EverFocus EZ180 Manual de usuario

User’s Manual

and

Operation Instructions

Notice

This manual is presented to the users of EZ180 by EverFocus Electronics

Corp. With years of engineering researches, EverFocus has spared no effort

to provide the high quality products to the worldwide users. For the policy

of continual product improvement, EverFocus reserves the right to make

changes to the product specifications and documentation without notice.

All the components of the products, including accessories, components, and

outlook, are based on the agreements of each deals to satisfy all kinds of

users. Meanwhile, please be advised that every step of operation must

follow the instruction of this manual to keep EZ180 working under the best

condition. Please notice that EverFocus will not be charged any claims or

renewing cases resulted from inappropriate operation.

Table of Contents

Safety Warning …………………………………………1

Introduction……………………………………………..2

Specification…………………………………………….3

Major Parts Names…..…………………………….…..4

Installation Instructions………………………….….…5

Settings………………………………………………….7

1. Handle the camera with care.

Be careful when handling the camera, do not drop it or subject

it to strong shock or vibration to prevent any damages to it. Do

not disassemble it or place it on an unstable base.

2. Do not install the camera near electric or magnetic fields.

Installed the camera away from TV, radio transmitter, magnet,

electric motor, transformer, audio speakers because the

magnetic fields generate from above devices will distort the

video image.

3. Do not install the camera in the high temperature environment.

Installed the camera away from stoves, or other heat

generating devices as the high temperature could cause

deformation, discoloration or other damages of the camera.

Install the camera at where the temperature range will stay

between -35℃~+50℃for 12VDC,-45℃~+50℃for 24VAC.

4. Never face the camera toward the sun.

Never aim the camera at the sun or other extremely bright objects

whether it is in use or not.

5. Cleaning

Do not touch the surface of CCD sensor by hand directly. Use

a soft cloth to remove the dirt from the camera body. Use lens

tissue or a cotton tipped applicator and ethanol to clean the

CCD sensor and the camera lens. When the camera is not in

use, put the cover cap on the lens mount.

Safet

Warnin

The EZ180 series offers great performance in 1/3”image format B/W

CCD camera. The EZ180 is ideal for outdoor applications such as

parking lots, gas stations or shopping malls. The sophisticated circuit

design provides a heater that turns on at 10℃for cold weather. The

EZ180 will provide protection against the elements and provide an

excellent quality picture.

Main Features :

High Resolution: 560 TV Lines.

Two types of built-in vari-focal lens for versatile applications.

Designed with sturdy aluminum shell specifically for outdoor

surveillance.

Removable sun shield.

The heater allows the camera to be used in extremely low

temperature to -46°C.

Introduction

EZ180

Pickup Device 1/3” SONY B/W CCD

Picture Elements 768 x 494 (EIA)

752 x 582 (CCIR)

Horizontal Resolution 560 TV lines

Video Output BNC 1.0Vp-p, 75 ohm

Lens Focal Length Vari-focal lens f=3.5~8mm

Vari-focallensf=9~22mm

*Lens models and availability vary in different regions

Sensitivity 0.1 lux/F=1.6

Gamma Correction 0.45

S/N Ratio Over 48dB (AGC off)

Back Light Comp. On/Off switch

Auto Gain Control On/Off switch

Flickerless On/Off switch

Line Lock On/Off switch

Sync. Mode Internal Sync.

Weatherproof IP66

Power Source 12VDC/24VAC

Power Consumption 12VDC: 7.5W max. (Heater ON)

24VAC: 10W max. (Heater ON)

Dimensions With sun shield : 90.7mm(W) x 70mm(H) x 172mm(L);3.57"(W) x

2.8"(H) x 6.8"(L)Without sun shield: 57mm(O.D) x 132mm(L);

2.2"(O.D) x5.2"(L)

Weight 0.71 kg ; 1.6 lbs

0.91 kg ; 2 lbs (with bracket)

Operating Temperature -46℃~ 50℃; -50.8°F~122°F (20%~80% Humidity)

Heater Operating Temperature 10 °C ; 50°F

Certifications FCC/CE

ecification

Mounting

Base

Swivel

Screw

Assembly

Screw

Sun Shield

Cover

Back Fixing Plate

Mounting

Base

Swivel

Screw

Assembly

Screw

Sun Shield

Cover

Back Fixing Plate

Major Parts Names and Their Functions

Fixing Screw Front

Fixing Plate

Fixing Screw Front

Fixing Plate

Mounting Bracket

O-ring Seal

Heater

Lens

Focus Zoom

IRIS ALC/Level Adjustment

Control Switch Mounting Bracket

O-ring Seal

Heater

Lens

Focus Zoom

IRIS ALC/Level Adjustment

Control Switch

Set-Screw

1. Using the supplied screws, mount the bracket base on the desired

location.

2. Connect the BNC connector of the camera to a monitor or other

video device through a 75 ohm type coaxial cable with BNC female

connector at cable extension.

3. Connect the 24VAC or 12VDC regulated power source of the camera

(power jack) to the power-in jack with 2mm plug. For 12VDC

power source, please make sure the power plug is center+ outer-

for heater normal operation.

4. Our factory settings is for you to get the best image within about 3~5

meters (for veri-focal lens f=3.5~8mm) or 5~10 meters (for

veri-focal lens f=9~22mm) . If it is out of focus, or any other

adjustment is required, follow the procedures below.

a. Remove the fixing screw in the front, which hold the sun shield

cover. Remove the sun shield cover.

b. Twist open and carefully remove the housing cover.

(Please pay attention to prevent damage to the “O”-Ring seal.)

c. Loosen the focal lens and focus locking screws.

d. Adjust the lens to bring the subject into focus.

(Caution: Heater elements could be hot! When camera power is

on, use caution when adjusting the camera.)

e. Retighten the screws.

f. Please refer to the Settings section for the details of the other

adjustments. Adjust accordingly if necessary.

Installation Instructions

g. When all the adjustments and settings are completed, overlaying

the cover gently. Be careful not to damage to the “O”-Ring and

camera components.

h. To reassemble the sun shield, match the hole on the sun shield to

the back fixing plate of camera, Fix the screw on the front fixing

plate. Make sure the wider side of the fixing plate holds the edge

of the camera well.

5. Attach the camera onto the mounting bracket.

6. Loosen the swivel screw and point the camera to the desired

direction.

7. Tighten the swivel screw. To strengthen the fixing power of the

swivel screw, tighten the set-screw with the set-screw wrench.

(supplied)

Notes:

(A) Make wiring connections only after it has been determined that

power has been disconnected.

(B) There is a desiccant pack attached to the housing base under the

camera which is designed to absorb any moisture trapped inside

the housing during adjustment. To avoid excessive moisture

build up, it is recommended that the camera not be installed in

rainy or excessively damp conditions. It is also advisable to

limit the number of times the housing cover is removed. The

desiccant pack can be replaced if condensation develops inside

the housing.

The camera is set up at factory and normally requires no adjustments.

Sometimes, however, adjustments may be necessary. Please refer to the

following description for the function details.

The IRIS ALC and IRIS Level adjustments are located on the side

circuit board, use a screwdriver to adjust if it’s necessary.

IRIS Level Adjustment

To adjust brightness level –

zTurn the IRIS Level Adjustment VR counterclockwise to get

darker picture.

zTurn the IRIS level adjustment VR clockwise to get brighter

picture.

IRIS ALC Adjustment

To select light metering method –

zTurn the IRIS ALC Adjustment VR counterclockwise for

Average Metering.

zTurn the IRIS ALC Adjustment VR clockwise for Peak

Metering.

Settings

IRIS ALC

Adjustment

IRIS Level

Adjustment

Control Switches
