EverFocus ED200 Series Manual de usuario
EVERFOCUS
Color Dome Camera
Operation Instructions
Model No. ED200
Please read this manual first for correct installation and operation. This manual should be retained
for future reference. The information in this manual was current when published. The
manufacturer reserves the right to revise and improve its products. All specifications are therefore
subject to change without notice.
PRECAUTIONS
1. Do not have camera immersed in water.
2. Do not disassemble it or place it on an unstable base.
3. Do not touch the surface of CCD sensor by hand directly.
4. Never face the camera toward the sun.
5. Use proper power source otherwise the camera will not function correctly.
6. Use the camera at temperatures within 0℃~ 50℃/32℉~122℉and humidity between 20%~
80%. The input power sources is 12VDC only.
1
PREFACE
The ED200 Series Camera is a compact, full functioned CCD Camera. Their stylish appearance
can be applied as per installer's ideal locations. These dome cameras can be mounted either on
the ceiling or on the wall easily. ED200 uses high sensitive 1/3" color interline transfer CCD
sensor with DSP. The sensor is featured with Auto Electronic Shutter, Automatic Gain Control,
and Auto White Balance function.
FEATURES
zDesigned with advance digital signal processing circuitry for high image quality
zThe high sensitivity is achieved by using 1/3” SONY Super HAD interline transfer color
CCD
zBuilt-in vari-focal type, mechanical auto iris lens
zBuilt-in fixed lens
zAble to adjust the viewing range with manual zoom lens (for vari-focal lens only)
zBack Light Comp., Auto Gain Control and Auto White Balance functions
zCompact size: 108 mm O.D. x 80 mm H / 4.3” O.D x 3.2” H
zSystem available for NTSC or PAL
STANDARD ACCESSORIES
zCamera Unit
zOperation Instructions (this document)
2
LENS AVAILABLE
* Standard board lens f=3.6 mm, F=2.0 mm.
* Other available lens : 2 Lens f=2.5 mm, F=2.0 mm
4 Lens f=4.3 mm, F=2.0 mm
6 Lens f=6.0 mm, F=2.0 mm
8 Lens f=8.0 mm, F=2.0 mm
3P Pinhole lens f=3.7 mm, F=3.0 mm
INSTALLATION
1. Remove the plastic dome cover.
2. Loosen the two screws of the supporting bracket to remove the camera body.
3. Using four screws to fix the camera base on the ceiling.
4. Put the camera body back to the supporting bracket, the connector of the back panel
should always be placed to camera’s left lower corner, in order to obtain the image of best
quality. Tighten the 2 screws to fix the camera. Please refer to the back panel diagram
shows as below:
a. Floor Mount b. Ceiling Mount
c. Wall mount, aim to the right d. Wall mount, aim to the left
3
5. Connect the BNC connector of the camera to a color monitor, or other video device
through a 75 ohm type coaxial cable with BNC female connector at cable extension.
6. Connect the DC +12V regulated power source of the camera (DC Jack) to the DC 12V
Power-in jack with 2 mm, center+, outer- plug.
7. Once the image appears on the monitor, loosen the fixing screw located at the lens
mount then adjust the focus and diaphragm of the lens to obtain the best picture. When the
ideal picture is obtained, secure the lens mount by fixing screw firmly again.
8. Put the plastic cover back on the Dome Camera.
4
SPECIFICATIONS
Pickup Device 1/3'' SONY Super HAD CCD
Video Format NTSC or PAL
Scanning System NTSC: 525 TV lines, 60 fields/sec
PAL: 625 TV lines, 50 fields/sec.
Picture Elements NTSC: 510(H) x 492(V);
PAL: 500(H) x 582(V)
Horizontal Resolution 380 TV Lines
Sensitivity 0.3 Lux/F=1.2
S/N Ratio Over 48dB (AGC off)
Electronic Shutter 1/50(1/60)~1/100,000
Lens Type
f=2.5mm; f=3.6mm; f=4.3mm; f=6.0mm; f=8.0mm; f=12.0mm;
f=16.0
*Lens models and availability vary in different regions
Back Light Comp. Yes
Auto Gain Control Yes
Auto White Balance Yes
Gamma Correction 0.45
Video Output BNC 1.0Vp-p, 75ohm
Sync. Mode Internal sync
Power Source 12VDC
Power Consumption 12VDC 1.5W max
Dimensions 108 mm (O.D.) x 80 mm (H) ; 4.3” (O.D) x 3.2” (H)
Weight 0.3kg ; 0.7 lbs
Operating Temperature 0°C~50°C ; 32°F~122°F (20%~80% Humidity)
Certifications FCC/CE
5
EverFocus Electronics Corp.
Head Office:
12F, No.79 Sec. 1 Shin-Tai Wu Road,
Hsi-Chih, Taipei, Taiwan
TEL: +886-2-26982334
FAX: +886-2-26982380
www.everfocus.com.tw
USA L.A. Office:
1801 Highland Ave. Unit A
Duarte, CA 91010, U.S.A.
TEL: +1-626-844-8888
FAX: +1-626-844-8838
www.everfocus.com
USA N.Y. Office:
415 Oser Avenue Unit S
Hauppauge, NY 11788
TEL: 631-436-5070
FAX: 631-436-5027
www.everfocus.com
Europe Office:
Albert-Einstein-Strasse 1
D-46446 Emmerich, Germany
TEL: 49-2822-9394-0
www.everfocus.de
China Office:
Room B-05D-1, KESHI PLAZA , Shangdi
Information Industry Base,
Haidian District, Beijing China
100085
TEL: +86-10-62973336/37/38/39
FAX: +86-10-62971423
www.everfocus.com.cn
Japan Office:
1809 WBG MARIBU East 18F,
2-6 Nakase.Mihama-ku.
Chiba city 261-7118, Japan
TEL: +81-43-212-8188
FAX: +81-43-297-0081
www.everfocus.com
Y
our EverFocus product is desi
g
ned and
manufactured with high quality materials and
components which can be recycled and
reused.
This symbol means that electrical and
electronic equipment, at their end-of-life,
should be disposed of separately from your
household waste.
Please, dispose of this equipment at your
local community waste collection/recycling
centre.
In the European Union there are separate
collection systems for used electrical and
electronic product.
Please, help us to conserve the environment
we live in!
Ihr EverFocus Produkt wurde entwickelt und
hergestellt mit qualitativ hochwertigen
Materialien und Komponenten, die recycelt
und wieder verwendet werden können.
Dieses Symbol bedeutet, dass elektrische und
elektronische Geräte am Ende ihrer
Nutzungsdauer vom Hausmüll getrennt
entsorgt werden sollen.
Bitte entsorgen Sie dieses Gerät bei Ihrer
örtlichen kommunalen Sammelstelle oder im
Recycling Centre.
Helfen Sie uns bitte, die Umwelt zu erhalten, in
der wir leben!
P/N: MED2G02100
