Elcometer 456

High Temperature

PINIP™ Probe

Operating Instructions

English

The Elcometer 456 High

Temperature PINIP™ probe has

been tested in accordance with EU

regulations governing Electro-

magnetic compliance and it meets

the required directives.

is a registered trademark of

Elcometer Instruments Ltd.

All other trademarks acknowledged.

2004.

may be reproduced, transmitted, transcribed,

stored (in a retrieval system or otherwise) or

translated into any language, in any form or

by any means (electronic, mechanical,

magnetic, optical, manual or otherwise)

without the prior written permission of

Elcometer Instruments Ltd.

Doc.No. TMA-0308 Issue 01

Text with Cover No: 19156

English

CONTENTS

Section Page

1 About your probe . . . . . . . . . . . . . . . . . 2

2 Fitting the probe . . . . . . . . . . . . . . . . . . 3

3 Calibrating the probe . . . . . . . . . . . . . . 4

4 Taking a reading . . . . . . . . . . . . . . . . . . 5

5 Packaging . . . . . . . . . . . . . . . . . . . . . . . 5

6 Maintenance . . . . . . . . . . . . . . . . . . . . . 6

7 Spares . . . . . . . . . . . . . . . . . . . . . . . . . . 6

8 Related equipment . . . . . . . . . . . . . . . . 6

English

hank you for your purchase of this

Elcometer 456 High Temperature

PINIP™ probe. Welcome to Elcometer.

Elcometer are world leaders in the design,

manufacture and supply of inspection

equipment for coatings and concrete.

Our products cover all aspects of coating

inspection, from development through

application to post application inspection.

The Elcometer 456 High Temperature

PINIP™ probe is a world beating product.

With the purchase of this product you now

have access to the worldwide service and

support network of Elcometer. For more

information visit our website at

www.elcometer.com

1 ABOUT YOUR PROBE

The Elcometer 456 High Temperature

PINIP™ probe enables fast and accurate

measurement of the thickness of coatings on

metal substrates at temperatures up to 250°C

(480°F).

The PINIP™ format (Plug-In Integral Probe)

is an integral style probe which plugs in to an

Elcometer 456 or Elcometer 4562separate

gauge type F or FNF. This provides all the

benefits of an integral gauge and the

flexibility of a separate gauge in a single unit.

English

The High Temperature PINIP™ is an F1 2

scale probe which combines the F1 scale

with the F2 scale in a single probe. The user

selects the appropriate range for the work in

hand. The resolution of the gauge is

dependent on the scale selected on the

gauge.

1.1 What the box contains

• Elcometer 456 High Temperature

PINIP™ probe

• Calibration thickness standard, 2 x

• Storage case, 2 x

• Operating instructions

2 FITTING THE PROBE

To ensure correct transfer of data from the

probe and detection of the new probe, the

gauge must be switched off when the

PINIP™ probe is fitted.

Twist the PINIP™

until the connector

locates. Taking

care not to cross

the threads, lock

the probe by turning

the locking ring 1½

times clockwise, or

until tight.

English

A probe must be calibrated once it has been

fitted - refer to your Elcometer 456 Operating

Instructions and section 3 of these

instructions.

3 CALIBRATING THE PROBE

Special thickness standards are supplied

with F1 2 High Temperature PINIP™ Probes.

To use these special thickness standards,

place the appropriate thickness standard

over the end of the PINIP™ probe during the

calibration procedure. Remove the thickness

standard from the end of the PINIP™ probe

after use.

A High Temperature PINIP™ probe should

always be calibrated on a hot substrate. The

temperature of the substrate used for

calibration is best equal to the temperature of

the surface being measured.

The magnetic properties of the substrate can

be affected by the temperature of the

substrate. It is therefore advisable to use a

substrate for calibration that is of a similar

material and temperature to the coated

substrate being measured.

English

4 TAKING A READING

The procedure for taking a reading with a

High Temperature PINIP™ probe is the same

as for a standard Elcometer 456 probe,

however the following points should be

noted:

Take care: High Temperature

PINIP™ probes are capable of

measuring on surfaces up to 250°C

(480°F).

Wear appropriate protective clothing and

avoid bodily contact with the hot surface

during measurement.

Measurement speed.

When measuring

high temperature materials measurement

speed must be reduced to prevent

overheating of the probe. The maximum

measurement speed of the High Temperature

PINIP™ probe at 250°C (480°F) is 4 readings

per minute.

5 PACKAGING

The Elcometer High Temperature PINIP™

probe is packed in a cardboard and foam

package. Please ensure that this packaging

is disposed of in an environmentally sensitive

manner. Consult your local Environmental

Authority for further guidance.

English

6 MAINTENANCE

The Elcometer High Temperature PINIP™

probe does not contain any user-serviceable

components. In the unlikely event of a fault,

the probe should be returned to your local

Elcometer supplier or directly to Elcometer.

Details of Elcometer offices around the world

are given on the outside cover of these

Operating Instructions. Alternatively visit the

Elcometer website, www.elcometer.com

7 SPARES

The following replacement High Temperature

PINIP™ thickness standards are available

from Elcometer or your local Elcometer

supplier:

Thickness standard Sales Part Number

1.5 mm T45618978-2

5 mm T45618978-3

8 RELATED EQUIPMENT

Users of the High Temperature PINIP™

probe may also benefit from the following

Elcometer products:

• Infrared portable printer for 456 gauges.

• Infrared Digital Thermometers with or

without laser assisted alignment.

Visit www.elcometer.com for more details.
