Commissioning and Servicing

Equipment connections

Personnel undertaking installation, commissioning or servicing work on this

equipment should be aware of the correct working procedures to ensure safety.

The product documentation should be consulted before installing, commissioning

or servicing the equipment.

Terminals exposed during installation, commissioning and maintenance may

present a hazardous live voltage unless the equipment is electrically isolated.

If there is unlocked access to the rear of the equipment, care should be taken by

all personnel to avoid electric shock or energy hazards.

Voltage and output connections should be made using insulated crimp terminations

to ensure that terminal block insulation requirements are maintained for safety.

To ensure that wires are correctly terminated, the correct crimp terminal and tool

for the wire size should be used.

Before energising the equipment it must be earthed using the protective earth

terminal. The recommended minimum earth wire size is 1.0 mm2.Omitting or

disconnecting the equipment earth may cause a safety hazard.

Page 5

Before energising the equipment, the following should be checked:

Voltage rating and polarity;

Protective fuse rating;

Integrity of earth connection

Equipment operating conditions

The equipment should be operated within the specified electrical and

environmental limits.

Insulation and dielectric strength testing

Insulation testing may leave capacitors charged up to a hazardous voltage.

At the end of each part of the test, the voltage should be gradually reduced to

zero, to discharge capacitors, before the test leads are disconnected.

Disposal

It is recommended that incineration and disposal to water courses is avoided.

The product should be disposed of in a safe manner.

Technical Specifications

Protective fuse rating

The recommended maximum rating of the external protective fuse for this

equipment is 2A, Red Spot type or equivalent.

Insulation class: IEC 61010-1: 1990/A2: 1995 This equipment requires a

Class I protective (safety) earth

EN 61010-1: 1993/A2: 1995 connection to ensure user

Class I safety.

Installation IEC 61010-1: 1990/A2: 1995 Distribution level, fixed

Category Category III installation. Equipment in

(Overvoltage): EN 61010-1: 1993/A2: 1995 this category is qualification

Category III tested at 5kV peak,

1.2 50µs, 500Ω, 0.5J,

between all supply circuits

and earth and also

between independent

circuits.

Environment: IEC 61010-1: 1990/A2: 1995 Compliance is

Pollution degree 2 demonstrated by reference

EN 61010-1: 1993/A2: 1995 to generic safety standards.

Pollution degree 2

Product safety: 73/23/EEC Compliance with the

European Commission

Low Voltage Directive.

EN 61010-1: 1993/A2: 1995 Compliance is

EN 60950: 1992/A11: 1997 demonstrated by reference

to generic safety standards.

Page 6

Applications

For situations where batteries are located in unmanned substations it is important that the

security of the supply is maintained. This means, not only that the battery voltage is within

required limits, but that Earth Leakage is minimised and any latent faults in the battery and its

connections will not result in failure to initiate tripping when a heavy current is demanded.

The Battery Alarm is suitable for use on all batteries with an impedance exceeding 0.1Ω.

Connections

Figure 1 below shows how the Battery Alarm should be included in the system. The Battery

Alarm positive and Battery Alarm negative leads should be connected as near to the battery

terminals as possible via 2A rated fuses.

For safety reasons, the earth terminal must be connected to earth. If either the positive or

negative of the battery is earthed, the standard Battery Alarm 300 will indicate an earth fault

alarm. In the case when an earth relay is already fitted, a Battery Alarm 300 model without

earth fault is recommended.

Test Method for Battery Alarm

The unit can be tested using the equipment shown in Figure 2. With this set-up, carry out the

following tests:

WARNINGS

i) E(GND) is not connected to earth for this test. The metal backplate will be

at half the battery voltage, current limited to 5mA.

ii) Ensure that the 220µF capacitor is safely discharged using a suitable

resistor.

Figure 1: External Wiring Diagram

Non-urgent

Urgent

To telemetry

2A Busbars to

battery loads

Battery

Charger

Optional

choke FS1

2A FS2

Note: The Battery Alarm is shown in the energised state. Under healthy operating

conditions, the urgent relay is operated and the non-urgent relay is released.

Page 7

1. Power Supply

Set the power supply voltage mid way between the two voltage trip settings.

Check the current indicated on the milliammeter (3) is approximately 20mA.

NB: Replace the milliammeter (3) with a link for the following tests.

2. Over Voltage Trip

Slowly increase the voltage until the over voltage alarm LED lights.

3. Over Voltage Reset

Slowly reduce the voltage until the over voltage alarm

LED extinguishes

4. Under Voltage Trip

Slowly reduce the voltage until the under voltage alarm LED lights.

5. Under Voltage Reset

Slowly increase the voltage until the under voltage alarm LED extinguishes

6. Cut-off Facility

For units with cut-off facility, slowly increase the supply voltage until the over voltage LED

lights and check that the cut-off relay alarm trips after the specified time delay.

7. Timer

Increase the voltage to a value above the over voltage trip point. Note the time between

the over voltage alarm LED coming on and the output relay alarm tripping.

8. High Impedance

Set the power supply voltage midway between the two voltage trip points. Increase the

series resistance (5) from zero until the high impedance LED comes on.

NB: Reset the series resistance to zero.

9. Earth Fault, Positive (Negative)

Connect point A to the positive (negative) terminal of the alarm. Slowly decrease the

resistor (10) from 100kΩuntil the positive (negative) EARTH FAULT LED lights.

The earth fault current is proportional to the reading on the voltmeter (9). The total

resistance (8) + (10) should be specified value ±10%.

10. Output Contacts

The correct operation of the relay contacts can be checked using a battery operated test

lamp or buzzer.

A version with both relays designated as non-urgent is also available: Refer either to the

connection label or the Operating and Maintenance manual for relay connections.

Page 8

Key

1. Variable dc power supply, 0–1A output.

Output impedance less than 0.2Ω

2. Capacitor 220µF, 400V (required if power supply output impedance is greater than

0.2Ω)

3. Low impedance milliammeter, to indicate 20mA dc

4. Voltmeter (10,000Ω/V or better)

5. Variable resistance, 0–5Ωin 0.1Ωincrements

6. Battery

7. Bulb or buzzer to suit (6)

8. 1kΩprecision resistor

9. 0–1V voltmeter

10. Variable resistor 0–100kΩ(increments of 100Ω)

Application note

Battery charger systems with an inductive output element only, should have a suitable load

connected, such as a battery, during commissioning and normal operation.

This is to avoid resonance of the output inductor with the system capacitance which may

produce damaging high peak output voltages.

For use with inductor only filtered chargers, a small standing drain will be required on the

battery busbars so that a high resistance alarm is given for a completely open circuit battery,

eg. typical drain of 0.3A for a 110V system.

498

E(GND)

Figure 2: Connection diagram for Battery Alarm test sequence

Page 9

For battery charger systems with capacitor filtered outputs, the Battery Alarm requires a

choke of ≥2mH to be fitted at the output of the battery charger to ensure correct operation of

the high impedance alarm (see Figure 1).

In normal operation, the non-urgent (earth fault or high volts cut-off) relay is de-energised and

the urgent relay is energised, thus providing a ‘fail to safety’ feature.

If the supply voltage falls below 66% nominal for longer than 50 milliseconds, an

instantaneous urgent alarm is given. When the supply voltage returns to above 66% nominal

a ‘power on reset’ occurs after a time delay of 1 second.

Operation

The Battery Alarm derives its power supply from the battery being monitored. The current

consumption is approximately 20mA. Four monitoring functions are provided:

A. Earth fault alarm (positive and negative).

B. Over voltage alarm.

C. Under voltage alarm.

D. High battery impedance alarm.

A common configuration for alarm relay outputs is routing functions B, C and D via a timer

circuit to the urgent relay.

Six LED indicators are provided for diagnostic purposes and under normal healthy conditions

only the one monitoring the power supply is lit.

The LEDs for all four functions listed above will light instantaneously when a fault is detected

and the urgent and non-urgent alarm relays will trip after their preset time delays.

Commissioning

Battery Alarms are available calibrated for other battery voltages between 24V and 220V.

They are designed for flush panel mounting in a cut-out measuring 92mm square (+0.8, –0),

and secured in position with the clamps provided. Before connecting up, ensure that the unit

supplied is suitably rated for the battery installation to be monitored, otherwise damage

could be sustained. Connect the + and – terminals and also connect the E terminal to earth.

Connect the output contacts to the telemetry or other alarm annunciators as required.

After carefully removing the small access window, the front-mounted potentiometers can be

adjusted as follows:

1. High Impedance

Rotate this control anticlockwise until the associated LED is lit, then slowly rotate

clockwise until the LED is just extinguished. This gives maximum sensitivity. Further

clockwise rotation increases the trip impedance.

2. Over Voltage – preset at factory.*

3. Under Voltage – preset at factory.*

* A limited amount of adjustment is possible to suit a particular installation but an

injection test is preferred (apply to factory for details).

Page 10

Technical Specifications

Battery Voltage Ranges

Battery voltages (VB) 24V, 30V, 32V, 48V, 50V, 60V,

110V, 125V, 220V.

Operating Range 80…140%VB

Burden 20mA nominal

Voltage alarm levels (adjustable)

Under voltage range 80…110%VB

Over voltage range 105…140%VB

Accuracy of setting ±0.5%

Hysteresis on setting 0.5%

Earth leakage protection (preset)

Trip level range 5kΩto 90kΩ

Accuracy of trip level ±10%

Hysteresis on trip level 5%

Short circuit current <5mA

High impedance alarm (adjustable)

Setting range 0.1Ω…5.0Ω

Accuracy of setting ±0.05Ω

Hysteresis on setting 0.05Ω

Temperature

Nominal range of use –20°…+60°C

Reference temperature 23°C

Temperature coefficient

Voltage alarms ±0.006%/°C

Earth leakage alarm ±0.06%/°C

Timer settings ±0.06%/°C

High impedance alarm <0.1Ωdeviation in setting over

temperature range

Tabla de contenidos

Otros manuales de Sistema de seguridad de GE

GE NX-108E - Security NetworX NX-4 System Manual de usuario

GE Interlogix 60-875 Simon Manual de usuario

GE AL-1291 Point ID Manual de usuario

GE Concord express Guía

GE Allegro 60-874-95R Manual de usuario

GE 8RP Board Instrucciones de montaje

GE Security Pro 500 Manual de usuario

GE Simon XT V2 Manual de usuario

GE AS272 Manual de usuario

GE Choice-Alert 45136 Manual de usuario

GE SuperBus 2000 Manual de usuario

GE CareGard Manual de usuario

GE Concord 4 Manual de instrucciones

GE 45236 Manual de usuario

GE SIMON XT Manual de usuario

GE Concord 4 Manual de usuario

GE ARITECH AS399 Manual de usuario

GE 51209 Manual de usuario

GE 60-806-95R-16Z - Security Concord Express System Control... Manual de usuario

GE Supra KeySafe Manual de usuario

GE SIMON XT Manual de usuario

GE Concord Manual de usuario

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario
