EPOX MVP4A Manual de usuario

TRADEMARK

All products and company names are trademarks or registered

trademarks of their respective holders.

These specifications are subjected to change without notice.

Manual Revision 3.1

June 21, 1999

MVP4A

ISA/PCI Motherboard with Onboard AGP

VGA PCI Audio, PCI IDE and Super

Multi-I/O

FeaturesMVP4A

Page 2

FEATURES

MVP4A Features:

•Intel Pentium®Processor, Pentium Processor with MMX technology, AMD

K5/K6, Cyrix 6x86L/6x86MX & idt C6 operating at 133 ~ 450 MHz with

321 ZIF socket 7 provides scalability to accept faster Processors in the

future.

•Designed with VIA MVP4 AGPset.

•Supports up to 384 MB of DRAM (minimum of 16 MB) on board, You can

use 168-pin DIMM x 3. It will automatically detect Extended Data Output

(EDO) DRAM at 66MHz only or Synchronous DRAM memory (SDRAM) at

66MHz or 100MHz.

•Supports (2) 16 bit ISA slots, (4) 32 bit PCI slots, and provides (2) independent

high performance PCI IDE interfaces capable of supporting PIO Mode 3/4

and Ultra DMA 33/66 devices. The MVP4A supports (4) PCI Bus Master

slots and a jumperless PCI INT# control scheme which reduces configuration

confusion when plugging in PCI card(s).

•Supports ATAPI (e.g. CD-ROM) devices on both Primary and Secondary IDE

interfaces.

•Designed with lntegrated Multi I/O: (1) floppy port, (1) parallel port (EPP,

ECP), and (2) serial ports (16550 Fast UART).

Note: Japanese “Floppy 3 mode” is also supported

•Features Award Plug & Play BIOS. With Flash Memory you can always

upgrade to the current BIOS as they are released. (http://www.2themax.com

please visit our Technical Support section for the latest updates).

•MVP4A utilizes a Lithium battery which provides environmental protection

and longer battery life.

•Software power-down when using Windows®95/98.

•Supports ring-in feature (remote power-on through external modem,

allows system to be turned on remotely).

Features MVP4A

Page 3

• Resume by Alarm - Allows your system to turn on at a preselected time.

•Supports CPU Hardware sleep and SMM (System Management Mode).

• Supports Keyboard power ON function (KBPO).

• Supports USDM software to offer motherboard various status.

• Supports the CPU and Chassis fan Auto stop in sleep mode.

• Built-in WOL (Wake On Lan) Connector.

• Built-in Sound Blaster compatible/DirectSound AC97 Audio.

• Built-in AGP 2D/3D Graphics Accelerator.

Installation MVP4A

Page 4

Figure 1

MVP4A Detailed Layout

PCI Slot #2

PCI Slot #3

PCI Slot #4

ISA Slot #1

Battery

VIA

VT8501

VIA

VT82C686A

COM 1

USB

VGA

Parallel Port

USB 1

(Top)

Mouse

(Top)

USB 0

(Bottom)

PS/2 Keyboard

(Bottom)

IDE1

Secondary IDE

FDD1

Flash Memory

for BIOS

J7:WOL

Game Port

SOCKET 7

JP4

DIMM 3 Bank 2

DIMM 2 Bank 1

DIMM 1 Bank 0

CPU FAN

ISA Slot #2

PCI Slot #1

JP3

POWER_ON/OFF

SPK

Power LED

RESET

IR CONN.

Chassis FAN

JP1

COM2

USB CONN.

CD1

AUX1

IDE2

PW1

InstallationMVP4A

Page 5

Easy Installation Procedure

The following must be completed before powering on your new system:

Configure Jumpers

System Memory Configuration

Device Connectors

Configure Jumpers

We design this motherboard with the fewest jumpers to make your install fast and

easy.

The following will describe all of the jumpers that you are required to set before

moving on to step 2.

Note: The jumpers as depicted as shown (Figure 1) in their correct physical

orientation.

JP4 Disabled(Default)

Enabled

Keyboard Power-ON function (refer to the section 3-4)

JP4 = 1-2 -

= 2-3 -

J7 WOL (Wake On Lan) Connector

Reserved for NIC (Network Interface Card) to

Wake the System.

JP1 = 1-2 - Run Mode (Default)

= 2-3 - Clear CMOS (momentarily)

JP1 CMOS Clear

Installation MVP4A

Page 6

SW1: CPU Vcore Voltage Selection

1234

SW 1 CPU

Vcore

2345

ON 1.8V

2.0V

2.1V

ONON ON

2.2V

2.3V

2.4V

3.2V

2.9V

2.8V

ONON ON ON

XMM/muitneP 6K/5KDMA 6C-TDI

3PJ

MBI/xiryC IIM/XM68x6

reilpitluMkcolCsuB

zHM661

X5.2

zHM66002RP

zHM57332RP

zHM38662RP

zHM59003RP

zHM052zHM001663RP

ZHM002

zHM66662RP

zHM57003RP

zHM052zHM38333RP

zHM59004RP*

zHM003zHM001334RP*

zHM332

X5.3

zHM66003RP

zHM57333RP

zHM38004RP*

zHM333zHM59664RP*

zHM053zHM001005RP*

zHM662

zHM66333RP

zHM57004RP

zHM333zHM38664RP*

zHM083zHM59335RP*

zHM004zHM001055RP*

zHM003

X5.4

zHM66

zHM054zHM001

zHM333

zHM66

zHM574zHM59

zHM005zHM001

zHM663X5.5zHM66

JP3: CPU Speed Selection

ESDJ

* Reserved

InstallationMVP4A

Page 7

System Memory Configuration

Memory Layout

The MVP4A supports (3) 168-pin DIMMs (Dual In-line Memory Module). The

DIMMs can be either EDO (Extended Data Out) or SDRAM (Synchronized

DRAM). The DIMMs may be installed using just one chip.

•We recommend using SDRAM DIMM can not mixing

with EDO DIMM modules.

• DIMM SDRAM may be 83MHz (-12ns), 100MHz (-10ns) or

125MHz (-8ns) bus speed.

• No Registered DIMM support.

Figure 2 and Table 1 show several possible memory configurations using

* SDRAM only supports 8, 16, 32, 64, 128MB DIMM modules.

* We recommend to use PC100 Memory Module for bus speed between 100MHz

and 66MHZ.

DIMM 1

DIMM 2

Bank 0

Bank 1 -Synchronous

-EDO

DIMM 3

Bank 2

yromeMlatoT 1MMID )0knaB( 2MMID )1knaB( 3MMID )2knaB(

BM821= mumixaM

*MARDS/ODE ,BM23,BM61,BM8 1XBM821,BM46 enoNenoN

BM652=

mumixaM

*MARDS/ODE

,BM23,BM61,BM8

1XBM821,BM46

*MARDS/ODE

,BM23,BM61,BM8

1XBM821,BM46 enoN

BM483=

mumixaM

*MARDS/ODE

,BM23,BM61,BM8

1XBM821,BM46

*MARDS/ODE

,BM23,BM61,BM8

1XBM821,BM46

*MARDS/ODE

,BM23,BM61,BM8

1XBM821,BM46

Table 1

Installation MVP4A

Page 8

Device Connectors

Please install the motherboard into the chassis.

Now that your motherboard is installed you are ready to connect all your connections

(figure 6).

J4: CPU Fan Power

• A plug-in for the CPU Fan Power

J6: Chassis Fan Power

• A plug-in for the chassis Fan Power

J7: WOL (Wake On Lan) Connector

PW1: ATX Power Connector

• 20-pin power connector

J2,J3: Chassis Panel Connector

• Power_LED, Speaker, Reset, Sleep, Turbo LED and HDD LED

IDE1: Primary IDE Connector

IDE2: Secondary IDE Connector

FDD1: Floppy Controller Connector

CD1: CD-ROMAudio_in

AUX1: AUXAudio_in

COM2:RS232 COM2 Connector

USB CONN.: The third and fourth USB port (cable optional)

PS/2 Mouse

PS/2

KEYBOARD

COM1 VGA1

parallel port

Speaker

Joystick/Midi port

USB port

Line_in

MIC

Figure 6

InstallationMVP4A

Page 9

Device Connectors (continued)

(This is connected to the power button on the case. Using the

Soft-Off by Pwr-BTTN feature, you can choose either Instant

Off (turns system off immediately), or 4 sec delay (you need to

hold the button down for 4 seconds before the system turns off).

When the system is in 4 sec delay mode, there is a special feature

to make the system to go into suspend mode when the button is

pressed momentarily.)

Turbo LED indicator - LED ON when higher speed is selected

IDE LED indicator - LED ON when Onboard PCI IDE Hard

disks is activate

J3 1

IR Connector

1. VCC 4. GND

2. NC 5. IRTX

3. IRRX

Power On/Off

Speaker - Connect to the system's speaker for beeping

1. Speaker 3. GND

2. N/C 4. GND

Reset - Closed to restart system.

Power LED - Power LED connector

1. Power LED(+) 4. NC

2. N/C 5. GND

3. GND
