Dormakaba M Series Manual de usuario

User'sManual

M-seriesLock

Dear user,

Thanks for purchasing our dormakaba smart lock!

Before using the product, please read the user's manual carefully and keep

it properly.

We are so honored that you become our user. Before using the product, we

strongly recommend you to read the instruction manual first in order to make

sure the good using experience. Our company does not bear any liabilities if

you suffer from any losses from improper operations of the lock according to

the user's manual. The instruction manual is only applicable to use

methods, operating conditions and environmental requirements of M5/M6

smart lock. It does not mean actual configurations and interfaces of the

software and hardware, and the actual configurations shall be subject to the

purchased products and packing list.

To improve performance and reliability of components and complete

machine, we may modify hardware or software of the products, which may

result in differences between the physical device and the instruction manual.

However, the using of products won't be affected. Your understanding is

much appreciated.

Contents

1How to Use

AdminPINCodeSetting

HowtoEnterMenu

FactoryReset

DeleteallUsersInformation

MenuFlowChart

FingerprintRegistration

CardRegistration

PINCodeRegistration

UnlockingMethods

CollectFingerprint

BluetoothAPP Downloading

EnableBluetoothAPP

BindDevice

DeviceManagement

ViewDeviceInformation

BluetoothKeySharing

CheckMessages

LanguageSetting

BluetoothFunctionPreview

NetworkAccessingPreparations

AddDoorLock

ViewingDeviceInformation

CheckMessages

SettingFunction

ZigbeeAPPFunctionPreview

LocktheDoorfromInside

VistorMode

PrivacyMode

PassageMode 30

SafetyRugulations

Troubleshooting

Warranty Service

WarrantyCard

ServiceRecordsTable

Certificate of Approval

Installation Receipt

Emergency Use

How to Replace Batteries

Precautions forusing Batteries

UseofEmergencyPowerSupply

User'sPermissionsAssignmentTable

User'sPermissionsLevel

ProductionFunctionConfigurations

AlarmFunction 33

HowtoUse

Ope n t he fi n ger p rint

cover;

‚Place admin fingerprint

on the fingerprint reader

Thisuser's manual only introduces theoperation methods of product and does not list

the product hardware and software configurations. Functionsanddesignofthe

productsaresubjecttochangewithoutpriornotice.

The admin PIN code, admin fingerprint and admin cardonly have admin function

and can't be used to open the door.

Wa ke u p t h e

keyp a d;

‚Input PIN code and

press the # button

Byad m in P I Ncode

Swi p e the c a rd

in fro n t o f t he

re a der

Admin PIN Code Setting

Re move th e

batt e r y cover

Thedefault admin PIN code 00123456.

After installation and commissioning of the door lock, please change the

default admin PIN code as soon as possible.

The PIN code is consisted of random 6-12 digits.

Press the [M]

button for about

10 seconds

Input the PIN

code again and

press the #

button

Input 6-12

digits new PIN

code and press

the # button

1234

How to Enter Menu

Byad m infi n ger p ri n t Byad m in ca rd

123

Note

Warning

Note

HowtoUse

Allusers' fingerprints, PINcodesandcardswillnolongerbeexistingafter

successfullydeletingalluserinformation.

The admin PIN code won't be affected by deleting all users' information.

Press [E] button

for about 10

seconds.

Input 6-12 digits

admin PIN code and

press # button

Remove the

battery

FactoryReset

After factoryreset, the registered fingerprints, cards, remote controls and

Bluetooth users willbe cleared and the database bank only contains the default

admin PIN code 00123456.

After resetting successfully,the lock will restore to default setting.

Remove the

battery

cover

Simultaneously

press [M] and [E]

button on rear

lock for 5

seconds

Select the

language

based on voice

guide and press

#button

Input 6-12

digits admin

PIN code and

press #

button

Note

Delete all Users Information

Note

Menu Flow Chart

1HowtoUse

1. Fingerprint management (Input menu number and

press [#] button to manage)

Fingerprint

management

In ﬂow chart, user needs to input the number and characters to enter

the menu. For example, for” “the user needs input

[#] to enter the ﬁngerprint management interface (The same as below).

SOS user and SOS ﬁngerprint are available only when wireless communication

function is on.

GeneralfingerprintuserID:10-79,temporaryfingerprintuserID:80-89,

SOS fingerprintuserID:90-99,andadminfingerprintuserID:00-09;

Onenumberonly correspondstooneuser.

Finger p r i n t

Registration

General Fingerprint

Registration Input User ID

Input User ID

Press a Finger on the

Fingerprint Reader

Press a Finger on the

Fingerprint Reader

Press a Finger on the

Fingerprint Reader

Press a Finger on the

Fingerprint Reader

Temporary Fingerprint

Registration

SOS Fingerprint

Registration

Admin Fingerprint

Registration

Delete an Individual

Fingerprint

Input the User ID

You Want to Delete

Delete all

Fingerprints

Delete all General

Fingerprints

Delete all Temporary

Fingerprints

Delete all SOS

Fingerprints

Delete all Admin

Fingerprints

# # #

Note

[1] and

1HowtoUse

2. Card Management(Input menu number and press [#] to manage)

Card

Registration

General Card

Registration Input User ID

Input User ID

Swipe card on the

Card Reader

Swipe card on the

Card Reader

Swipe card on the

Card Reader

Swipe card on the

Card Reader

Temporary Card

Registration

SOS Card

Registration

Admin Card

Registration

Delete an

Individual Card

Input the User ID

You Want to Delete

Delete all

Cards

Delete all

General Cards

Delete all

Temporary Card

Delete all

SOS Card

Delete all

Admin Card

SOS user and SOS card are available only when wireless communication function is on.

General card user ID:10-79, temporary card user ID: 80-89, SOS card user ID : 90-

99, and the admin card user ID: 00-09. Please swipe the card in front of the the

reader,distance between them should be within 10mm.

Note

General PIN code userID:01-07, activation PIN code userID: 08, SOS PIN

userID:09 ,and the admin PIN userID:code is 00. The activation PIN code is used

for remote unlocking by Zigbee APP, and default code is the last 6 digits of the

lock serial number.

The PIN code consists 6-12 digits. You can follow the voiceguideto input the PIN

code.Any numbers added before (after) the correct PIN code called scramble

code,the PIN code and scramblecodecannotexceed32digits.

SOSPINcodeandSOSuserareavailableonlywhenwirelesscommunication

functionison.

1HowtoUse

3. PIN Code Management (Input menu number and press [#] to manage)

Activation PIN

Code Registration2

###

PIN Code

Registration

General PIN

Code Registration Input User ID

Input User ID

Input the PIN Code

Twice in a Row

Input the PIN Code

Twice in a Row

Input the PIN Code

Twice in a Row

SOS PIN Code

Registration

Delete an Individual

PIN Code

Input the User ID

You Want to Delete

Delete all

PIN Codes

Delete all General

PIN Codes

Delete all Activation

PIN Codes

Delete all SOS

PIN Codes

# #

Note

1HowtoUse

The wireless communication will be automatically opened after installation

if the lock is equipped with wireless module.

4.WirelessCommunicationSetting((Input menu number and press [#] to manage)

 

Binding user ID: 00-09.

Bluetooth function

setting

Zigbee function

setting

Turn on

Turn oﬀ

Ubind the mobile

phone

4##

Input the user ID

Turn on

Turn oﬀ

Note
