EnGenius EOA7530 Manual de usuario

EOA7530 Dual Radio Concurrent AP/CB

• 2.4GHz / 5GHz

• 54Mbps

• 802.11a/b/g

• Flexible Application



PRODUCT DESCRIPTION

EOA7530 equips with two powerful independent RF interfaces which support

802.11a and 802.11b/g. With certified IP-65 protection, it is designed to deliver

high reliability under harsh outdoor environment.

Built-in advanced multi-functions provide flexibility in constructing scalable

WiFi networks for all possible applications. With two individual interfaces, each

can be configured into 3 different modes with maximum of 5 combinations.

EOA7530 offers bandwidth up to 54Mbps to accommodate heavy traffic

services such as multimedia streaming. Establishing backbone network using

802.11a ensures stability and reduces interference while 802.11b/g offers

great compatibility to all wireless clients.

EOA7530 provides wide-range of authentication and encryption standards

(including WEP, WPA, WPA2, TKIP/AES and IEEE 802.1X) to enforce

maximum security. Furthermore, friendly security management user interface

reduces configuration complexity. EOA7530 is a true carrier-grade product

which is guaranteed to fulfill any business proposals.

Package Content

→1 x Dual Radio Concurrent AP (EOA7530)

→1 x PoE injector with Power Adapter(48V)

→1 x Mounting kit

→1 x Grounding Cable

→1 x CD with User’s Manual

→1 x QIG

→2 x N-type Dual Band Omni Antenna

Learn more about EnGenius Solutions at www.engeniustech.com.sg

BUSINESS CLASS

EOA7530

EOA7530 Datasheet Version 03172010

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

FEATURES

Wireless

- Dual Radio Two radio ( a, radio1 and b/g, radio2 ) for independent application

- High Data Rate High speed physical transmitting rate up to 54Mbps, support large payload such as MPEG video streaming

- Multifunction application 8 Modes (AP-AP, AP-CB, AP-CR, CB-AP, CR-AP, AP Concurrent, CB Concurrent, CR Concurrent)

- Signal Strength Display Show the signal condition for more convenient installation and setup.

- QoS(WMM) Enhance performance and density

- BSSID Basic Service Set ID

- Multiple SSID 4 BSSID supported. Primary (1st) BSSID for normal setting follow this router’s main default setting for security setting.

Each SSID can set itself wireless or WAN access setting.

Networking

- PPPoE Point-to-Point Protocol over Ethernet at Client Router mode. This function will keep trying when failed or disconnected

- PPTP The Point-to-Point Tunneling Protocol (PPTP) is a method for implementing virtual private networks

- VPN Pass Through

Security

- 802.11i WEP, WPA-PSK(TKIP or AES), WPA2

- 802.1x 802.1x Authenticator, EAP-TLS/TTLS

- MAC address functions MAC address access control list, MAC address filter

Management

- Firmware Upgrade Upgrading firmware via web browser, setting are reserved after upgrade

- Reset & Backup Reset to factory default. User can export all setting into a file via WEB

- Telnet teletype network provides a bidirectional interactive communications facility to easy uesr to communicate with network

device.

- MIB MIB I, MIB II(RFC1213) and private MIB

- SNMP V1, V2c

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOA7530

BUSINESS CLASS

EOA7530

EOA7530 Datasheet Version 03172010

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

TECHNICAL SPECIFICATIONS

> Hardware Specification

MCU Atheros AR7161

RF Atheros AR5413 (Radio1) + Atheros AR5413 (Radio2)

Memory 64MB DDR RAM

Flash 8MB

Physical Interface 1 x RJ-45 : 10/100 Fast Ethernet

1 x Reset Button

Power Requirements Power over Ethernet, 48V DC

Regulation Certifications FCC Part 15C/15B/15E, EN301 893, EN 300 328, EN 301 489-1/-17, EN60950

> RF Specification

Frequency Band 802.11a

5.15 ~ 5.35GHz,

5.47 ~ 5.725GHz, 5.725~5.825GHz

802.11b/g

U.S., Europe and Japan product covering 2.400 to 2.484 GHz, programmable for different

country regulations

Modulation Technology OFDM = BPSK, QPSK, 16-QAM, 64-QAM

DSSS = DBPSK, DQPSK, CCK

Operating Channels 802.11a

US/Canada:12 non-overlapping channel (5.15~5.35GHz, 5.725~5.825GHz)

Europe:19 non-overlapping channel (5.15~5.35GHz, 5.47~5.825GHz)

Japan:4 non-overlapping channel (5.15~5.25GHz)

China:5 non-overlapping channel (5.725~5.85GHz)

802.11b/g

11 for North America, 14 for Japan, 13 for Europe

Receive Sensitivity (Typical) 802.11a

-92dBm @ 6Mbps,

-73dBm @ 54Mbps

802.11g

-94 dBm @ 6Mbps,

-74 dBm @ 54Mbp

802.11b

-97 dBm @ 1Mbps

-92 dBm @ 11Mbps

Available transmit power Radio 1 (WLAN1)

FCC ETSI

Frequency Power Frequency Power

5.150~5.350 GHz

IEEE802.11a

28dBm@6~24Mbps

26dBm@36Mbps

24dBm@48Mbps

22dBm@54Mbps

5.150~5.350 GHz

IEEE802.11a

28dBm@6~24Mbps

26dBm@36Mbps

24dBm@48Mbps

22dBm@54Mbps

5.470~5.725 GHz

IEEE802.11a

28dBm@6~24Mbps

26dBm@36Mbps

24dBm@48Mbps

22dBm@54Mbps

5.470~5.725 GHz

IEEE802.11a

28dBm@6~24Mbps

26dBm@36Mbps

24dBm@48Mbps

22dBm@54Mbps

5.725~5.825 GHz

IEEE802.11a

28dBm@6~24Mbps

26dBm@36Mbps

24dBm@48Mbps

22dBm@54Mbps

5.725~5.825 GHz

IEEE802.11a

28dBm@6~24Mbps

26dBm@36Mbps

24dBm@48Mbps

22dBm@54Mbps

Radio 2 (WLAN2)

FCC ETSI

Frequency Power Frequency Power

2.412~2.462 GHz

IEEE802.11g

28dBm@6~24Mbps

26dBm@36Mbps

25dBm@48Mbps

24dBm@54Mbps

2.412~2.472 GHz

IEEE802.11g

28dBm@6~9Mbps

26dBm@12~18Mbps

25dBm@24~36Mbps

24dBm@48~54Mbps

2.412~2.462 GHz

IEEE802.11b 29dBm@1~11Mbps 2.412~2.472 GHz

IEEE802.11b 29dBm@1~11Mbps

Antenna 2 x N-Type Connector for 802.11a & 802.11b/g

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOA7530

BUSINESS CLASS

EOA7530

EOA7530 Datasheet Version 03172010

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

SOFTWARE FEATURES

> General

Topology Infrastructure

Protocol / Standard IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet)

IEEE 802.11a (5GHz WLAN)

IEEE 802.11b/g (2.4GHz WLAN)

Operation Mode Access Point ( Radio1 ) – Access Point ( Radio2 )

Access Point ( Radio1 ) – Client Bridge ( Radio2 )

Client Bridge ( Radio1 ) – Access Point ( Radio2 )

Access Point ( Radio1 )– Client Router ( Radio2 )

Client Router ( Radio1 ) – Access Point ( Radio2 )

AP Concurrent

CB Concurrent

CR Concurrent

LAN DHCP Server(AP mode)

DHCP Client(CR mode)

Wireless Auto Channel Selection (Setting varies by Regular Domains)

Transmission Rate

- 11 a/g：54, 48, 36, 24, 18, 12, 9, 6 Mbps

- 11b : 11, 5.5, 2, 1 Mbps

Distance Control (802.1x Ack timeout)

Bandwidth Selection

Multiple SSID (4 SSID)

VLAN

WDS AP/WDS Bridge

Security Authentication:

- 802.11i (WPA, WPA2)

- 802.1x (including EAP-TLS/TTLS)

IEEE 802.1x Supplicant support in CB mode

Encryption: Open, WEP-64/128, TKIP, AES

MAC address access control list

Hide SSID in beacons

User Isolation

MAC address Filtering

NAT in Client Router mode

QoS WMM

> Management

Configuration Web-based configuration (HTTP)/Telnet

Firmware Upgrade Upgrade firmware via web browser

Fix latest setting parameter when firmware upgrading

Administrator Setting Administrator password can be changed

System monitoring Status in hand , useful statistic and Event log

Reset Setting Reset to factory default and reboot

MIB MIB I , MIB II(RFC1213) and Private MIB

SNMP V1 , V2c

Backup Save all setting and condition to a file by web

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOA7530

BUSINESS CLASS

EOA7530

EOA7530 Datasheet Version 03172010

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g,chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

ENVIRONMENT AND MECHANICAL

Temperature Range Operating -20°C~70°C

Storage -30°C to 80°C

Humidity (non-condensing) 0%～95% typical

Dimensions 260mm (L) x 175mm (W) x 65mm (H)

Weight 730g

V2.0

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOA7530

BUSINESS CLASS

EOA7530

EOA7530 Datasheet Version 03172010

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g chipset used. Actual throughput may vary.Network conditions and environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice
