FeiYu Tech G5 Manual de usuario
Guilin Feiyu Technology Incorporated CompanyV 2.0ENUser Manual3-Axis Stabilized Handheld GimbalCompatible with GoPro HERO5 / HERO4 / HERO3+ / HERO3 / Yi Cam 4K / AEE etc.
1. Product Overview* The showing sports camera is only for reference[1] [3] [4] [5] [6] [2] 1 [9] [8] [7] [10] [11] Counter weight[12] [12] Weight ring [13] [13] Thumb screw[14] [14] Retainer plate[15] [15] Retainer bar[16] [17] [16] USB interface[17] Trigger button[2] Rolling axis [3] Status indicator [4] Joystick [5] Function button [6] Self-timer button [7] Titling axis [8] Vertical arm[9] Panning axis [10] Handle[1] Cross arm[11]
USB cable X1Battery (Type:22650) X1Mini camera charging cable X1Thumb screw X2HERO 5 camera charging cable X1Portable bag X1App ControlCompatible with Accessories*Never submerge the gimbal in water2 Water Splash ProofPackage List
3 2. User GuideAttention: Please complete the following instructions before powering on the gimbal.12Install the camera on retainer plate,then x the camera with retainer bar and screw.Install the CameraTake the Gopro HERO 5 camera for exampleoption 12-option 2Install the batteryRemove the handle and insert one 22650 battery into it.1-normal position2-reverse position
3In order to achieve in a better performance of the gimbal, please try to balance the camera before powering on G5.Balance adjustment reference :GoPro HERO 5 counter weight & weight ringGoPro HERO 4 counter weightBest BalanceCamera balance adjustment
weight ringcounter weight
4Power on / oPower OnPress and hold the function button until the green light comes on and you hear the tone.Power OPress and hold the function button until the red light changes from quick ashing to constant and you hear the tone.In case of low battery the indicator light will ash red three times every 5 seconds. Please charge gimbal or replace the battery.!Attention: Make sure the camera is secure before powering on the Gimbal.4
3. Modes / FunctionsFunction ButtonTwo tapsOne tapFunction ExplanationAll followThree tapsRotate horizontal 180°Make the lens rotate 180 ° Mode / Function Operation Instructions5 Trigger Button
In the panning follow or all follow, press and hold the button to enter the locking mode, release it to return previous mode
Two tapsPanning ResetLong pressLocking ModeFunctionExplanationExplanation of LED indicator statusThe current mode of the gimbal can be identied by the indicator status.
Indicator
statusMode / Status
Blue light ashes onceBlue light ashes twice
Panning followAll followLocking mode / Initialize the gimbal
Blue light constant onBlue light keeps ashing
Initialization failure / MalfunctionLow battery
Red light ashes three timesRed light keeps ashing
Entering power o
Explanation of joystick controlFunction ButtonSelf-timer button
Up
Status
indicator
LeftRightDownLong press the self-timer button, the lens will rotate 180 °,release to restore.Four tapsQuadruple taps to enter autototation modeAutorotation ModeFive taps InitializationFive taps to automatically enter initialization
Panning follow / Locking ModeSingle tap to switch between panning follow and locking modeUnder all follow, single tap to switch to locking modeRestore the initial follow state of the panning follow
The orientation of the camera is xed.Working ModesPanning followAll direction are xed, and the camera lens moves according to the hand movement directionof the user.All followThe rolling direction is xed, and the camera lens moves according to the hand movement directionof the user.Locking ModeReturn to panning follow, all to return to default.Reset
*The gimbal will work in panning follow after powering on.
Reset30°30°Single tapSingle tapSingle tapSingle tap30°30°Vertical ShootingVertical ShootingVertical Shooting ModeWhen installing GoPro HERO5 on G5, the following conguration of HERO5 will help you to get better audio eect:[MANUAL AUDIO CONTROL] Wind OnlyAudio eect optimizationWind OnlyMANUAL AUDIO CONTROL[RAW AUDIO TRACK] HIGHRAW AUDIO TRACKApplies full audio processing including wind and/or stereo and automatic gain.HIGHMIDStereo Only6
7TiltingTiltingPanningPanningExit operations:1.Click the function button to exit the autorotation mode during automatic rotation and reset the gimbal. 2.Enter the autorotation mode or autorotation setting, four times click the function button to exit the autorotation mode and reset the gimbal.gimbal speed setting reference tableAnnexed parameter tableAutorotation ModeNote: Both the panning and tilting directions can be rotated.1.Four taps on function button, gimbal will access the autorotation mode . 2. Set the gimbal rotetion start position: Pull the tilting axis or panning axis to the start position by hand,clicking the function button to record. 3. Set the gimbal rotetion end position:Pull the gimbal (which can be rotated more than one turn) to the rotation path you want to set, and then click the function button to record the end position .4.The gimbal will go to the start position and start the automatic rotation.Using the gimbal autorotation function with a camera, timelapse photography functioning can be used to achieve special movement timelapse photograpy.use the Feiyu ON App for control the speed setting .1.Four taps on function button, gimbal will access the autorotation mode setting.2. Turn the panning axis or tilting axis to the start position and hold for half a second.Click on function button to record the start position . 3 .Turn the panning axis or tilting axis to the end position and hold for half a second.Click on the function button to record the end position .4.Gimbal will recover to start position automatically. Tilting axis and panning axis turn to end position at constant speed.The gimbal is automatically reset after the end.
128 Manual Lock Hold the camera and change its angle in tilting axis direction.Keep this position for half second, the current angle will be locked manually.Pull to the required angle and hold for half a second to lock in that position.(The tilting axis and panning axis in the locking mode can be manual locking .The tilting axis can be manually locked in the panning follow.)Take the tilting axis as an example :
?G5G5?G5360°9 4. Download and connect App12* Use the browser to scan two-dimensional code can be downloaded the App directlyApp StoreDownload "Feiyu ON " and install it.(1) iOS version:(2) Android version:Google playFeiyu ONDownloadGuiLin FeiYu Technology Incorporated CompanyFeiyu ONConnecting AppStart the App on your smartphone,follow the instructions to connect the smartphone with gimbal via bluetooth.Feiyu ONDownloadGuiLin FeiYu Technology Incorporated CompanyFeiyu ONFY_G5 _XXChoose a gimbalFY_XXX_XXFY_XXX_XXFY_XXX_XX×ConnectConnect
