Brief Operating Instructions

Proline 100

Modbus RS485

Transmitter with

Coriolis sensor

These instructions are Brief Operating Instructions; they are

not a substitute for the Operating Instructions pertaining to

the device.

Transmitter Brief Operating Instructions

Contain information about the transmitter.

Sensor Brief Operating Instructions →  3

KA01335D/06/EN/01.17

71377320

Proline 100 Modbus RS485

2 Endress+Hauser

Order code:

Ext. ord. cd.:

Ser. no.:

www.endress.com/deviceviewer Endress+Hauser

Operations App

XXXXXXXXXXXX

XXXXX-XXXXXX

XXX.XXXX.XX

Serial number

A0023555

Proline 100 Modbus RS485 Brief Operating Instructions for the device

Endress+Hauser 3

Brief Operating Instructions for the device

The device consists of a transmitter and a sensor.

The process of commissioning these two components is described in two separate manuals:

• Sensor Brief Operating Instructions

• Transmitter Brief Operating Instructions

Please refer to both Brief Operating Instructions when commissioning the device as the

contents of the manuals complement one another:

Sensor Brief Operating Instructions

The Sensor Brief Operating Instructions are aimed at specialists with responsibility for

installing the measuring device.

• Incoming acceptance and product identification

• Storage and transport

• Installation

Transmitter Brief Operating Instructions

The Transmitter Brief Operating Instructions are aimed at specialists with responsibility for

commissioning, configuring and parameterizing the measuring device (until the first

measured value).

• Product description

• Installation

• Electrical connection

• Operation options

• System integration

• Commissioning

• Diagnostic information

Additional device documentation

These Brief Operating Instructions are the Transmitter Brief Operating Instructions.

The "Sensor Brief Operating Instructions" are available via:

• Internet: www.endress.com/deviceviewer

• Smart phone/tablet: Endress+Hauser Operations App

Detailed information about the device can be found in the Operating Instructions and the

other documentation:

• Internet: www.endress.com/deviceviewer

• Smart phone/tablet: Endress+Hauser Operations App

Table of contents Proline 100 Modbus RS485

4 Endress+Hauser

Table of contents

1 Document information ............................................................ 5

1.1 Symbols used ......................................................................... 5

2 Basic safety instructions .......................................................... 7

2.1 Requirements for the personnel ............................................................ 7

2.2 Designated use ........................................................................ 7

2.3 Workplace safety ...................................................................... 8

2.4 Operational safety ......................................................................8

2.5 Product safety ......................................................................... 8

2.6 IT security ............................................................................ 9

3 Product description ............................................................... 9

4 Installation ....................................................................... 9

4.1 Mounting the measuring device ............................................................9

5 Electrical connection ............................................................ 11

5.1 Connection conditions .................................................................. 11

5.2 Connecting the measuring device ......................................................... 17

5.3 Special connection instructions ........................................................... 20

5.4 Hardware settings ..................................................................... 21

5.5 Ensuring the degree of protection ......................................................... 23

5.6 Post-connection check ..................................................................23

6 Operation options ............................................................... 24

6.1 Overview of operating options ............................................................ 24

6.2 Structure and function of the operating menu ................................................ 25

6.3 Access to the operating menu via the operating tool ............................................ 26

7 System integration .............................................................. 30

8 Commissioning .................................................................. 30

8.1 Function check ....................................................................... 30

8.2 Setting the operating language ........................................................... 30

8.3 Configuring the measuring device ......................................................... 30

8.4 Protecting settings from unauthorized access ................................................. 31

9 Diagnostic information .......................................................... 31

Proline 100 Modbus RS485 Document information

Endress+Hauser 5

1 Document information

1.1 Symbols used

1.1.1 Safety symbols

Symbol Meaning

DANGER

DANGER!

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in

serious or fatal injury.

WARNING

WARNING!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

serious or fatal injury.

CAUTION

CAUTION!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

minor or medium injury.

NOTICE

NOTE!

This symbol contains information on procedures and other facts which do not result in

personal injury.

1.1.2 Symbols for certain types of information

Symbol Meaning Symbol Meaning

Permitted

Procedures, processes or actions that

are permitted.

Preferred

Procedures, processes or actions that

are preferred.

Forbidden

Procedures, processes or actions that

are forbidden.

Tip

Indicates additional information.

Reference to documentation

Reference to page

Reference to graphic

… Series of steps

Result of a step Visual inspection

1.1.3 Electrical symbols

Symbol Meaning Symbol Meaning

Direct current Alternating current

Direct current and alternating current Ground connection

A grounded terminal which, as far as

the operator is concerned, is grounded

via a grounding system.

Document information Proline 100 Modbus RS485

6 Endress+Hauser

Symbol Meaning

Protective Earth (PE)

A terminal which must be connected to ground prior to establishing any other connections.

The ground terminals are situated inside and outside the device:

• Inner ground terminal: Connects the protectiv earth to the mains supply.

• Outer ground terminal: Connects the device to the plant grounding system.

1.1.4 Tool symbols

Symbol Meaning Symbol Meaning

Torx screwdriver Flat blade screwdriver

Cross-head screwdriver Allen key

Open-ended wrench

1.1.5 Symbols in graphics

Symbol Meaning Symbol Meaning

1, 2, 3,... Item numbers

… Series of steps

A, B, C, ... Views A-A, B-B, C-C, ... Sections

Hazardous area

Safe area (non-hazardous area)

Flow direction

Proline 100 Modbus RS485 Basic safety instructions

Endress+Hauser 7

2 Basic safety instructions

2.1 Requirements for the personnel

The personnel must fulfill the following requirements for its tasks:

‣Trained, qualified specialists must have a relevant qualification for this specific function

and task.

‣Are authorized by the plant owner/operator.

‣Are familiar with federal/national regulations.

‣Before starting work, read and understand the instructions in the manual and

supplementary documentation as well as the certificates (depending on the application).

‣Follow instructions and comply with basic conditions.

2.2 Designated use

Application and media

• The measuring device described in these Brief Operating Instructions is intended only for

flow measurement of liquids and gases.

• The measuring device described in these Brief Operating Instructions is intended only for

flow measurement of liquids.

Depending on the version ordered, the measuring device can also measure potentially

explosive, flammable, poisonous and oxidizing media.

Measuring devices for use in hazardous areas, in hygienic applications or where there is an

increased risk due to process pressure, are labeled accordingly on the nameplate.

To ensure that the measuring device remains in proper condition for the operation time:

‣Keep within the specified pressure and temperature range.

‣Only use the measuring device in full compliance with the data on the nameplate and the

general conditions listed in the Operating Instructions and supplementary documentation.

‣Based on the nameplate, check whether the ordered device is permitted for the intended

use in the hazardous area (e.g. explosion protection, pressure vessel safety).

‣Use the measuring device only for media to which the process-wetted materials are

sufficiently resistant.

‣If the measuring device is not operated at atmospheric temperature, compliance with the

relevant basic conditions specified in the associated device documentation is absolutely

essential: "Documentation" section.

‣Protect the measuring device permanently against corrosion from environmental

influences.

Incorrect use

Non-designated use can compromise safety. The manufacturer is not liable for damage caused

by improper or non-designated use.

LWARNING

Danger of breakage due to corrosive or abrasive fluids!

‣Verify the compatibility of the process fluid with the sensor material.

‣Ensure the resistance of all fluid-wetted materials in the process.

‣Keep within the specified pressure and temperature range.

Basic safety instructions Proline 100 Modbus RS485

8 Endress+Hauser

NOTICE

Verification for borderline cases:

‣For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in

verifying the corrosion resistance of fluid-wetted materials, but does not accept any

warranty or liability as minute changes in the temperature, concentration or level of

contamination in the process can alter the corrosion resistance properties.

Residual risks

LWARNING

The electronics and the medium may cause the surfaces to heat up. This presents a burn

hazard!

‣For elevated fluid temperatures, ensure protection against contact to prevent burns.

Only applies for Proline Promass E, F, O, X and Cubemass C

LWARNING

Danger of housing breaking due to measuring tube breakage!

‣In the event of a measuring tube breakage for a device version without rupture disk it is

possible for the pressure loading capacity of the sensor housing to be exceeded. This can

lead to rupture or failure of the sensor housing.

2.3 Workplace safety

For work on and with the device:

‣Wear the required personal protective equipment according to federal/national

regulations.

For welding work on the piping:

‣Do not ground the welding unit via the measuring device.

If working on and with the device with wet hands:

‣Due to the increased risk of electric shock, gloves must be worn.

2.4 Operational safety

Risk of injury.

‣Operate the device in proper technical condition and fail-safe condition only.

‣The operator is responsible for interference-free operation of the device.

2.5 Product safety

This measuring device is designed in accordance with good engineering practice to meet state-

of-the-art safety requirements, has been tested, and left the factory in a condition in which it

is safe to operate.

It meets general safety standards and legal requirements. It also complies with the EU

directives listed in the device-specific EU Declaration of Conformity. Endress+Hauser confirms

this by affixing the CE mark to the device.

Proline 100 Modbus RS485 Product description

Endress+Hauser 9

2.6 IT security

We only provide a warranty if the device is installed and used as described in the Operating

Instructions. The device is equipped with security mechanisms to protect it against any

inadvertent changes to the device settings.

IT security measures in line with operators' security standards and designed to provide

additional protection for the device and device data transfer must be implemented by the

operators themselves.

3 Product description

The device consists of a transmitter and a sensor.

The device is available as a compact version:

The transmitter and sensor form a mechanical unit.

Applies for Promass, Cubemass, CNGmass, LNGmass and LPGmass

If a device with Modbus RS485 intrinsically safe is ordered, the Safety Barrier Promass 100 is

part of the scope of supply and must be implemented to operate the device.

For detailed information on the product description, see the Operating Instructions for

the device

4 Installation

For detailed information about mounting the sensor, see the Sensor Brief Operating

Instructions →  3

4.1 Mounting the measuring device

4.1.1 Turning the display module

The local display is only available with the following device version:

Order code for "Display; operation", option B: 4-line; illuminated, via communication

The display module can be turned to optimize display readability.

Installation Proline 100 Modbus RS485

10 Endress+Hauser

Aluminum housing version

3 mm

A0023192

Compact and ultra-compact housing versions

3. 3.

8 mm

A0023195

Tabla de contenidos

Otros manuales de Accesorios de Endress+Hauser

Endress+Hauser

Endress+Hauser Indumax CLS54 Manual de usuario

Endress+Hauser

Endress+Hauser Oxymax H COS21 Manual de usuario

Endress+Hauser

Endress+Hauser CCS120D Manual de usuario

Endress+Hauser

Endress+Hauser Oxymax H COS21D Manual de usuario

Endress+Hauser

Endress+Hauser Prosonic S Series Manual

Endress+Hauser

Endress+Hauser Soliwave FQR56 Manual de usuario

Endress+Hauser

Endress+Hauser Ceramax CPS341D Manual de usuario

Endress+Hauser

Endress+Hauser Turbimax CUS50D Manual de usuario

Endress+Hauser

Endress+Hauser CCS50D Manual de usuario

Endress+Hauser

Endress+Hauser Oxymax COS61 Manual de usuario

Endress+Hauser

Endress+Hauser Prosonic S FDU91 Manual

Endress+Hauser

Endress+Hauser Micropilot M FMR230 Manual de usuario

Endress+Hauser

Endress+Hauser Deltapilot M FMB50 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Cleanfit P CPA472 Manual de usuario

Endress+Hauser

Endress+Hauser Levelflex FMP56 Manual de usuario

Endress+Hauser

Endress+Hauser Memosens COS81D Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag H Especificaciones técnicas

Endress+Hauser

Endress+Hauser omnigrad M TR 44 Manual

Endress+Hauser

Endress+Hauser Proline 800 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Cleanfit P CPA472D Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar S FMD 77 Manual

Endress+Hauser

Endress+Hauser NAR 300 Manual de usuario

Endress+Hauser

Endress+Hauser Chloromax CCS142D Manual de usuario

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario
