Operating Instructions

Condumax CLS15D/16D/21D

Sensors with Memosens protocol

For conductive measurement of conductivity in

liquids

BA01147C/07/EN/05.20

71464661

2020-01-31

EU Declaration of Conformity Condumax CLS15D/16D/21D

2 Endress+Hauser

EU Declaration of Conformity

ATEX / NEPSI II 1G Ex ia IIC T3/T4/T6 Ga, IECEx Ex ia IIC T3/T4/T6 Ga

Condumax CLS15D/16D/21D EU Declaration of Conformity

Endress+Hauser 3

ATEX/NEPSI II 3G Ex ic IIC T3/T4/T6 Gc

Table of contents Condumax CLS15D/16D/21D

4 Endress+Hauser

Table of contents

1 About this document ........... 5

1.1 Warnings ........................... 5

1.2 Symbols ............................ 5

2 Basic safety instructions ....... 6

2.1 Requirements for personnel ........... 6

2.2 Designated use ...................... 6

2.3 Workplace safety .................... 6

2.4 Operational safety ................... 7

2.5 Product safety ....................... 7

3 Incoming acceptance and

product identification .......... 9

3.1 Incoming acceptance ................. 9

3.2 Product identification ................ 10

3.3 Scope of delivery .................... 11

3.4 Certificates and approvals ............ 11

4 Installation .................... 13

4.1 Mounting the sensor ................ 13

4.2 Post-installation check ............... 17

5 Electrical connection .......... 17

5.1 Quick wiring guide .................. 18

5.2 Connecting the sensor ............... 20

5.3 Ensuring the degree of protection ..... 20

5.4 Post-connection check ............... 20

6 Commissioning ................ 21

7 Maintenance .................. 21

8 Repair .......................... 22

8.1 Sealing ring replacement and

recalibration (CLS16D only) .......... 22

8.2 Return ............................ 23

8.3 Disposal ........................... 23

9 Technical data ................. 24

9.1 Input .............................. 24

9.2 Performance characteristics .......... 25

9.3 Environment ....................... 26

9.4 Process ............................ 26

9.5 Mechanical construction ............. 28

Condumax CLS15D/16D/21D About this document

Endress+Hauser 5

1 About this document

1.1 Warnings

Structure of information Meaning

LDANGER

Causes (/consequences)

If necessary, Consequences of non-

compliance (if applicable)

‣Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid the dangerous situation will result in a fatal or serious injury.

LWARNING

Causes (/consequences)

If necessary, Consequences of non-

compliance (if applicable)

‣Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid the dangerous situation can result in a fatal or serious injury.

LCAUTION

Causes (/consequences)

If necessary, Consequences of non-

compliance (if applicable)

‣Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid this situation can result in minor or more serious injuries.

NOTICE

Cause/situation

If necessary, Consequences of non-

compliance (if applicable)

‣Action/note

This symbol alerts you to situations which may result in damage to property.

1.2 Symbols

Symbol Meaning

Additional information, tips

Permitted or recommended

Not permitted or not recommended

Reference to device documentation

Reference to page

Reference to graphic

 Result of a step

Basic safety instructions Condumax CLS15D/16D/21D

6 Endress+Hauser

2 Basic safety instructions

2.1 Requirements for personnel

• Installation, commissioning, operation and maintenance of the measuring system may be

carried out only by specially trained technical personnel.

• The technical personnel must be authorized by the plant operator to carry out the specified

activities.

• The electrical connection may be performed only by an electrical technician.

• The technical personnel must have read and understood these Operating Instructions and

must follow the instructions contained therein.

• Faults at the measuring point may only be rectified by authorized and specially trained

personnel.

Repairs not described in the Operating Instructions provided must be carried out only

directly at the manufacturer's site or by the service organization.

2.2 Designated use

The conductivity sensors are designed for the conductive measurement of the conductivity of

liquids.

They are used in the following fields:

Sensor Applications Hazardous areas

Condumax CLS15D Measurements in pure and ultrapure water Approved for Ex zone 0

Condumax CLS16D Measurements in pure and ultrapure water with hygienic requirements Approved for Ex zone 0

Condumax CLS21D Measurements in media with medium or high conductivity Approved for Ex zone 0

Use of the device for any purpose other than that described, poses a threat to the safety of

people and of the entire measuring system and is therefore not permitted.

The manufacturer is not liable for damage caused by improper or non-designated use.

2.3 Workplace safety

As the user, you are responsible for complying with the following safety conditions:

• Installation guidelines

• Local standards and regulations

• Regulations for explosion protection

Electromagnetic compatibility

• The product has been tested for electromagnetic compatibility in accordance with the

applicable international standards for industrial applications.

• The electromagnetic compatibility indicated applies only to a product that has been

connected in accordance with these Operating Instructions.

Condumax CLS15D/16D/21D Basic safety instructions

Endress+Hauser 7

2.4 Operational safety

Before commissioning the entire measuring point:

1. Verify that all connections are correct.

2. Ensure that electrical cables and hose connections are undamaged.

3. Do not operate damaged products, and protect them against unintentional operation.

4. Label damaged products as defective.

During operation:

‣If faults cannot be rectified:

products must be taken out of service and protected against unintentional operation.

2.5 Product safety

2.5.1 State-of-the-art technology

The product is designed to meet state-of-the-art safety requirements, has been tested, and

left the factory in a condition in which it is safe to operate. The relevant regulations and

international standards have been observed.

2.5.2 Electrical equipment in hazardous areas

ATEX/NEPSI II 1G Ex ia IIC T3/T4/T6 Ga

• The Memosens inductive sensor-cable connection system is suitable for use in hazardous

areas in accordance with EC type examination certificate BVS 04 ATEX E 121 X. The

corresponding EC declaration of conformity is part of this document.

• The certified conductivity sensors CLS15D/CLS16D/CLS21D may only be connected via the

measuring cable CYK10-G/I*** to the certified intrinsically safe digital sensor output

circuits of measuring device Liquiline M CM42-KE/F/G/I/J********** in accordance with

EC type-examination certificate TÜV 13 ATEX 7459 X.

• The electrical connection must be made according to the wiring diagram of the transmitter.

• Metallic process connection parts must be mounted at the mounting location

electrostatically conductive (< 1 MΩ).

• The CLS15D-type sensors with non-metal process connections and the CLS21D-type

sensors may only be employed for measurement in liquids with a minimum conductivity of

10 nS/cm.

• The CLS15D-type sensors with non-metal process connections may not be operated under

process conditions in which electrostatic charging of the sensor, and particularly of the

electrically insulated outer electrode, is likely to occur.

• Measuring cable CYK10-G/I*** and its terminal head must be protected against

electrostatic charging if it is run through Zone 0.

• The maximum permitted cable length is 100 m.

• Ex versions of digital sensors with Memosens technology are indicated by an orange-red

ring.

• Full compliance with regulations for electrical systems in hazardous areas (e.g. EN/IEC

60079-14) is mandatory when using the devices and sensors.

Basic safety instructions Condumax CLS15D/16D/21D

8 Endress+Hauser

Temperature classes

Name Type Medium temp. Ta for temperature class (Tn) Cat.

Condumax CLS15D - A ** G -20 °C ≤ Ta ≤ +135 °C (T3)

-20 °C ≤ Ta ≤ +120 °C (T4)

-20 °C ≤ Ta ≤ +70 °C (T6)

II 1G

Condumax CLS15D - B/L ** G -20 °C ≤ Ta ≤ +135 °C (T3)

-20 °C ≤ Ta ≤ +100 °C (T4)

-20 °C ≤ Ta ≤ +50 °C (T6)

II 1G

Condumax CLS16D - ** ** G -5 °C ≤ Ta ≤ +135 °C (T3)

-5 °C ≤ Ta ≤ +115 °C (T4)

-5 °C ≤ Ta ≤ +65 °C (T6)

II 1G

Condumax CLS21D - * ** G -20 °C ≤ Ta ≤ +135 °C (T3)

-20 °C ≤ Ta ≤ +115 °C (T4)

-20 °C ≤ Ta ≤ +65 °C (T6)

II 1G

If the specified medium temperatures are complied with, temperatures that are not permitted

for the respective temperature class will not occur on the equipment.

ATEX/NEPSI II 3G Ex ic IIC T3/T4/T6 Gc

• The Memosens inductive sensor-cable connection system is suitable for use in hazardous

areas, Zone 2. The corresponding EU declaration of conformity is part of this document.

• The certified conductivity sensors CLS15D / CLS16D / CLS21D may only be connected via

the measuring cable CYK10-V*** to the certified intrinsically safe digital sensor output

circuits of measuring device Liquiline M CM42-KV*********.

• The electrical connection must be made according to the wiring diagram of the transmitter.

• Metallic process connection parts must be mounted at the mounting location

electrostatically conductive (< 1 MΩ).

• The CLS15D-type sensors with non-metal process connections and the CLS21D-type

sensors may only be employed for measurement in liquids with a minimum conductivity of

10 nS/cm.

• The CLS15D-type sensors with non-metal process connections may not be operated under

process conditions in which electrostatic charging of the sensor, particularly of the

electrically insulated outer electrode, is likely to occur.

• The maximum permitted cable length is 100 m.

• Full compliance with regulations for electrical systems in hazardous areas (EN/IEC

60079-14) is mandatory when using the devices and sensors.

Temperature classes

Name Type Medium temp. Ta for temperature class (Tn) Cat.

Condumax CLS15D - A ** V -20 °C ≤ Ta ≤ +135 °C (T3)

-20 °C ≤ Ta ≤ +120 °C (T4)

-20 °C ≤ Ta ≤ +70 °C (T6)

II 3G

Condumax CLS15D - B/L ** V -20 °C ≤ Ta ≤ +135 °C (T3)

-20 °C ≤ Ta ≤ +100 °C (T4)

-20 °C ≤ Ta ≤ +50 °C (T6)

II 3G

Condumax CLS15D/16D/21D Incoming acceptance and product identification

Endress+Hauser 9

Name Type Medium temp. Ta for temperature class (Tn) Cat.

Condumax CLS16D - ** ** V -5 °C ≤ Ta ≤ +135 °C (T3)

-5 °C ≤ Ta ≤ +115 °C (T4)

-5 °C ≤ Ta ≤ +65 °C (T6)

II 3G

Condumax CLS21D - * ** V -20 °C ≤ Ta ≤ +135 °C (T3)

-20 °C ≤ Ta ≤ +115 °C (T4)

-20 °C ≤ Ta ≤ +65 °C (T6)

II 3G

If the specified medium temperatures are complied with, temperatures that are not permitted

for the respective temperature class will not occur on the equipment.

FM/CSA IS/NI Cl.1 Div.1&2 Gr. A-D

Observe the documentation and the control drawings of the transmitter.

3 Incoming acceptance and product identification

3.1 Incoming acceptance

1. Verify that the packaging is undamaged.

 Notify the supplier of any damage to the packaging.

Keep the damaged packaging until the issue has been resolved.

2. Verify that the contents are undamaged.

 Notify the supplier of any damage to the delivery contents.

Keep the damaged goods until the issue has been resolved.

3. Check that the delivery is complete and nothing is missing.

 Compare the shipping documents with your order.

4. Pack the product for storage and transportation in such a way that it is protected

against impact and moisture.

 The original packaging offers the best protection.

Make sure to comply with the permitted ambient conditions.

If you have any questions, please contact your supplier or your local Sales Center.

Incoming acceptance and product identification Condumax CLS15D/16D/21D

10 Endress+Hauser

3.2 Product identification

3.2.1 Type code for versions with explosion protection

Name Type Version

Condumax CLS15D

CLS16D

CLS21D

Process connections,

materials not Ex-relevant

For use in hazardous areas, ATEX/NEPSI II 1G Ex ia IIC

T3/T4/T6 Ga, IECEx Ex ia IIC T3/T4/T6 Ga

Name Type Version

Condumax CLS15D

CLS16D

CLS21D

Process connections,

materials not Ex-relevant

For use in hazardous areas, FM/CSA IS/NI Cl I Div.1&2

Gr. A-D

Name Type Version

Condumax CLS15D

CLS16D

CLS21D

Process connections,

materials not Ex-relevant

For use in hazardous areas, ATEX/NEPSI II 3G Ex ic IIC

T3/T4/T6 Gc

3.2.2 Nameplate

The nameplate provides you with the following information on your device:

• Manufacturer identification

• Order code

• Serial number

• Ambient and process conditions

• Safety information and warnings

• Cell constant (nominal value)

• Degree of protection

• Ex labeling on hazardous area versions

‣Compare the information on the nameplate with the order.

3.2.3 Product identification

Product page

www.endress.com/cls15d

www.endress.com/cls16d

Otros manuales para CLS15D

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Accesorios de Endress+Hauser

Endress+Hauser

Endress+Hauser CCS50D Manual de usuario

Endress+Hauser

Endress+Hauser Oxymax COS22D Manual de usuario

Endress+Hauser

Endress+Hauser Chloromax CCS142D Manual de usuario

Endress+Hauser

Endress+Hauser Oxymax W COS71 Manual

Endress+Hauser

Endress+Hauser OUSAF46 Manual de usuario

Endress+Hauser

Endress+Hauser Turbimax W CUS65 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual de usuario

Endress+Hauser

Endress+Hauser Proline 200 PROFIBUS PA Especificaciones técnicas

Endress+Hauser

Endress+Hauser Deltapilot M FMB50 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Ceramax CPS341D Manual de usuario

Endress+Hauser

Endress+Hauser CLS15D Manual de usuario

Endress+Hauser

Endress+Hauser Turbimax CUS51D Manual

Endress+Hauser

Endress+Hauser Turbimax CUS51D Manual de usuario

Endress+Hauser

Endress+Hauser Memosens COL37E Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag H Especificaciones técnicas

Endress+Hauser

Endress+Hauser CCS140 Manual de usuario

Endress+Hauser

Endress+Hauser OUSAF11 Manual de usuario

Endress+Hauser

Endress+Hauser Oxymax COS61D Manual de usuario

Endress+Hauser

Endress+Hauser CCS120D Manual de usuario

Endress+Hauser

Endress+Hauser Soliwave FQR56 Manual de usuario

Endress+Hauser

Endress+Hauser Memosens COS51E Manual de usuario

Endress+Hauser

Endress+Hauser Proline 200 FOUNDATION Fieldbus Especificaciones técnicas

Endress+Hauser

Endress+Hauser Proline 100 Modbus RS485 Especificaciones técnicas

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario
