USER’S GUIDE

Documentation version 1.2.6

INTRODUCTION

Documentation Version 1.2.6

INTRODUCTION

Documentation Version 1.2.6Documentation Version 1.2.6

/ 3

INTRODUCTION

• Objective:

Provide a visual guide of the dierent steps to set-up and get

started using the MicroDelta Rework 3D printer.

• Authors of this document :

eMotion Tech – http://www.emotion-tech.com

Hugo FLYE

Anthony BERNA

• Photographics credits :

Pictures and 3D representations made by eMotion Tech :

http://www.emotion-tech.com

• Sources :

http://reprap.org/wiki/RepRap

http://www.repetier.com/

• Licence :

MicroDelta Rework : CC BY-NC-SA 4.0

is document : CC BY-NC-SA 4.0

http://creativecommons.org/licenses/by-nc-sa/4.0/

• Update:

Last update : 09/10/2017

• Links :

You can nd more informations on the following links :

eMotion Tech’s website : http://www.emotion-tech.com

RepRap community : http://reprap.org/wiki/reprap

RepRap

INTRODUCTION

Documentation Version 1.2.6

SUMMARY

INTRODUCTION 2

SUMMARY 4

SOFTWARE INSTALLATION 5

A. Software installation on Mac OS 6

PREPARATION 7

A. Files to copy on the TF card 8

B. Connecting your printer to Repetier-Host 9

C. Printer’s settings 11

D. Slicing settings 13

E. Motion test 15

F. Heating test 16

G. Charging lament 17

H. Extrusion test 18

I. Calibration process using command lines 19

PRINTING 22

A. Spool Holder Print 23

APPENDIX 27

Mounting of the spool holder 28

Spring lament pressure adjustment 30

Printing a 3D model 33

PID calculation 36

To go further 37

Maintenance 38

Recommandations 38

Restore the TF card 39

Documentation Version 1.2.6Documentation Version 1.2.6

/ 5

SOFTWARE INSTALLATION

SOFTWARE

INSTALLATION

SOFTWARE INSTALLATION

Documentation Version 1.2.6

Soware installation on Mac OS

Objective : Install the necessary soware to use the MicroDelta Rework on a Mac operating system computer.

1°) Dowload the latest version of Repetier-Host from the support section of eMotion Tech’s website (www.emotion-tech.com).

Support / MicroDelta Rework / Soware / Mac /

2°) Find all the necessary informations for the installation on the following link :

https://www.repetier.com/documentation/repetier-host-mac/installation-and-connection/

Note: the version of Repetier for Mac OS X is less developed than those on Windows / Linux. erefore the use of a virtual machine is advised to take

advantage of the latest updates and added options. However, we will guide you through this documentation for the installation of the ocial version

of Repetier for Mac OS X.

Documentation Version 1.2.6Documentation Version 1.2.6

/ 7

PREPARATION

Documentation Version 1.2.6

Files to copy on the TF card

1°) Go to the eMotion Tech’s website support section, then go to «MicroDelta Rework / Soware / Conguration» and download the correspon-

ding conguration les to your MicroDelta Rework depending on it’s version and options.

2°) Connect your printer to the computer

3°) Once downloaded, unzip the le and copy all its content in the eMotronic’s TF card.

Objective : copy the required les in the eMotronic’s TF card.

Note: TF card is usually automatically detected and its content displayed once you connect your 3D printer to you computer. e

TF card generally appears as drive «NO NAME» but this can vary depending on your hardware.

4°) Press the «Reset» button on the 3D printer (located on one side of the lower plate).

Mac OS X : what you should have on the TF card aer this step

5°) Check that the device has been properly recognized by your operation system.

Documentation Version 1.2.6Documentation Version 1.2.6

/ 9

PREPARATION

Connecting your printer to Repetier-Host

1°) Run Repetier-Host soware.

2°) Go to «Cong» then «Printer Settings».

3°) Check that all the parameters correspond to those on the image below. Select the COM port assigned to your MicroDelta Rework.

PREPARATION

Documentation Version 1.2.6

4°) Click on Connect.

is one should change color, becomes green when connected :

5°) Check on the bottom of the screen that the extruder’s temperature

is consistent (logical value) and the printer’s status is «Idle» as shown

below:

If you have a Heated Bed, its temperature will be displayed

next to the extruder’s.
