Flashforge Adventurer3 Manual de usuario
本手册仅适用于闪铸科技 Adventurer3 3D打印机
This guide is only applicable to FLASHFORGE Adventurer3 3D printer
1. Hot! Avoid touching the heating nozzle and heatingbuild platein operation.
Please refer to FlashForge official website www.flashforge.com to download
the newest User's Guide, Software and Instruction Videos.
(Support-Support Center-Select a Product)
2. Moving parts inprintermaycause injury. Do not wear gloves or other
sources of entanglement in operation.
Download
1. 高温危险！打印机喷嘴和打印平台在工作时会被加热，请避免接触!
2. 可动部件可能造成卷入挤压和切割伤害。操作机器时请不要佩戴手套或缠绕物。
前往闪铸科技官方网站 www.sz3dp.com ，可以在[ 技术支持 ] 页面下载用户使
用手册、切片软件等资料，或查看相关操作视频。
资料下载
SZ16-ZN/EN-A06
快速启动指南
ADVENTURER 3 /冒险家 3
Quick Start Guide
中文P10
01
3D Printer Filament After-sales
service card
Allen WrenchScrewdriverQuick Start Guide Unclogging Pin Tool
Power Cable
Kit Contents
本手册仅适用于闪铸科技 Adventurer3 3D打印机
快速启动指南
Thisguide is only applicable to FLASHFORGEAdventurer3 3D printer
ADVENTURER3 发明家3
SZ16-ZN/EN-A01
1. 高温危险！打印机喷嘴和打印平台在工作时会被加热，请避免接触!
1.Hot! Avoid touching the heating nozzle and heating build plate in operation.
Pleaserefer to FlashForge official websitewww.flashforge.com to download
thenewest User Guide and Quick Start Guide.
(SUPPORT-SupportCenter - Select a Product)
2.Moving parts in printer may cause injury. Do not weargloves or other
sourcesof entanglement in operation.
2. 可动部件可能造成卷入挤压和切割伤害。操作机器时请不要佩戴手套或缠绕物。
最新版本说明书请前往闪铸科技官方网站www.sz3dp.com下载。
（技术支持 - 下载中心 - 说明书/快速启动指南下载）
9
Grease
Getting to know your Adventurer 3
1. Filament guide tube 2. Filament guide tube joint 3. Extruder base 4.Cooling Fan
5. Removable nozzle 6. Extruder cables 7. Clip 8. Led light
9. Wind guide nose 10. Front door 11.Y-Axis sliding slot 12.Platform base
13. Removable build plate 14.Touch-screen 15.USB stick input 16.Power switch
17. Power input 18. Spool holder 19.Filament cover 20. Filament cover handle
21. Moto 22. Filament intake 23.Filament feeding wheel 24. Top cover
25. Air outlet 26. Ethernet input
2
3
4
5
16
7
8
9
22
23
10
13
11
12
14 15
21
16
17
18
19
20
24
25
26
02
Unpacking
KEEP DRY
HANDLE
WITH CARE
FRAGILE
ThePeople's Insurance Companyof China
KEEP DRY
HANDLE
WITH CARE
FRAGILE
ThePeople's Insurance Companyof China
KEEP DRY
HANDLE
WITH CARE
FRAGILE
1. Open the box. 2. Take out the wrapping paper box
on the top.
3. Be careful! Filament, tools kit and power
cable are all placed inside the wrapping
paper box.
4. Take out the printer from the box.
03
7. Open the front door, take out the paper box inside
the printer, printer unpacking completed.
6. Click [tools]-[setting] in turn to enter page like this, turn to page two, click [move].
Click the upper arrow in the moving page to make the extruder raises for removing the
paper box on the bottom easier.
04
Power Switch
5. Plug the power cable into the input on the
back and turn on the power switch, the touch
screen is turned on.
X
YZ
X: 20.00 Y: 45.00 Z: 36.00
Status Language
Calibration Home
Move Camera
FilamentCheck Led
1/3
<
<<
2/3
<
05
Power Switch
Plug the power cable into the input on the
back and turn on the power switch, the touch
screen is turned on.
1. Open the filament cover, insert the filament into the
filament intake, push filament into the feeding wheel
until some resistance is sensed.
Note: Please make sure filament has been pushed into
the feeding wheel!
First Print
Load Filament
06
2. Tap [Filament]--Tap [Load]--After Load completed--Tap [OK]
3. Load completed when you see filament come out of extruder, Tap [OK].
Put the spool of filament on the spool holder, close the filament cover.
Build
Tools
Filament
Load
Change
200 /235℃
Heating extruder...
Cancel
235 /235℃
Preheat completed,
Begin loading...
ok
235 /235℃
Press ok when new color appears
Mind the loading direction of filament, make sure
to be clockwise as the picture showed.
ok
07
1. Tap [Build], choose the file path: Print from local memory card.
2. Locate the model file in the model list, Tap on its right to start printing;
or tap model file picture or file name to enter model details page, tap to start printing.
3. Extruder will heat up and printer will start printing after heating completed. After model
printing finished, printer will sound a beep and pop out notice on touch screen.
Model Print
Build
Tools
Filament
6.67GB
No job
Not Available
1/3
<
<
...
0h10 min
Time Remaining
m
7.49
20mm_Box-
PLA.gx
20mm_Box-PLA.gx
20mm_Box-P...
0 h 10 min
0.70M
Build completed!
ok
08
Model Remove
1. As showed in picture, press down dotted line area and draw out the
removable build plate.
When printing completed, extruder and build plate may still hot,
please start operating after cooling down!
2. Bend the build plate, the plate will produce certain deformation, seperating the
plate away from the bottom of model (Please use a scraper to assist removing
when model is too small or big).
Notices
Heating extruder...
1. Tap [Filament]--Tap [Change], extruder will start preheating.
2. Pull out the filament as the picture
showed above.
4. When new filament come out of extruder steadily, replace is completed, Tap [OK].
3. Insert new filament into the filament intake
and push the filament into the feeding wheel
until resistance is sensed.
Load
Change
200/235℃
Cancel
220/235℃235/235℃
OK
235/235℃
OK
Unloading the filament,
please wait...
Pull out filament,
feed new filament, press [OK]
Press ok when new color appears
Change Filament
09
