EOC-2610

Long Range Wireless

Access Point / Client Bridge

2.4GHz

108 Mbps

802.11b/g/Super G

Multi-function AP

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditions and

environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 20080930_V1.0

EOC-2610 is a long range outdoor wireless Access Point / Client Bridge that operates

seamlessly in the 2.4GHz frequency spectrum and provides high bandwidth up to 108Mbps

with Super G. It features high transmitted output power and high receivable sensitivity. High

output power and high sensitivity can extend range and coverage to reduce the roaming

between Access Points to get a more stable wireless connection. It also reduces the

expense of equipment in the same environment.

It supports distance control by 1km to 30km and RSSI indicator which enables the best

transmit and receive signals for traffic communication. This product comes with PoE injector

for building in outdoor environment easily.

To protect your wireless connectivity, it can encrypt all wireless transmissions through

64/128-bit WEP data encryption and also supports WPA/WPA2. The MAC address filter lets

you select exactly which stations should have access to your network. In addition, the User

Isolation function can protect the private network between client users.

The attractive design, high performance, and array of features make EOC-2610 a suitable

wireless solution for your residence or office.

Package Content

¾1* 802.11b/g Long range AP/CB (EOC-2610)

¾1* PoE Injector (EPE-1212)

¾1* Power Adaptor

¾1* CD with User’s Manual

¾1* QIG

¾1* Metal strap

¾1* Special screw set

Jia Ying Trading Pte Ltd

1 Rochor Canal Road #02-67/ 69/ 34-37 Sim Lim Square Singapore 188504

Tel:(+65) 6336 0404 Fax:(+65) 6338 0404

Website: www.jiaying.com Email: [email protected] / [email protected]

EOC-2610

Long Range Wireless

Access Point / Client Bridge

2.4GHz

108 Mbps

802.11b/g/Super G

Multi-function AP

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditions and

environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 20080930_V1.0

Features

Wireless

-2.4GHz It works in 2.4GHz frequency spectrum

-High output power Transmit output power programmable for different country selections

-High Data Rate High speed transmitting rate up to 108Mbps with Super G, support large payload such as MEPG

video streaming

-Multifunction application Access Point/Client Bridge/Client Router

-Long range transmitting Transmit power control and distance control (ACK timeout)

-Signal Strength LED indicators have the best transmit and receive signal for traffic communication

Networking

-Public wireless solution An AP interface that is especially useful in public areas such as hotspots and enterprise

-Signal Strength Display RF signal strength status shown LEDs of 3 colors, making network build-up easier

-QoS(WMM) Enhance performance and density

Security

-802.11i WEP, WPA, WPA2 (Encryption support TKIP/AES)

-MAC address functions MAC address filter (AP mode)

-802.1x IEEE802.1x Authencatior

-L2 isolation

-Station isolation

Management

-Firmware Upgrade Upgrading firmware via web browser, setting are reserved after upgrade

-Reset & Backup Reset to factory default. User can export all setting into a file via WEB

-MIB MIB I, MIB II(RFC1213)

-SNMP V1, V2c

Jia Ying Trading Pte Ltd

1 Rochor Canal Road #02-67/ 69/ 34-37 Sim Lim Square Singapore 188504

Tel:(+65) 6336 0404 Fax:(+65) 6338 0404

Website: www.jiaying.com Email: jiaying@singnet.com.sg / email@jiaying.com.sg

EOC-2610

Long Range Wireless

Access Point / Client Bridge

2.4GHz

108 Mbps

802.11b/g/Super G

Multi-function AP

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditions and

environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 20080930_V1.0

Technical Specifications

Hardware Specification

Physical Interface One 10/100 Fast Ethernet RJ-45

Reset Button

One SMA Connector

One switch (external and internal antenna switching)

LED indicators Power/ Status

LAN (10/100Mbps)

WLAN (Wireless is up)

3 x Link Quality (Client Bridge mode)

¾Green: Good Quality

¾Yellow: Marginally Acceptable Quality

¾Red: Bad Quality

Power Requirements Active Ethernet (Power over Ethernet) Proprietary PoE design

Power Adapter 24V / 0.8A DC

Regulation Certifications FCC Part 15C/15B, EN 300 328/EN 301 489-1/-17

RF Specification

Frequency Band 802.11b/g

2.412~2.472GHz

Modulation Technology OFDM = BPSK, QPSK, 16-QAM, 64-QAM

DSSS = DBPSK, DQPSK, CCK

Operating Channels 802.11b/g

11 for North America, 14 for Japan, 13 for Europe

Receive Sensitivity (Typical) 802.11g

-92 dBm @ 6Mbps

-74 dBm @ 54Mbp

802.11b

-97 dBm @ 1Mbps

-89 dBm @ 11Mbps

Available transmit power

(Average power) FCC ETSI

Jia Ying Trading Pte Ltd

1 Rochor Canal Road #02-67/ 69/ 34-37 Sim Lim Square Singapore 188504

Tel:(+65) 6336 0404 Fax:(+65) 6338 0404

Website: www.jiaying.com Email: jiaying@singnet.com.sg / email@jiaying.com.sg

EOC-2610

Long Range Wireless

Access Point / Client Bridge

2.4GHz

108 Mbps

802.11b/g/Super G

Multi-function AP

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditions and

environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 20080930_V1.0

Frequency Power Frequency Power

2.412~2.462

GHz

IEEE802.11g

26dBm@6~24Mbps

25dBm@36Mbps

23dBm@48Mbps

22dBm@54Mbps

2.412~2.472

GHz

IEEE802.11g

26dBm@6~24Mbps

25dBm@36Mbps

23dBm@48Mbps

22dBm@54Mbps

2.412~2.462

GHz

IEEE802.11b

27dBm@1~11Mbps

2.412~2.472

GHz

IEEE802.11b

27dBm@1~11Mbps

ToleranceġƲ1 dBm ToleranceġƲ1 dBm

Internal Antenna Embedded 10dBi Panel antenna

External Antenna 1* SMA connector

Software Features

General

Topology Infrastructure

Protocol / Standard IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet)

IEEE 802.11b/g (2.4GHz WLAN)

Operation Mode 802.11 b/g

Access Point

Client Bridge

Client Router

LAN DHCP Server

DHCP Client

VPN VPN – pass through

Wireless Channel Selection (Setting varies by countries)

Transmission Rate

11 b/gǺ54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 Mbps

Super G : 108 Mbps

Long distance transmission : 1km to 30km

Jia Ying Trading Pte Ltd

1 Rochor Canal Road #02-67/ 69/ 34-37 Sim Lim Square Singapore 188504

Tel:(+65) 6336 0404 Fax:(+65) 6338 0404

Website: www.jiaying.com Email: jiaying@singnet.com.sg / email@jiaying.com.sg

EOC-2610

Long Range Wireless

Access Point / Client Bridge

2.4GHz

108 Mbps

802.11b/g/Super G

Multi-function AP

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditions and

environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 20080930_V1.0

Transmit power table

Signal Strength indication using LEDs

PPPoE(CR mode)

Security WEP Encryption-64/128/152 bit

WPA/WPA2 Personal (WPA-PSK using TKIP or AES)

WPA/WPA2 Enterprise (WPA-EAP using TKIP)

802.1x Authenticator

Hide SSID in beacons

802.1Q VLAN

MAC address filtering, up to 50 field

L2 isolation(AP mode)

Wireless STA (Client) connected list

Web-redirect

QoS WMM

Management

Configuration Web-based configuration (HTTP)

Firmware Upgrade - Upgrade firmware via web-browser

- Keep latest setting when f/w update

Administrator Setting Administrator password change

Reset Setting - Reboot (Press 1 second)

- Reset to Factory Default (Press 5 seconds)

System monitoring Status, Event Log

SNMP V1, V2c

MIB MIB I, MIB II (RFC1213) and Private MIB

Backup & Restore Settings through Web

Time setting NTP (Auto-setting of time)

Time setting manually

Environment & Mechanical

Temperature Range Operating -20°C~70°C

Storage -30°C to 80°C

Jia Ying Trading Pte Ltd

1 Rochor Canal Road #02-67/ 69/ 34-37 Sim Lim Square Singapore 188504

Tel:(+65) 6336 0404 Fax:(+65) 6338 0404

Website: www.jiaying.com Email: jiaying@singnet.com.sg / email@jiaying.com.sg

EOC-2610

Long Range Wireless

Access Point / Client Bridge

2.4GHz

108 Mbps

802.11b/g/Super G

Multi-function AP

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditions and

environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 20080930_V1.0

Humidity (non-condensing) 0%ɴ90% typical

Dimensions 260mm (L) x 84mm (W) x 55mm (H)

Weight 300g

Jia Ying Trading Pte Ltd

1 Rochor Canal Road #02-67/ 69/ 34-37 Sim Lim Square Singapore 188504

Tel:(+65) 6336 0404 Fax:(+65) 6338 0404

Website: www.jiaying.com Email: jiaying@singnet.com.sg / email@jiaying.com.sg

EOC-2610

Long Range Wireless

Access Point / Client Bridge

2.4GHz

108 Mbps

802.11b/g/Super G

Multi-function AP

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditions and

environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 20080930_V1.0

Application

Access Point + Client Bridge scenario

Long Range Transmitting



Jia Ying Trading Pte Ltd

1 Rochor Canal Road #02-67/ 69/ 34-37 Sim Lim Square Singapore 188504

Tel:(+65) 6336 0404 Fax:(+65) 6338 0404

Website: www.jiaying.com Email: jiaying@singnet.com.sg / email@jiaying.com.sg

EOC-2610

Long Range Wireless

Access Point / Client Bridge

2.4GHz

108 Mbps

802.11b/g/Super G

Multi-function AP

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditions and

environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 20080930_V1.0

Product ID & Mounting Base

Front Rear

Jia Ying Trading Pte Ltd

1 Rochor Canal Road #02-67/ 69/ 34-37 Sim Lim Square Singapore 188504

Tel:(+65) 6336 0404 Fax:(+65) 6338 0404

Website: www.jiaying.com Email: jiaying@singnet.com.sg / email@jiaying.com.sg

EOC-2610

Long Range Wireless

Access Point / Client Bridge

2.4GHz

108 Mbps

802.11b/g/Super G

Multi-function AP

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g chipset used. Actual throughput may vary. Network conditions and

environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 20080930_V1.0

Standard Mountin

Kits Optional mountin

kits

Window

mount

Wall

mount

Pole mount



Jia Ying Trading Pte Ltd

1 Rochor Canal Road #02-67/ 69/ 34-37 Sim Lim Square Singapore 188504

Tel:(+65) 6336 0404 Fax:(+65) 6338 0404

Website: www.jiaying.com Email: jiaying@singnet.com.sg / email@jiaying.com.sg

Otros manuales para EOC-2610

Tabla de contenidos

Otros manuales de Punto de acceso inalámbrico de EnGenius

EnGenius

EnGenius Wireless Outdoor Access Point & Client... Manual de usuario

EnGenius

EnGenius M8000 Manual de usuario

EnGenius

EnGenius EOC-2610 Manual de usuario

EnGenius

EnGenius ENH1750EXT Manual de usuario

EnGenius

EnGenius EWS650AP Manual de usuario

EnGenius

EnGenius EW310AP Manual de usuario

EnGenius

EnGenius EWS370AP Manual de usuario

EnGenius

EnGenius ENH202 Manual de usuario

EnGenius

EnGenius ENH900EXT Manual de usuario

EnGenius

EnGenius ETR9330 Manual de usuario

EnGenius

EnGenius EOA3630 Manual de usuario

EnGenius

EnGenius ENH200 Manual de usuario

EnGenius

EnGenius ENH210EXT Manual de usuario

EnGenius

EnGenius EAP1750H Manual de usuario

EnGenius

EnGenius ECB9500 Manual de usuario

EnGenius

EnGenius EAP900H Manual de usuario

EnGenius

EnGenius EnStation6 Manual de usuario

EnGenius

EnGenius EAP350 Manual de usuario

EnGenius

EnGenius EAP300 Manual de usuario

EnGenius

EnGenius ECB3500 Manual de usuario

EnGenius

EnGenius EOC1650 Manual de usuario

EnGenius

EnGenius X-TRA RANGE ERB300H Manual de usuario

EnGenius

EnGenius EOC-8610 Series Manual de usuario

EnGenius

EnGenius EnStation 6 Manual de usuario

Manuales populares de Punto de acceso inalámbrico de otras marcas

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manual de usuario

Ubiquiti

Ubiquiti NanoStation NSM2 Manual de usuario

Cisco

Cisco Aironet 1550 Series Manual de usuario

Aruba

Aruba IAP-335 Manual de usuario

Advantek Networks

Advantek Networks AWN-AP-54MR Manual de usuario

IP-COM

IP-COM AP355 Manual de usuario

Buffalo

Buffalo AirStation WLA-L11G Manual de usuario

D-Link

D-Link DAP-3662 Manual de usuario

xG Technology

xG Technology xMax CN1300 Manual de usuario

Widelink

Widelink ezWave WAP-1100 Series Manual de usuario

Edimax

Edimax CAP1200 Manual de usuario

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manual de usuario

Aruba

Aruba AP-203R Manual de usuario

LuXout Shades

LuXout Shades LUXSHADE MOTION Manual de usuario

CreatComm

CreatComm TB5F Manual de usuario

SineDigital

SineDigital MW-1500AP(H) Manual de usuario

TP-Link

TP-Link AP9650 V1 Manual de usuario

Draytek

Draytek VIGORAP 902 Manual de usuario
