Franke Swiss Mambo Manual de instalación

Programming Instructions Typ G

Swiss Mambo

Softwareversions up from G 2.00; G3.01

Date: Mai 1998

Visum: BJ

Franke Kaffeemaschinen AG

CH-4663 Aarburg

Tel.: *41 0)62 787 37 37

Fax: *41 0)62 787 30 10

www.km.franke.ch

Coffee-MachineG

CONTENTS

1. Programmingkeyboard

1.1 Generalview

1.2 Accessintoprogramparameters

1.3 Exitfromtheprogrammingtreestructure

1.4 Inputkey

2. Maingroupsintheprogrammingtree

structure

2.1 Installation

2.1.1 Explanationsoftheinstallationmaingroup

2.2 Service

2.2.1 CalibrationoftheGrinder

2.3 Programparameters

2.4 Counters

2.5 Set-up

3. Settingparametersintheprogrammingtree

structure

4. Additionalprogrammingpossiblitieswiththe

SoftwareG.301

5. Concisedescriptionofthespecialoptions

MANUAL 2/1

Coffee-MachineG

1. Programming keyboard

1.1 General view

MANUAL 2/2

Inlet for

ground coffee

Coffee beans container

Cup storage space

Control panel

Coffee outlet with

integrated Cappucinato

Coffee cake container

Grate

CLEAN

OFF

678910

11 12 13

System Chipcard

Steam tube

ot water outlet

Coffee-MachineG

1.2 Access into program parameters

User:

The"Adjust-Card"allowsfastandimmediateaccesstoadjustandoptimizeproduct

parameters,suchaswaterquantity,grindquantity,steam-timeandmilkquantityfor

Cappuccino,coffeebrewingtemperatureandpricingforinternaldatacentral.

Procedure:

1. Insert"Adjust-Card"

2. Keeppressingbutton+untildesiredoptionisshownindigitaldisplay

3. Confirmdesiredoptionwithbutton--

4. Pressdesiredproductbutton

5. Pressbutton+toincreaserespectivelybutton--todecreasedata

6. Remove"Adjust-Card",alldataisstored

Service:

1. Pluginprogrammingkeypadonmainboard

2. Accessprogrammingmodeby

- TurncoffeemachineoffwiththeON/OFFbutton

- Pressbutton"OK",keepitpressed

- TurnmachinebackonwiththeON/OFFbutton

- EnterServiceCode-No.21onkeypad(ServiceCode)

3. PressbuttonOKtoaccessdesiredparameter

1.3 Exit of the programming tree structure

END RepeatedactuationoftheENDkeytakesusbackuptheprogrammingtree

untiltheprogrammingmodeisleftandthenormaloperatingmodestarted.

OFF Exitfromtheprogrammingmodeisalsopossiblebyswitchingoffthewhole

machine.

MANUAL 2/3

Coffee-MachineG MANUAL 2/4

1.4 Input keys

NEXT Whenthiskeyisactuatedwe

moveontothenextpro-

grammingstep.

BACK SimilarfunctiontotheNEXT

keytomovebackonestepin

theprogrammingtreestructure.

OK Thiskeyisusedtoconfirman

input,toaccessamaingroup

oftheprogrammingtreestruc-

tureorcertainprogramstepsto

startaprocedure.

END ActuationoftheENDkeyexitsfromthecurrentstep.Theprogram

indicatormovesonemaingrouphigher.

ALT Thiskeyisusedtodisplaytheoldvalueagainifawronginputhas

beenmadeandtheOKkeyhasnotbeenactuated.Italsohasvarious

functionsinconnexionwiththedefinitionofthewaiters'keysand

clearingthecountertables.

. Thedotkeyisusedtoinputnumericalvalueswithdecimalplaces,

whenproductnamesaretobeselectedfromatable(programpara-

meters)andwhenthecounterreadoutaretobeprintedoutona

reportprinter.

Inputofdigit Enteradigitbymeansofthekeyboardincludingthedecimalpoint.

Iftheinputiscorrect,confirmwiththeOKkey.

Iftheinputisincorrect,theBACKkeycanbeusedtomovebackone

placeortheALTkeytorecallthepreviousdisplaycontent.

AninputmustthereforebeterminatedeitherbyOKorbyALTbefore

wecanmoveonfurtherinthetree.

Coffee-MachineG

2.1 Installation

Inthismaingroupwe

havethepossibilityto

activateallactuators

manually.Inthedis-

playwillappeara

smallmenu.Bypres-

singthecorrespon-

dingnumericpadthe

desiredactuatoris

activated.

MANUAL 2/6

2.1.1 ExplanationsoftheINSTALLATIONmaingroup

Scaldhead 1:UP Thepistonmovesupaslongasthekeyisactuated.Switch-offis

noteffectedbeforethemechanicalendstopisreached.

2 : DN Thepistonmovesdownaslongasthekeyisactuated.Once

again,noswitch-offiseffectedbeforetheendstopisreached.

3: INIT Actuationofthekey3triggersareferencecycle.Thepistonruns

downtothelowerendstop,changesitssenseofrotationand

runsuptothetopendstop.

end ok

back next

MOTORS

1: PU 2:ML 3:MR

TEA / STEAM 1:VT

2:VS 3:VW 4:HT

INSTALLATION

back next

COFFEE 1

1:WD 2:VC 3:HC 4:ON

SLIDE

1:SL 2:SR

back next

FILLING

1:COFFEE 2:TEA

OUTPUT 2

REL 1 - 7

back next

SCALD HEAD

1:UP 2:DN 3:INIT

1: COFFEE TEMP 85.2

end

back next

OUTPUT 2

REL 8 - 14

CAPPUCCINO

1:VC 2:VR 3:VL

back next

Coffee-MachineG MANUAL 2/7

Itthentravelstothebasicposition.Thisreferencecycleenables

thepistonitselftomeasurethegeometryofthebrewingassem-

blyandsetitstopandbottompoints,togetherwiththeposition

ofthestopswitch.

Slide 1:SL Theleftslideisactivated(Y10)aslongasthekeyispressed.

2:SR Therightslideisactivated(Y11)aslongasthekeyispressed.

Motors 1 : PU Activationofthepumpmotor(M2).

2 : ML Activationoftheleftgrindingmill(M3).

3 : MR Activationoftherightgrindingmill(M4).

Coffee 1 : VC Activatesthecoffeevalve(Y1).

2 : HC Therelayontheoutputcardandthepowerrelay(K1)forthe

heatingsystemofthecoffeeheater(E1)areactivated.

Cappuccino 1 : VC ValveCappu(Y20)isactuated

2:VR ValveCappu(Y30)isactuated

3:VL ValveCappuAir(Y21)isactuated

Temp.display 1:COFFEETEMP Actualtemperaturedisplayed;

Operationofthekey1:Coffeeheateron.

Tea/Steam 1 : VT Valvetea1(Y4)isactuated.

2 : VS Thesteamoutletvalve(Y6)isactuated.

3 : VW Activationofthesteamfeedvalve(Y5).

4 : HT Therelayontheoutputcardandthepowerrelay(K2)forthe

heatingsystemoftheteaheater(E2)areactivated.

Filling 1:COFFEE Thepump(M2)andthecoffeevalves(Y1/Y2)areactiva-

ted.Thisenablesthesystemtobefilled.1.Operationof

thekey1:Thepistonisgoingdowntotherinsingposition.

2.Operationofthekey1:Filling.

2:TEA Thepump(M2),thesteamvalve(Y6)andthevalvetea

(Y4)areactivated.

Coffee-MachineG MANUAL 2/8

Output2 Key1: Y21 = Coffeeoutletinfront.

Key2: Y22 = Commonoutlet.

Relay1- 7: Key 1 = Relay 1

Key 7 = Relay 7

Relay8-14: Key 1 = Relay 8

Key7 = Relay 14

SERVICE

DATE

28.02.91

end

SERVICE

TELEFONE

end

back Maximal 20 digits

TELEFONE

062.43.31.31

end

back

SERVICE

ERROR HISTORY

08 PROBE

Table with 20 places

02 CONTAINER FULL

ERROR HISTORY

clear it < ok> ?

old

ok end

no Data erased

Data erased

SERVICE

CHECK

end

back CHECK

20875 / 30000

SERVICE

CHIPCARD

DOWNLOAD= ok

back

DOWNLOADING

2.2 ervice

Thismaingroupisconsideredasahelpfortheserviceengineer.Itconsistofthe

followingpossibilities:

-Dateoflastservice

-Telephonenumberofservicecenter

-ServicechecknumberofpistonmovementsACTUALNUMBERS/SETTING

-Errorhistoryofthelast20failures

Coffee-MachineG

Calibrationofgrinders

Ifinthemaingroup"SETUP"under

"MILLOPTIONS"the"CLAFTER

CHECK"isseton2,itisnecessaryto

calibrate the grinders prior to the

"MILLCHECK".

Eachgrinderhastobecalibratedonly

once!

Adjustdegreeoffinenessofgrind

before calibration to +/- 1/2 scale

setting.Ifaconsiderableadjustmentis

maderepeatcalibration.

MANUAL 2/10

back

COFEE

MILLQUANT 3.25

back COFFEE

MILL C H EC K

COFFEE

CAL-> O K

Grinder isshorter

activated

WEIGHT_

Input of weight of

ejected coffee cake.

Key OK

yes Weight= 0 ?

Grinder islonger

activated

WEIGHT_

yes Weight= 0 ?

Input of weight of

ejected coffee cake.

Key OK

yes

Key OK ?

MILLCHECK

CAL-> OK

( N EXT )

pressOK

Coffee-MachineG

Default-

facts

from

Tree Parameter Function Min Max E-prom Remarks

SERVIC DATE Date of last service

TELEPHONE Telephone no. of service

station

20 digits

00000.00.

00.00 99999.99.

99.99

SERVICE

CHECK Automatically reminder to the

operator to call the service for

a check-up

030000 0

ERROR

HISTORY List of errors with 20 places

(ring buffer)

CHIPCARD DOWNLOAD with card

Datas on card

PROGR

PARA

METER

Coffee

PRODUCT Group of product

0 = empty key 1 = COFFEE 0 to 2

NAME Select name of product out of

table with dot key See

Man 3/3

CUPS Numbers of cups 199 1

PRICE Price unit per cup 09999.99 0

CYCLES Numbers of cycles 199 1

PREINFUSION Preinfusion

00 = OFF

35 (example)

3 = 3.0 sec. waiting

5 = 0.5 sec. water injection

0 1 0

PUMP Pump on/off for this key

0 = OFF 1 = ON 0 1 1 1 only

when free

in SETUP

PRESS 0 = Function off

Ground will be pressed

1 = Coffee ground will be

pressed first, then piston

automatically retracts

2 = Brew coffee

Piston stops in cleaning-

position

40 - 255 = OFF-set function

Piston stops before

pressing

0255 0

CAPPU 0 = Without common outlet

(in front)

1 = With common outlet

steam

and coffee at the same

time

2 = With common outlet,

first coffee, then steam

3 = With common outlet,

first steam, then coffee

0 3 0

MILK Proportion milk to froth 0100 10

CAPPU TIME Actuation time steam valve 0.1 99.9 1seconds

MANUAL 2/14

3. Parameters in Programming Tree
