Flashforge Creator 3 Pro Manual de usuario

快速启动指南

Creator 3 Pro / 金刚狼3 Pro

Quick Start Guide

EN/CN/DE/FR/한-A01

本手册仅适用于闪铸科技金刚狼3 Pro 3D打印机

This guide is only applicable to FLASHFORGE Creator 3 Pro 3D printer

EN P01 / CN P09 / DE P17 / FR P25 / 한 P33

WARNING

注意事项

1. Hot! Avoid touching the heating nozzle and heating build plate in

operation.

2. Moving parts in printer may cause injury. Do not wear gloves or other

sources of entanglement in operation.

1. 高温危险！打印机喷嘴和打印平台在工作时会被加热，请避免接触!

2. 可动部件可能造成卷入挤压和切割伤害。操作机器时请不要佩戴手套或缠绕物。

Creator 3 Pro Quick Start Guide

Creator 3 Pro Introduction

12 13 14

1. Touch screen

2. USB disk port

3. Right extruder

4. Left extruder

5. Nozzle brush

6. Build plate

7. Leveling nut

8. Filament holder cover

9. Filament holder cover handle

10. Wind guide nozzle

11. Nozzle

12. Ethernet port

13. Power switch

14. Power cord entry

Packing List

Creator 3 Pro Filament Quick Start Guide After-sales

service card

Power cord

Unclogging pin tool

Lubricating grease PVP glue stick

Stamping wrench Cross screwdriver

Allen wrench

USB disk Leveling card

PTFE tube

Scraper

快速启动指南

Creator 3 Pro 金刚狼3 Pro

Quick Start Guide

EN/CN/DE/FR/한-A01

本手册仅适用于闪铸科技金刚狼3 Pro 3D打印机

This guide is only applicable to FLASHFORGE Creator 3 Pro 3D printer

EN P01 / CN P09 / D E P17 / FR P2 5 / 한 P33

WARNING

注意事项

1. Hot! Avoid touching the heating nozzle and heating build plate in

operation.

2. Moving parts in printer may cause injury. Do not wear gloves or other

sources of entanglement in operation.

1. 高温危险！打印机喷嘴和打印平台在工作时会被加热，请避免接触!

2. 可动部件可能造成卷入挤压和切割伤害。操作机器时请不要佩戴手套或缠绕物。

Precautions for Unpacking the Equipment

4. Remove the buckles on the X-axis and Y-axis synchronous belts.

1. Take out the top accessories and pearl cotton.

2. Remove the tape from the machine.

3. Take out the internal pearl cotton block.

6. Press and hold [Z-] continuously until the build plate rises to a higher position, and

then take out the foam block below.

5. Connect the printer to the power supply, after power on, and then click [Tools] and

[Manual] in turn on the touch screen to enter the manual control interface.

1. Open the ﬁlament holder cover.

2. Take out the ﬁlament and insert it

into the ﬁlament feeding inlet.

Filament

intake

3. Attention: To facilitate smooth rotation of the ﬁlament, please install the ﬁlament in

the direction shown in the ﬁgure.

When installing the left-side ﬁlament, please make it run in the counterclockwise

direction;

When installing the right-side ﬁlament, please make it run in the clockwise direction.

Filament Loading

Preparation for Printing

4. Insert the ﬁlament into the ﬁlament

feeding inlet continuously until the ﬁlament

goes through the ﬁlament guide tube.

5. Press the ﬁlament feeding pressing plate

in front of the extruder, insert the ﬁlament

vertically into the extruder until it can't be

inserted any further, and then loosen the

ﬁlament feeding pressing plate.

6. Insert the ﬁlament guide tube into the

ﬁlament inlet hole on the extruder to ﬁx.

7. Finally, ﬁx the ﬁlament spool on the

ﬁlament spool holder and close the cover.

8. Filament feeding operation: Click the [Tools]-[Filament] button on the screen in turn,

and set a reasonable heating temperature according to the required temperature value

of the material; Operate according to the screen prompts, and wait for the nozzle to

extrude uniform ﬁlament smoothly.

Filament unloading operation: Click [Unload], press down the ﬁlament pressing plate

after the extruder temperature heating is completed, pull out the white ﬁlament guide

tube, and pull out the ﬁlament upward quickly and then ﬁlament unloading is completed.

Push ﬁlament

down through

for 3 seconds

Withdraw

Filament

Guidetube

Press here

9-point leveling function: when the printing ﬂatness is still poor after the platform

leveling and XY/Z axis calibration, this function can be used to compensate for better

ﬂatness;

Manual leveling mode: Execute platform leveling, Z-axis calibration and X, Y axis

calibration in turn. This is a complete set of leveling and calibration operation procedures.

The equipment has been leveled and calibrated before leaving factory. However, the

leveling plane may be damaged due to the vibration generated during transportation. It

is recommended to perform leveling before the ﬁrst printing. There are two leveling

modes: auxiliary leveling mode and manual leveling mode. In the auxiliary leveling

mode, all execution will be completed with the help of the extruder sensor and auxiliary

prompts. When the function option is in the manual mode, the platform leveling in the

auxiliary mode will not activate the sensor function.

In total, the equipment contains the following leveling calibrations: Platform Leveling,

Calibration XY, Calibration Z and Auto level;

Please operate in the following order:

1. Click [Tools] and [Level Calibration] on the touch screen;

2. Select the auxiliary mode for leveling and calibration;

3. The extruder sensor calibration has been set before leaving factory, so there is no need

to operate again; Click platform leveling and operate following the prompts on the

screen;

4. Perform Z-axis calibration and operate following the prompts on the screen;

5. The X, Y axis have been calibrated before leaving factory, so there is no need to

operate again;

6. The whole leveling and calibration is completed.

Leveling and Calibration

Before the ﬁrst printing, please complete the leveling, loading and calibration correctly

under the guidance of the quick start guide.

1. Tap [Print]. 2. Tap [Local memory] to choose print ﬁles.

3. Choose the preset print ﬁle [pavilion.gx].

5. The printer starts to heat up and will start printing after heating completed.

First Print

4. Tap [Print].
