Front Runner LASS026 Manual de usuario

LASS026

ENG

universal Load Bed

legs 188mm (PaiR)

Thank you for purchasing a Front Runner Universal Load Bed Legs.

Before you start, take a moment to familiarize yourself with the Fitting Instructions and the components received.

Refer to Page 2 for a list of all the components, quantities and tools required.

READ ME !

IMPORTANT WARNING!

IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD

RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT

RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND

DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO

INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY

FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.

Please call us if you have any questions about the installation of this product.

LASS026_REV_A02

TOOLS NEEDED

1 2 X Leg

2 4 X M8 x 25 Button Head Bolt

3 4 X M8 Spring Washer

4 4 X M8 x 19 x 2SS Flat Washer

5 4 X M8 Channel Nut

6 4 X M8 Nut Cap

7 4 X M8 Nyloc Nut

8 4 X M8 x 16 x 1.6SS Flat Washer

9 4 X M8 x 25 Hex Bolt

IN THE BOX

FIGURE 1.1

5mm

GET ORGANIZED

13mm

LASS026_REV_A02

FIT AND SECURE

13mm

2.1

2.2

Loosely assemble the M8 Channel Nuts

(Item 5) to the Legs (Item 1) using M8 x 25

Button Head Bolts, M8 Spring Washers and

M8 x 25 x 2SS Flat Washers (Items 2, 3 & 4)

as shown.

Slide the required number of Leg

Assemblies into the Universal Load Bed

Track as shown.

In some cases the Channel Nut may need

dressing with a ﬁle to remove high spots

and to insure it slides smoothly in the

track.

The M8 Channel Nut will rotate at an angle

in the Track when fastening.

The remaining fasteners will be used

when mounting your Load Bars or Tray to

the Universal Load Bed Legs.

13mm

INSTALL OTHER VEHICLE AND RACK ACCESSORIES

Now's the time to visit your favorite Front Runner Dealer in person or online.

Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam

Share your adventures on:

FINISH

Congratulations! You did it. Take a step back and admire your work!

5mm
