Aristo®

Instruction manual

0460 971 101 GB 20140521 Valid for: W82:905-,944- xxx-xxxx RetrofitW82:419-xxx-xxxx

W82

TABLE OF CONTENTS

0460 971 101 © ESAB AB 2014

1 SAFETY ................................................................................................................ 4

2 INTRODUCTION................................................................................................... 7

2.1 Equipment............................................................................................................. 7

3 TECHNICAL DATA ............................................................................................... 8

4 INSTALLATION..................................................................................................... 9

4.1 Mains supply ........................................................................................................ 9

4.2 Assembly instruction...........................................................................................9

4.3 System description ............................................................................................10

4.4 How to set-up the U82 for use with W82..........................................................10

4.4.1 Save your stored data ...................................................................................... 10

4.4.2 Convert the U82 stand alone unit to a presentation unit .................................. 11

4.5 Systems diagrams ............................................................................................. 11

5 OPERATION ....................................................................................................... 13

5.1 Connections and control devices.....................................................................13

5.2 Overheating protection......................................................................................13

6 MAINTENANCE.................................................................................................. 14

6.1 Inspection and cleaning .................................................................................... 14

7 ORDERING SPARE PARTS ............................................................................... 15

DIAGRAM ..................................................................................................................16

ORDERING NUMBERS.............................................................................................19

ACCESSORIES .........................................................................................................20

Rights reserved to alter specifications without notice.

1 SAFETY

0460 971 101 -4- © ESAB AB 2014

1 SAFETY

NOTE!

The unit is tested by ESAB in a general set-up. The responsibility for safety and

function, of the specific set-up, lies with the integrator.

Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who

works on or near the equipment observes all the relevant safety precautions. Safety

precautions must meet the requirements that apply to this type of equipment. The following

recommendations should be observed in addition to the standard regulations that apply to

the workplace.

All work must be carried out by trained personnel well-acquainted with the operation of the

equipment. Incorrect operation of the equipment may lead to hazardous situations which can

result in injury to the operator and damage to the equipment.

1. Anyone who uses the equipment must be familiar with:

○ its operation

○ location of emergency stops

○ its function

○ relevant safety precautions

○ welding and cutting or other applicable operation of the equipment

2. The operator must ensure that:

○ no unauthorised person is stationed within the working area of the equipment when it

is started up

○ no-one is unprotected when the arc is struck or work is started with the equipment

3. The workplace must:

○ be suitable for the purpose

○ be free from drafts

4. Personal safety equipment:

○ Always wear recommended personal safety equipment, such as safety glasses,

flame-proof clothing, safety gloves

○ Do not wear loose-fitting items, such as scarves, bracelets, rings, etc., which could

become trapped or cause burns

5. General precautions:

○ Make sure the return cable is connected securely

○ Work on high voltage equipment may only be carried out by a qualified

electrician

○ Appropriate fire extinquishing equipment must be clearly marked and close at hand

○ Lubrication and maintenance must not be carried out on the equipment during

operation

CAUTION!

This product is solely intended for arc welding.

1 SAFETY

0460 971 101 -5- © ESAB AB 2014

WARNING!

Arc welding and cutting can be injurious to yourself and others. Take precautions

when welding and cutting. Ask for your employer's safety practices which should

be based on manufacturers' hazard data.

ELECTRIC SHOCK - Can kill

• Install and earth the unit in accordance with applicable standards

• Do not touch live electrical parts or electrodes with bare skin, wet gloves or

wet clothing

• Insulate yourself from earth and the workpiece

• Ensure your working stance is safe

FUMES AND GASES - Can be dangerous to health

• Keep your head out of the fumes

• Use ventilation, extraction at the arc, or both, to take fumes and gases away

from your breathing zone and the general area

ARC RAYS - Can injure eyes and burn skin.

• Protect your eyes and body. Use the correct welding screen and filter lens

and wear protective clothing

• Protect bystanders with suitable screens or curtains

FIRE HAZARD

• Sparks (spatter) can cause fire. Make sure therefore that there are no

inflammable materials nearby

NOISE - Excessive noise can damage hearing

• Protect your ears. Use earmuffs or other hearing protection. Protect your

ears. Use earmuffs or other hearing protection

• Warn bystanders of the risk

MALFUNCTION - Call for expert assistance in the event of malfunction.

Read and understand the instruction manual before installing or operating.

PROTECT YOURSELF AND OTHERS!

CAUTION!

Class A equipment is not intended for use in residential

locations where the electrical power is provided by the

public low-voltage supply system. There may be potential

difficulties in ensuring electromagnetic compatibility of

class A equipment in those locations, due to conducted

as well as radiated disturbances.

1 SAFETY

0460 971 101 -6- © ESAB AB 2014

NOTE!

Dispose of electronic equipment at the recycling

facility!

In observance of European Directive 2012/19/EC on

Waste Electrical and Electronic Equipment and its

implementation in accordance with national law, electrical

and/or electronic equipment that has reached the end of

its life must be disposed of at a recycling facility.

As the person responsible for the equipment, it is your

responsibility to obtain information on approved collection

stations.

For further information contact the nearest ESAB dealer.

CAUTION!

Read and understand the instruction manual before

installing or operating.

ESAB can provide you with all necessary welding protection and accessories.

2 INTRODUCTION

0460 971 101 -7- © ESAB AB 2014

2 INTRODUCTION

W82is a control unit and it exists in two different chassis:

Aristo® W82

W82is a control unit that adjusts the communication between

welding equipment and automation equipment, such as robots and

computers. Communication protocols: DeviceNet, Profibus,

CANopen and Ethernet.

W82is used together with ESAB's CANbus equipped power sources

for welding automation. For power source and wire feed unit

handling, see the relevant instruction manual.

Retrofit Aristo® W82

Retrofit Aristo® W82is retrofitted on top of supported ESAB power

sources. It connects to the CANbus internally. Communication

protocol: WeldLink.

For information about supported power sources, contact your ESAB

sales representative.



2.1 Equipment



Aristo® W82

• W82DeviceNet, W82Profibus, W82CANopen and W82Ethernet are supplied with a

USB memory and an instruction manual.

• W82Integrated is supplied with an instruction manual.



Retrofit Aristo® W82

• Retrofit Aristo® W82is supplied with the software WeldLink and an instruction manual.



Measurement cable kit and connection cables for different power sources are available as

accessories, see "ACCESSORIES" chapter and separate spare parts list.

Instruction manuals in other languages can be downloaded from the Internet:

www.esab.com

3 TECHNICAL DATA

0460 971 101 -8- © ESAB AB 2014

3 TECHNICAL DATA

Aristo® W82

Supply voltage (to feed unit through W82) 42 V, 50-60 Hz

Supply voltage (from robot) 24 V DC

Supply voltage (from power source) 12 V DC

Weight 4 kg

Dimensions (l × w × h) 366 × 101 × 159 mm

Enclosure class IP 23

Retrofit Aristo® W82

Supply voltage (from power source) 12 V DC

Supply current (max) 1.0 A (12 V DC)

Weight 3.6 kg

Dimensions (l × w × h) 477 × 250 × 90 mm

Enclosure class IP 23

Enclosure class

The IP code indicates the enclosure class, i. e. the degree of protection against penetration

by solid objects or water.

Equipment marked IP23 is intended for indoor and outdoor use.

4 INSTALLATION

0460 971 101 -9- © ESAB AB 2014

4 INSTALLATION

The installation must be carried out by a professional.

See the service manual for Aristo® W82.

4.1 Mains supply

NOTE!

Mains supply requirements

High power equipment may, due to the primary current drawn from the mains

supply, influence the power quality of the grid. Therefore connection restrictions

or requirements regarding the maximum permissible mains impedance or the

required minimum supply capacity at the interface point to the public grid may

apply for some types of equipment (see technical data). In this case it is the

responsibility of the installer or user of the equipment to ensure, by consultation

with the distribution network operator if necessary, that the equipment may be

connected.

4.2 Assembly instruction

Connection of Aristo® W82 to ESAB's Mig 5000i power source

1. Remove the welding power source's rear

handle by removing the screws.

2. Put the W82onto the welding power

source.

3. Screw the W82and the handle into place

in the same screw holes.

Connection of Retrofit Aristo® W82

For instructions on how to connect the Retrofit Aristo® W82, see the Service manual for W82

or contact the nearest ESAB Service Center or distributor.

Connection of Aristo® W82 to ESAB's Mig 3001i, Mig 4001i and Mig 6502c power

sources

Connect the W82with a 2 m cable and place it on the floor or on a stand next to the power

source.

4 INSTALLATION

0460 971 101 - 10 - © ESAB AB 2014

4.3 System description

It is possible to configure the U82unit for stand-alone usage (stand-alone unit) or

presentation usage (presentation unit). The presence of a W82unit within the welding system

determines which unit that is to be used.

The stand-alone unit is used when there is

no W82unit in the system.

The presentation unit is used when there

is a W82unit in the system.

It is necessary to convert the U82stand-alone unit to a U82presentation unit before it is used

together with a W82unit.

During unit start-up it is possible to see if the unit is a presentation unit or not.

4.4 How to set-up the U82 for use with W82

NOTE!

It is necessary to change the U82stand-alone unit to a presentation unit before it

is used together with a W82unit.

4.4.1 Save your stored data

1. Connect the U82stand-alone unit to a power source or a wire feed unit.

2. Turn on the power source's main switch.

3. Export weld data sets from the U82memory to a USB memory (see chapter

Export/Import in the U82instruction manual).

4. Turn off the power source's main switch.

5. Remove the USB memory.

Otros manuales para Aristo W82

Tabla de contenidos

Otros manuales de Accesorios de soldadura de ESAB

ESAB

ESAB PSF 305 Manual de usuario

ESAB

ESAB SDE-250 Manual de usuario

ESAB

ESAB EFU 30 Manual de usuario

ESAB

ESAB PSF 260 Manual de usuario

ESAB

ESAB A2 S GMAW Mini Master Manual de usuario

ESAB

ESAB A6 Mastertrac Manual de usuario

ESAB

ESAB PSF 250 Manual de usuario

ESAB

ESAB Cigweld ProGuard Manual de usuario

ESAB

ESAB PT-31XL Manual de usuario

ESAB

ESAB CIGWELD 454342 Manual de usuario

ESAB

ESAB Eye-Tech 9-13 Manual de usuario

ESAB

ESAB ET 17 Manual de usuario

ESAB

ESAB MT-400EHD Manual de usuario

ESAB

ESAB Eye-Tech 10-12 Select Manual de usuario

ESAB

ESAB SAVAGE A40 Manual de usuario

ESAB

ESAB TIGAID315 AC/DC Manual de usuario

ESAB

ESAB Arc Master ICE A6 S Manual de usuario

ESAB

ESAB PREST-O-LITE PZ-503 Manual de usuario

ESAB

ESAB WeldCloud Mobile Manual de usuario

ESAB

ESAB EDB-15/30 Manual de usuario

ESAB

ESAB SAVAGE A40 Manual de usuario

ESAB

ESAB SDF-50 Manual de usuario

ESAB

ESAB PSF 260C Manual de usuario

ESAB

ESAB PC-900 Manual de usuario

Manuales populares de Accesorios de soldadura de otras marcas

Lincoln Electric

Lincoln Electric LT-7 Tractor Manual de usuario

Weco

Weco Trolley R Manual de usuario

Cornwell Tools

Cornwell Tools MMWC1 Manual de usuario

Dohle

Dohle ExOn2A Manual de usuario

Nederman

Nederman Fume Eliminator FE 840/2500/P150 Manual de usuario

3M Speedglas 9100 Series Manual de usuario

Miller Electric

Miller Electric OM-842 Manual de usuario

Miller

Miller A-200 Series Manual de usuario

Abicor Binzel

Abicor Binzel ABIMIG WT Series Manual de usuario

optrel

optrel lifeflip autopilot Manual de usuario

Miller

Miller MIGmatic M-25 Manual de usuario

Tregaskiss

Tregaskiss TOUGH GUN TT3 Reamer Manual de usuario

Abicor Binzel

Abicor Binzel xFUME PRO Manual de usuario

Sealey

Sealey SR20.V2 Manual de usuario

iWeld

iWeld NORED EYE Manual de usuario

Sthor

Sthor 74483 Manual de usuario

Leister

Leister TWINNY T7 Manual de usuario

Miller

Miller I-22 CE Manual de usuario
