Thank you for purchasing the fi-5900C Image Scanner.

The fi-5900C is an image scanner designed to scan various documents in large quantities.

The fi-5900C has the following features.

 Improvement of color scanning speed (100 sheets or 200 pages

per minute) with high resolution (300dpi)

By the newly-developed high speed CCD and high speed image processing circuit,

scanning speed (A4 color, 300dpi) of 100 sheets/200 pages per minute) is improved.

Now you can scan a large amount of documents which is about 100,000 sheets a day!

 Efficient pre-processing and post-processing!

This scanner is able to scan mixed documents stables of papers of different color,

density, size and thickness. This makes the scanning process even simpler and

economic, since you no not have to sort out the documents before scanning any more!

Furthermore, this scanner is equipped with an "Elevator" Stacker, moving

automatically into the appropriate height, according to the amount of loaded

documents. This will make the documents be easily and elegantly handled and also

increases your scanning efficiency!

 Prevention of data loss because of improved multi feed detection

This scanner is equipped with ultrasonic multi feed detection sensors, which detect

reliably the feeding of 2 or more documents together into the scanner. Those multi

feed can also be detected surely, when scanning documents of different thickness,

size, color or density. This will help you to increase your efficiency, since the data loss

caused by multi feed is detected immediately. This gives you the opportunity to

correct the scanning without too much troubles and loss of time.

 High image processing function

The automatic detection function of this scanner is able to detect if the loaded

documents are color or monochrome and according to the detection the appropriate

settings will be automatically chosen for the image creation. Since the scanner does

this automatically, you do not have to set the image settings each time before

scanning. Furthermore, The Kofax VRS image processing board is installed as

standard equipment for this scanner. This VRS board which has a good reputation for

image processing on a high level, enables you to create images of high quality and

provides advanced functions like the "Automatic direction correction" and

"Background equalization function".

 Pre- and Post imprinter option can be installed

In today's document business, imprinters provide a vital tool for archiving, controlling

and verification processes. For this scanner, you can select two optional types of

imprinters, depending on your needs. The Pre-Imprinter Option prints information on

the front side of the documents prior to the scanning. When using Pre-imprinter, the

printed information will also be stored on the generated image. The Post-Imprinter on

the other hand, will print after the scanning on the back sides of your documents. So

only the originals, and not the images, will contain the imprint.
