Dremel 3D20 Idea Builder Manual de usuario
3D20 Quick Start Guide
WARNINGWARNING
READ ALL OPERATING/SAFETY INSTRUCTIONS IN THE MANUAL AND FAMILIARIZE YOURSELF WITH THE
DREMEL 3D20 BEFORE SETUP AND USE. FAILURE TO COMPLY WITH THE WARNINGS AND INSTRUCTIONS
MAY RESULT IN FIRE, EQUIPMENT DAMAGE, PROPERTY DAMAGE, OR PERSONAL INJURY.
ENGLISH
IMPORTANT: IMPORTANT:IMPORTANTE:
ReadBefore UsingLire avant usageLeer antes de usar
ForEnglish Version Versionfrançaise Versión enespañol
Seepage 2 Voirpage37 Verlapágina 73
Operating/SafetyInstructions
Consignesdesécurité/d’utilisation
Instruccionesde funcionamiento y seguridad
1-844-4DRML3D(1-844-437-6533) www.dremel.com
CallTollFreefor
ConsumerInformation
&Service Locations
Pourobtenir des informations
etles adresses denos centres
deservice après-vente,
appelezcenuméro gratuit
Llamegratispara
obtenerinformación
parael consumidor y
ubicacionesdeservicio
P.O.Box 081126 Racine, WI 53408-1126
3D20
Idea Builder
3D20 Quick Start Guide
WARNINGWARNING
READALL OPERATING/SAFETY INSTRUCTIONS IN THE MANUAL AND FAMILIARIZE YOURSELF WITH THE
DREMEL3D20 BEFORE SETUP AND USE. FAILURE TO COMPLY WITH THE WARNINGS AND INSTRUCTIONS
MAYRESULT IN FIRE, EQUIPMENT DAMAGE, PROPERTY DAMAGE, OR PERSONAL INJURY.
0
.
3
m
m
C
L
E
A
R
A
N
C
E
LEVELING SHEET
TURN LEFT TO RAISE
THE BUILD PLATFORM
TURN RIGHT TO LOWER
Adjust the platform until
leveling tool slides between
the extruder and platform
with some resistance
0.3mm
LEVELING TOOL
Unboxing
1Kit Contents
2
TIP: Save your Dremel 3D20 packaging for future transportation
and storage.
Firmly lift the build platform
to the top position
Dremel 3D20 Instruction Manual Quick Start Guide 1 Filament Spool
Power CableSpool Lock USB Cable SD Card
Build Tape Object Removal Tool Unclog Tool Leveling Sheet
12
34
56
Getting to Know Your Dremel 3D20
3
1. Lid
2. Door
3. Touch Screen
4. Build Platform
5. Build Platform Clips
6. Filament Spool
7. Filament Spool Holder/Lock
8. Extruder Tip
9. Extruder Fan
10. Extruder
11. Extruder Intake
12. X-Axis Guide Rails
13. Stepper Motor (1 of 3)
14. Z-Axis Guide Rail
15. Filament Guide Tube
16. Y-Axis Guide Rails
17. SD Card Input
18. USB Input
19. Power Switch
20. Power Input
1
2
3
4
5
6
7
8
9
1011 12
13
14
15
16
17 18 19 20
Filament
Guide
PRESS
LIFT
Getting Ready to Build
4
FILAMENT INSTALLATION
1. Ensure the power switch is in the off position, remove the lid
and remove the build platform.
2. Place filament spool onto spool holder with spool being fed from
the bottom towards the back of the Dremel 3D20. Insert spool
lock into spool holder and rotate 90 degrees to lock in place.
3. Thread filament through filament guide tube.
4. Insert the filament coming from the filament guide tube into
the extruder intake (top).
5. Adhere build tape over the build platform.
6. Install platform using 3 clips. Place the table under the two
back clips then snap it in with the front clip.
7. Plug power cord into outlet and turn on power switch.
8. Tap “Tools” on your Dremel 3D20’s touch screen, then tap
“Filament”, then tap “Load Filament” and wait for the extruder
to heat.
9. Once heated, filament will be drawn through the extruder. Allow
filament to exit the extruder for 10 seconds before tapping the
return arrow to complete.
WARNINGWARNING
OBSERVE ALL PROVIDED WARNINGS AND SAFETY
INSTRUCTIONS WHEN USING THE DREMEL 3D20.
FAILURE TO DO SO MAY RESULT IN FIRE, EQUIPMENT DAMAGE,
PROPERTY DAMAGE OR PERSONAL INJURY.
2
3
5
1
8
4
BACK
TURN LEFT TO RAISE
THE BUILD PLATFORM
TURN RIGHT TO LOWER
THE BUILD PLATFORM
STEP 1: LEFT ADJUSTMENT
NEXT
WARM
BACK
TURN LEFT TO RAISE
THE BUILD PLATFORM
TURN RIGHT TO LOWER
THE BUILD PLATFORM
STEP 2: RIGHT ADJUSTMENT
NEXT
WARM
BACK
TURN LEFT TO RAISE
THE BUILD PLATFORM
TURN RIGHT TO LOWER
THE BUILD PLATFORM
STEP 3: BACK ADJUSTMENT
NEXT
WARM
Getting Ready to Build (continued…)
5
LEVELING BUILD PLATFORM
1. Tap “Tools” on your Dremel 3D20’s touch screen and
tap “Level”.
2. First level the front left of the build platform.
3. Place the leveling sheet between the extruder and build
platform.
a) If the leveling sheet cannot slide between the extruder
and build platform, turn the knob counterclockwise until
you can slide the leveling sheet between the extruder and
build platform with some resistance.
b) If the leveling sheet can slide between the extruder and
build platform too easily, turn the knob clockwise until you
can slide the leveling sheet between the extruder and build
platform with some resistance.
4. Tap “Next” to move the build platform toward the right knob
and repeat step above.
5 Tap “Next” to move the build platform toward the rear knob
and repeat step above.
6. Tap “Finish” to complete the leveling process.
1 2
3
4 5
TURN LEFT TO RAISE
THE BUILD PLATFORM
TURN RIGHT TO LOWER
Building
6
BUILDING OUT OF THE BOX
1. On the main screen, tap the "Build" option. Then tap the
machine icon to select from pre-installed models.
2. Tap on the model file you would like to build and tap "Build".
3. Your Dremel 3D20 will align the extruder with the build
platform and will begin heating the extruder.
4. Once the build temperature is reached, your model will
begin to build.
5. Touch screen will display “Object Finished”. Tap the check
box to confirm. Wait until the touch screen indicates that
the extruder temperature is “COOL”.
REMOVING YOUR OBJECT FROM THE BUILD
PLATFORM
6. Wait for the extruder to cool before removing your object.
7. With the object still attached, remove build platform from
the build area.
8. Use your hand to peel your object from the build platform. If
needed, gently use the object removal tool to remove object
from build platform.
2
4
8
1
Best Practices & Resources
7
BEST PRACTICES
1. ALWAYS USE BUILD TAPE.
2. Ensure your platform is level (before you begin building
your object).
3. Ensure spool is installed properly and can rotate freely.
4. When loading filament, allow Dremel 3D20 to extrude until
material is consistent with the installed filament color.
5. It is important to stay near your Dremel 3D20 during
operation and watch the Dremel 3D20 begin building
objects. (If a situation occurs, select the STOP icon right
away, to stop any further building).
6. Remove the build platform before removing the object.
7. Use object removal tool gently to avoid damaging the build
platform or object.
OPERATING ENVIRONMENT
Room Temperature: 16-29° C (60 - 85° F)
Level workspace
Dry workspace environment
15.7” (400mm)
19.1” (485mm) 13.2” (335mm)
WALL
8” (203mm)
8” (203mm)8” (203mm)
14” (356mm)
3D20 RESOURCES
Quick Start Guide In box and www.dremel3d.com
3D20 Website www.dremel3d.com
3D20 Customer 1-844-4DRML3D
Support (1-844-437-6533)
www.dremel3d.com
Dremel 3D20 Installed from www.dremel3d.com
Software or from SD card provided with the
Dremel 3D20
Part#: 2610035692
Build on with Dremel3D.com
8
GETTING STARTED
1. Visit Dremel3D.com and create a profile.
2. Register your Idea Builder to gain access to all available models and support
from the Dremel Experts.
3. Go to the Dremel3D.com Support section to download the Dremel 3D software.
4. Review the Dremel 3D Quick Start Guide online to watch videos on how to easily
set up your Idea Builder.
KICKSTART YOUR 3D PRINTING EXPERIENCE
• Once you have built the Dremel 3D test print located on your Idea Builder,
verifying that your printer is set up properly, consider printing something more
personalized.
• Visit the Design Tools section of Dremel3D.com to add your name or personal
details to an existing model with a Dremel 3D customizer.
• Ready to design something from scratch? Try other free design tools developed
by Autodesk including TinkerCad, Meshmixer, 123D Design, or 123D Sculpt.
Build on Dremel Maker, Build on.
