Elcometer 112 Manual de usuario

User Guide

Elcometer 112, 115, 154,

3236, 3238 Wet Film Combs

Elcometer 3230 Wet Film Wheels

www.elcometer.com

Section

Page

Overview

en-2

Box Contents

en-3

Test Procedure

en-3

Technical Specification

en-5

www.elcometer.com

For the avoidance of doubt, please refer to the original English language version.

Please ensure that all packaging is disposed of in an environmentally sensitive manner. Consult your local

Environmental Authority for further guidance.

is a registered trademark of Elcometer Limited, Edge Lane, Manchester, M43 6BU.

United Kingdom

All other trademarks acknowledged.

transcribed, stored (in a retrieval system or otherwise) or translated into any language, in any form or by any

means (electronic, mechanical, magnetic, optical, manual or otherwise) without the prior written permission of

Elcometer Limited.

CONTENTS

en-1

WET FILM COMBS

Elcometer 112, 3236

& 112AL

Precision formed, long lasting and reusable hexagonal stainless steel

wet lm combs. Available in a range of thicknesses measuring up to

3000μm (120mils) with 24 or 36 measurement steps depending on

the comb.

An aluminium version of the Elcometer 112 is also available, the

Elcometer 112AL . Supplied in packs of 10, each aluminium comb

has Metric (25 - 3000μm) on one side and Imperial (1 - 118mils) on

the other.

Elcometer 154

Made from ABS plastic designed to be used once and kept as a

record of wet lm thickness measurement for quality assurance or

customer requirements. Supplied in packs of 500, each comb has

Metric (50 - 800μm) on one side and Imperial (7 - 32mils) on the

other.

Elcometer 115

Precision formed, long lasting and reusable stainless steel wet lm

combs. Four separate wet lm thickness ranges are available up to a

maximum of 1250µm (50mils) and each comb has 10 measurement

steps (teeth).

Elcometer 3238

Similar to the Elcometer 115, the Elcometer 3238 provides the user

with more measurement steps (teeth) - 24 per comb. Three separate

wet lm thickness ranges are available up to a maximum of 1200µm

(48mils).

WET FILM WHEELS

Elcometer 3230

The Elcometer 3230 wet lm wheel consists of a central eccentric

wheel and two outer concentric wheels. The diameter of the outer

wheels is greater than that of the central wheel. By rolling the gauge

through a wet coating, the centre wheel eventually touches the lm.

This point on the scale indicates the thickness. Various wet lm

thickness ranges are available up to a maximum of 1000µm (40mils).

Elcometer 3230

(Coil Coating)

Similar to the Elcometer 3230 but the outer wheels are knurled to

allow measurements to be taken on slippery coatings or on fast

moving substrates. Two separate wet lm thickness ranges are

available; 0 - 50μm (0 - 2mils) and 0 - 100μm (0 - 4mils).

www.elcometer.com en-2

1 OVERVIEW

a The Elcometer 112AL can be customised with your logo. Please contact Elcometer or your local

Elcometer supplier for further information.

Before you start, ensure the wet film comb or wheel is clean, see

Section 3.3 ‘Cleaning After Test’ on page en-4, and undamaged as

damage to the wet film teeth or wheel circumference will affect the

readings.

3.1 USING A WET FILM COMB

1 Hold the comb perpendicular to the

wet film and press the edge of the

comb into the film until it is stable on

the substrate.

2 Remove the comb from the wet film.

3 Examine the teeth of the comb and

locate the last tooth which is wetted.

Read the thickness value of this

tooth. The wet film thickness is

between this value and the

thickness value of the next dry

tooth.

In the example shown, the wet film

thickness lies between 2400μm and

2600μm.

To use the comb on pipes, ensure it is

placed parallel to the longitudinal axis of

the pipe.

On rough surfaces, measurements will be made from the surface

peaks and therefore will represent the minimum wet film thickness.

2 BOX CONTENTS



Elcometer Wet Film Comb or Wheel



Storage Wallet / Case



Calibration Certificate (if ordered)



User Guide

b A storage wallet / case is not supplied with the Elcometer 112AL and Elcometer 154.

c Calibration certificates are not available for the Elcometer 112AL, Elcometer 154 and Elcometer 3230 Coil

Coating Wet Film Wheels.

3 TEST PROCEDURE

www.elcometer.com

en-3

650

700

750

800

850

900

1000

1100

1200

1400

1600

1800

2000

2200

2400

2600

2800

3000

100

125

150

175

200

225

250

275

300

350

400

450

500

550

600

Wet Film

Substrate

3 TEST PROCEDURE (continued)

www.elcometer.com en-4

3.2 USING A WET FILM WHEEL

The procedure outlined below is for guidance only. Consult the

relevant Standard for full details of the applicable test procedure.

1 Using a finger and thumb, hold the

wheel by its central spindle with

the maximum reading on the scale

nearest to the paint film.

2 Place the wheel into the wet film

ensuring that the wheel is

perpendicular to the film.

3 Roll the wheel across the film

through 360°/180° (depending

upon standard) and then remove

from the surface.

4 Locate the first point on the central wheel where the paint has

adhered. Read the wet film thickness from the scale on the side

of the wheel at this point.

Repeat the procedure at least twice in different places to obtain

representative results.

To use the wheel on pipes, roll the wheel at right angles to the

longitudinal axis of the pipe.

On rough surfaces, measurements will be made from the surface

peaks and therefore will represent the minimum wet film thickness.

3.3 CLEANING AFTER TEST

Clean the wet film comb or wheel after each test using a suitable

solvent. After cleaning, ensure that all materials are removed and that

the gauge is dry.

DO NOT use very aggressive solvents or wire brushes, metal

scrapers, metal files, or other metallic tools for cleaning.

Store the wet film comb or wheel in the wallet / case provided when

not in use.

b A storage wallet / case is not supplied with the Elcometer 112AL and Elcometer 154.

d Does not apply to the Elcometer 154 which are designed to be used once and kept as a record of wet lm

thickness measurement for quality assurance or customer requirements.

max

Wet Film

Substrate

www.elcometer.com

en-5

4 TECHNICAL SPECIFICATION

4.1 ELCOMETER 112 & 3236 HEXAGONAL WET FILM COMBS (Stainless Steel)

Part Number

Range

Measurement Steps

K0003236M201

20 - 370µm

20, 30, 40, 50, 60, 70, 80, 90, 100, 110, 120, 130,

150, 170, 190, 210, 230, 250, 270, 290, 310, 330,

350, 370µm

K0003236M202

25 - 2000µm

25, 50, 75, 100, 125, 150, 175, 200, 225, 250, 275,

300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800,

850, 900, 950, 1000, 1100, 1200, 1300, 1400, 1500,

1600, 1700, 1800, 1900, 2000µm

B112----1B

25 - 3000µm

25, 50, 75, 100, 125, 150, 175, 200, 225, 250, 275,

300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800,

850, 900, 1000, 1100, 1200, 1400, 1600, 1800, 2000,

2200, 2400, 2600, 2800, 3000µm

K0US3236M203

0.5 - 15mils

0.5, 0.75, 1.0, 1.25, 1.5, 2, 2.5, 3, 3.5, 4, 4.5, 5, 5.5,

6, 6.5, 7, 8, 9, 10, 11, 12, 13, 14, 15mils

K0US3236M204

1 - 80mils

1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 14, 16, 18, 20, 22, 24,

26, 28, 30, 32, 34, 36, 38, 40, 42, 44, 46, 48, 50, 55,

60, 65, 70, 75, 80mils

B112----2B

1 - 120mils

1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18, 20, 22,

24, 26, 28, 30, 32, 34, 36, 38, 40, 45, 50, 55, 60, 70,

80, 90, 100, 110, 120mils

Accuracy

±5% of marked value or 3µm (0.12mil) whichever is the greater

Can be used in accordance with: ASTM D 4414-A, AS/NZS 1580.107.3, BS 3900-C5-7B,

ISO 2808-1A, ISO 2808-7B, JIS K 5600-1-7, NF T30-125, US NAVY PPI 63101-000,

US NAVY NSI 009-32

4.2 ELCOMETER 112AL HEXAGONAL WET FILM COMBS (Aluminium)

Part Number

Range

Measurement Steps

B112AL12473-3

Side A:

25 - 3000µm

25, 50, 75, 100, 125, 150, 175, 200, 225, 250, 275,

300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800,

850, 900, 1000, 1100, 1200, 1400, 1600, 1800, 2000,

2200, 2400, 2600, 2800, 3000µm

Side B:

1 - 118mils

1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18, 20, 22,

24, 26, 28, 30, 31, 33, 35, 39, 43, 47, 55, 63, 71, 79,

87, 94, 102, 110, 118mils

Accuracy

Nominal Values

Can be used in accordance with: ASTM D 4414-A, AS/NZS 1580.107.3, BS 3900-C5-7B,

ISO 2808-1A, ISO 2808-7B, JIS K 5600-1-7, NF T30-125, US NAVY PPI 63101-000,

US NAVY NSI 009-32

e Optional Calibration Certicates are available to purchase separately. Calibration Certicates must be

requested at time of order, they can not be supplied retrospectively.

www.elcometer.com en-6

4 TECHNICAL SPECIFICATION (continued)

e Optional Calibration Certicates are available to purchase separately. Calibration Certicates must be

requested at time of order, they can not be supplied retrospectively.

† Two 10mils values - one on each edge of the comb.

4.3 ELCOMETER 115 WET FILM COMBS (Stainless Steel)

Part Number

Range

Measurement Steps

B11529455M

20 - 325µm

20, 35, 50, 75, 100, 125, 175, 225, 275, 325µm

B11529456M

50 - 450µm

50, 75, 100, 150, 200, 250, 300, 350, 400, 450µm

B11529457M

50 - 750µm

50, 100, 150, 200, 250, 350, 450, 550, 650, 750µm

B11529458M

125 - 1250µm

125, 250, 375, 500, 625, 750, 875, 1000, 1125, 1250µm

B11529451E

1 - 13mils

1, 1.5, 2, 3, 4, 5, 7, 9, 11, 13mils

B11529452E

2 - 18mils

2, 3, 4, 6, 8, 10, 12, 14, 16, 18mils

B11529453E

2 - 30mils

† †

2, 4, 6, 8, 10 , 10 , 15, 20, 25, 30mils

B11529454E

5 - 50mils

5, 10, 15, 20, 25, 30, 35, 40, 45, 50mils

Accuracy

±5% of marked value or 3µm (0.12mil) whichever is the greater

Can be used in accordance with: ASTM D 4414-A, AS/NZS 1580.107.3, BS 3900-C5-7B,

ISO 2808-1A, ISO 2808-7B, JIS K 5600-1-7, NF T30-125, US NAVY PPI 63101-000,

US NAVY NSI 009-32

4.4 ELCOMETER 3238 LONG EDGE WET FILM COMBS (Stainless Steel)

Part Number

Range

Measurement Steps

K0003238M201

5 - 120µm

5µm intervals

K0003238M202

25 - 600µm

25µm intervals

K0003238M203

50 - 1200µm

50µm intervals

K0US3238M201

0.5 - 6mils

0.5mil intervals

K0US3238M202

1 - 24mils

1mil intervals

K0US3238M203

2 - 48mils

2mil intervals

Accuracy

±5% of marked value or 3µm (0.12mil) whichever is the greater

Can be used in accordance with: ASTM D 4414-A, AS/NZS 1580.107.3, BS 3900-C5-7B,

ISO 2808-1A, ISO 2808-7B, JIS K 5600-1-7, NF T30-125, US NAVY PPI 63101-000,

US NAVY NSI 009-32

4.5 ELCOMETER 154 PLASTIC WET FILM COMBS

Part Number

Range

Measurement Steps

B154----1

Side A:

50 - 800µm

50, 65, 75, 90, 100, 125, 150, 175, 200, 250, 300,

400, 500, 600, 700, 800µm

Side B:

2 - 32mils

2, 2.5, 3, 3.5, 4, 5, 6, 7, 8, 10, 12, 16, 20, 24, 28,

32mils

Accuracy

Nominal Values

Can be used in accordance with: BS 3900-C5-7B, ISO 2808-1A, ISO 2808-7B,

JIS K 5600-1-7, NF T30-125

e Optional Calibration Certicates are available to purchase separately. Calibration Certicates must be

requested at time of order, they can not be supplied retrospectively.

f Wet lm wheel handles are not compatible with Elcometer 3230 Coil Coating Wet Film Wheels.

4 TECHNICAL SPECIFICATION (continued)

TMA-0365 Issue 10 - Text with cover 19811

4.6 ELCOMETER 3230 WET FILM WHEELS

Part Number

Range

Graduations

Part Number

Range

Graduations

K0003230M001

0 - 25µm

1.25µm

K0US3230M001

0 - 1mil

0.05mil

K0003230M016

0 - 40µm

2.0µm

K0003230M002

0 - 50µm

2.5µm

K0US3230M002

0 - 2mils

0.10mil

K0003230M003

0 - 100µm

5.0µm

K0US3230M003

0 - 4mils

0.20mil

K0003230M004

0 - 150µm

7.5µm

K0US3230M004

0 - 6mils

0.25mil

K0003230M005

0 - 200µm

10.0µm

K0003230M006

0 - 250µm

12.5µm

K0003230M007

0 - 300µm

15.0µm

K0US3230M005

0 - 12mils

0.50mil

K0003230M008

0 - 400µm

20.0µm

K0003230M009

0 - 500µm

25.0µm

K0US3230M006

0 - 20mils

1.0mil

K0003230M010

0 - 1000µm

50.0µm

K0US3230M007

0 - 40mils

2.0mils

Accuracy

±5% of marked value or 3µm (0.12mil) whichever is the greater

Accessories

KT003230N003: Wet Film Wheel Handle ; 15cm (6”)

KT003230N002: Wet Film Wheel Handle ; 50cm (19”)

Can be used in accordance with: ASTM D 1212-A, AS/NZS 1580.107.3, BS 3900-C5-7A,

ISO 2808-1B, ISO 2808-7A, JIS K 5600-1-7, NF T30-125

4.7 ELCOMETER 3230 COIL COATING WET FILM WHEELS

Part Number

Range

Graduations

Part Number

Range

Graduations

K0003230M017

0 - 50µm

2.5µm

K0US3230M017

0 - 2mils

0.10mil

K0003230M018

0 - 100µm

5.0µm

K0US3230M018

0 - 4mils

0.20mil

Accuracy

Nominal Values

Can be used in accordance with: ASTM D 1212-A, AS/NZS 1580.107.3, BS 3900-C5-7A,

ISO 2808-1B, ISO 2808-7A, JIS K 5600-1-7, NF T30-125

Otros manuales para 112

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de Elcometer

Elcometer

Elcometer 331 Series Manual de usuario

Elcometer

Elcometer 205 Manual de usuario

Elcometer

Elcometer 319 S Manual de usuario

Elcometer

Elcometer 456 Manual de usuario

Elcometer

Elcometer 550 Manual de usuario

Elcometer

Elcometer 3000 Series Manual de usuario

Elcometer

Elcometer 204 Manual de usuario

Elcometer

Elcometer 224 Manual de usuario

Elcometer

Elcometer 355 Manual de usuario

Elcometer

Elcometer 6014 Manual de usuario

Elcometer

Elcometer SG80 Manual de usuario

Elcometer

Elcometer 2350 Manual de usuario

Elcometer

Elcometer CG20 Manual de usuario

Elcometer

Elcometer 456 Manual de usuario

Elcometer

Elcometer Novo-Gloss 406 Manual de usuario

Elcometer

Elcometer 139 Manual de usuario

Elcometer

Elcometer 701 Manual de usuario

Elcometer

Elcometer 308 Manual de usuario

Elcometer

Elcometer 224 Manual de usuario

Elcometer

Elcometer FD700DL+ Manual de usuario

Elcometer

Elcometer SAGOLA Classic S1 Manual de usuario

Elcometer

Elcometer 319/2 Manual de usuario

Elcometer

Elcometer 331 H Manual de usuario

Elcometer

Elcometer Novo-Gloss 401 Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
