Quick Installation Guide

ECB300 802.11b/g/n Wireless Client Bridge

Please verify contents of the box before continuing to set up the ECB300.

ECB300 * 1

12V/1A 100V~240V Power Adaptor * 1

RJ-45 Ethernet Cable * 1

Detachable Antenna * 2

CD with User's Manual * 1

Quick Installation Guide * 1

Hardware Installation

1) Ensure that the computer in use has an Ethernet Card (RJ-45 Ethernet Port). For more information,

verify with User Manual.

2) Connect one end of the Category 5e Ethernet cable into RJ-45 port of the ECB300 and the other

end to the RJ-45 port on the computer that will use the ECB300. Ensure that the cable is securely

connected to both the ECB300 and the Computer.

3) Connect the Power Adaptor DC Inlet to the DC-IN port of the ECB300 and the Power Adaptor to

the electrical out.

IP address configuration

1) After ensuring the EnGenius device is powered on and plugged in, ensure that your computer is

on.

2) For the next steps, refer to your Operating System User Manual.

3) Once your computer is on, ensure that your TCP/IP is set to On or Enabled. (In the control panel,

double click Network Connections and then double click on the connection of your Network

Interface Card (NIC). Select Internet Protocol (TCP/IP) and then click on the Properties button.)

4) If your PC is already on a computer network, ensure that you have set it to a Static IP Address on

the interface (or Ethernet card that will use the ECB300) as 192.168.1.21 and the Subnet Mask

6709A0213740

address as 255.255.255.0. (Select Use the following IP Address radio button). Once the

computer has been prepared, proceed to setting up the ECB300.

ECB300 Setup

1) To configure ECB300, open a web browser (example: Microsoft Internet Explorer, Mozilla Firefox,

Google Chrome, etc.).

2) In the address bar of the web browser, enter 192.168.1.1 (the default IP address of the ECB300)

and hit enter.

3) A login screen will appear. By default, the username of the ECB300 is admin and the password is

admin. Enter the current username and password of the ECB300 and then click Login. Refer to

the ECB300 user manual on how to change the

username and password.

4) After clicking Login with the correct username and

password, the ECB300 Main Menu will appear. If you are

successful, proceed to setting up the wireless connection.

Switching Between Operating Modes

This device can operate in the following modes: Access Point, Client Bridge, WDS, Repeater, AP Router.

1) Click on the Operation Mode link under the System navigation drop-down menu.

2) Operating Mode: Select an operating mode from the list (Access Point, Client Bridge, or Repeater)

and then click on the Apply button.

3) All basic setup is completed. Note: The wireless connection is not secure. To setup security on the

ECB300, refer to the ECB300 User Manual.

http://192.168.1.1
