User Guide

A single remote to control up to four devices.

IMPORTANT REGULATORY FACTORS

WIRELESS REMOTE CONTROL

This device complies with Part 15 of Federal Communications

Commission (FCC) Rules. Operation is subject to the following

conditions:

•This device may not cause harmful interference.

•This device must accept any interference that may cause

undesired operation.

•Unauthorized equipment changes may void FCC certification.

IMPORTANT SAFETY INSTRUCTIONS

You must keep safety in mind while using this device. Keep these and

any other instructions for future reference.

Installation

Observe Warnings: Carefully follow all warnings on the device

and in the operating instructions.

Heat: DO NOT place the device near heat sources such as

radiators, stoves, heat registers, or other appliances that

produce heat.

Care and Use

Cleaning: DO NOT use liquid, abrasive, solvent, or aerosol

cleaners. Use a damp cloth for cleaning.

When Not in Use: Remove the batteries if this device is to be

left unattended or unused for a long period of time.

Refer servicing to qualified personnel

when a solid object or liquid has fallen

onto or into the device.

DO NOT attempt to service this device.

Refer all servicing to qualified personnel.

Opening covers other than the battery cover

will void the warranty.

104333 1

TABLE OF CONTENTS

About the Remote Control...............................page 2

Remote Control Signals: UHF or IR.................page 2

Installing Batteries in the Remote Control........page 3

Remote Control Modes....................................page 3

Using the Remote Control Buttons ................page 4

SAT (Satellite Receiver) Mode.........................page 4

TV (Television) Mode .......................................page 8

VCR (VideoCassette Recorder) Mode.............page 10

AUX (Auxiliary) Mode for Cable TV Box..........page 12

AUX (Auxiliary) Mode for Tuner or Amplifier....page 13

Remote Control Procedures............................page 15

Controlling a Device.........................................page 15

Changing the Remote Control Address ...........page 16

Installing an Attenuator....................................page 17

Controlling Sound Volume................................page 18

Receiver Volume Control......................page 18

TV or Amplifier Volume Control............page 19

Doing the Device Code Scan...........................page 20

Finding the Device Codes................................page 21

Device Codes ...................................................page 22

TVs...................................................................page 22

VCRs................................................................page 23

DVD Players......................................................page 25

Tuners and Amplifiers......................................page 25

Cable TV Boxes...............................................page 25

Trouble-Shooting Table ...................................page 26

Limited Warranty ..............................................page 28

If You Need Help ...............................................page 30

Remote Control Signals: UHF or IR

2 104333

ABOUT THE REMOTE CONTROL

The remote control gives you easy access to all the features of a

DISH NetworkTM satellite TV system. You can set up the remote

to control up to three devices other than the satellite TV receiver.

The three devices may include a TV, a VCR, a DVD player, a cable TV

box, a tuner, or an audio amplifier.

REMOTE CONTROL SIGNALS: UHF OR IR

•The remote control uses Ultra-High Frequency (UHF) radio

signals to control the satellite TV receiver. UHF signals travel

long distances (100 feet or more) and go through walls and other

solid objects. Because UHF signals travel so far, the receiver

may respond to signals from other nearby remote controls.

To handle this problem, see Changing the Remote Control

Address on page16. If this does not work, see Installing an

Attenuator on page17.

•To use the remote to control the receiver, youmust attach the

UHF antenna to the receiver back panelUHF Remote Antenna

connection.

Note: To be able to use the remote control over the longest

possible distance, place the antenna straight up. Donot let the

antenna touch anything.

•The remote control uses Infra-Red (IR) light signals to control

devices other than the receiver. IR signals travel only short

distances (40 feet or less), and cannot go through walls or other

solid objects. You must point the remote control directly

at the device, with no objects blocking the line of sight.

Installing Batteries in the Remote Control

104333 3

INSTALLING BATTERIES IN THE

REMOTE CONTROL

The remote control comes with AAA batteries,

packaged separately. When you replace old batteries,

you should replace all of the batteries. Use batteries

of the same grade, for example, alkaline or carbon

zinc, and do not mix batteries of different grades.

Alkaline batteries provide longer battery life.

1.Press down on the slot in the battery cover

(on the back of the remote control) and slide

the cover off.

2.Insert the new batteries, making sure to match

the plus (“+”) ends with the plus markings

on the battery case.

3.Replace the battery cover by sliding the cover

back up into place.

REMOTE CONTROL MODES

To use the remote to control a device such as the satellite receiver or a

TV, you must first set up the remote to control the device,and then set

the remote to the right mode for that device.

1. Set up the remote to control the device. See Controlling a Device

on pag e15 for instructions.

2.Use the remote control mode buttons,SAT (satellite receiver),

TV, VCR (for a VCR or a DVD player), andAUX (“auxiliary,”

for a cable TV box, a tuner, or an audio amplifier) to set the

remote to the right mode for the device. To change the mode

setting, press the button for the device that you want the remote

to control. The mode button’s back light turns ON to show that

the remote is set to that mode.

The following sections describe how to use the

remote control buttons. Each section describesonly

the buttons that work inone remote control mode,

for example SAT mode or TV mode.

SAT (Satellite Receiver) Mode

4 104333

USING THE REMOTE CONTROL BUTTONS

SAT (SATELLITE RECEIVER) MODE

SAT MODE BUTTON

The remote control already is set up to control the satellite receiver.

But, you must press the SAT mode button to set the remote to SAT

mode. The SAT mode button’s back light turns ON to show that the

remote is set to SAT mode. Make sure to keep the remote inSAT

mode to use the buttons as described in this section.

AUX MODE BUTTON

Set up the remote to control the television and donot setup the remote

in AUX mode. If you do this, then with the remote in SAT mode you

can press the AUX mode button to turn the television ON or OFF.

This allows you to turn the TV on or off without leaving SAT mode.

TV/VIDEO BUTTON

If you connect the receiver using only its back panel RF or VHF

connections, use this button to switch the receiver between the satellite

signal (routed into the receiver’s Satellite In input) and another video

signal such as cable or broadcast TV antenna input (routed into the

receiver’s TV Antenna Cable In input).

MENU BUTTON

Press this button to open the Main Menu.

Some of the features described below may not

apply to your satellite receiver. See the receiver

User Guide for details about the receiver’s features.

If a remote control button is not described in this

section, it does not work in SAT mode.

SAT (Satellite Receiver) Mode

104333 5

POWER BUTTON

Press this button to turn the receiver ON or OFF. The greenPower

light on the receiver front panel lights up to show that the receiver

is ON, and goes out to show that the receiver is OFF.

PAGE UPAND PAGE DOWN (ARROW) BUTTONS

Press the Page Up button or the Page Down button to scan, page

by page, through the Program Guide, a Themes menu,

a Favorite List, an Event Timers list, or a list of channels.

MUTE BUTTON

Press this button to turn off the sound. Press it again to restore

the sound.

VOLUME BUTTON

Press the left-hand, minus (-) side of this button to lower the sound

volume. Press the right-hand, plus (+) side of this button to raise the

sound volume.

GUIDE BUTTON

Press this button to open the Program Guide. When the Program

Guide is open, press this button to switch among Favorite Lists.

SELECT BUTTON

Press this button to select a highlighted option or program in a menu.

SAT (Satellite Receiver) Mode

6 104333

UP/DOWN/LEFT/RIGHT

(ARROW) BUTTONS

•When using a menu, press these buttons to move the highlight

to an option.

•When watching a program, press the Right button to open the

Browse Banner or the Up or Down button to change channels.

•When the Browse Banner is open, press the Up or Down

button to see the Browse Banner for the next channel.

•When a menu offers a list of choices (different from menu

options), press the Up or Down button to see more choices.

•When the Program Guide is open, press these buttons to move

the highlight among the programs.

•To enter a number in a menu, highlight the place where you need

to enter the number. Then, press the Up or Down button

to increase or decrease the number in the highlighted field.

Or, you may use the Number Buttons.

•When the Browse Banner is open, press the Right or Left

button to display the current program or the next program on a

channel.

•When watching a program, press the Left button to open the

Themes menu.

RECALL BUTTON

Press this button to return to the last channel you were watching.

Press it again to switch between the last two channels that you

watched.

SAT (Satellite Receiver) Mode

104333 7

INFORMATION (INFO) BUTTON

•Press this button for more information when the

Program Guide or the Browse Banner is open, or when

watching a program.

•When a menu is open that includes aHelp option, press this

button to see help information for that menu.

•Highlight a program in a Themes list and then press this button

for more information on that program.

•When the receiver is OFF, press this button to display the

Important System Information menu.

VIEW BUTTON

•Press this button to return to watching a program.

•If you are watching a program, press this button to briefly display

the Program Banner.

•While using any menu, press this button to cancel a procedure

and return to watching a program.

CANCEL BUTTON

Press this button to cancel a procedure and to return to the previous

menu or to watching a program.

SYSTEM INFORMATION (SYS INFO) BUTTON

Press this button to display the Important System Information

menu.

TV (Television) Mode

8 104333

NUMBER BUTTONS

•When watching a program or with theProgram Guide open,

use these buttons to enter a channel number to change to that

channel.

•When the Program Guide is open, enter a number of hours

using these buttons, and then press the Right or Left arrow

button to skip the display backward or forward by that number

of hours.

•Use these buttons to enter menu option numbers. For an option

that has a number, you may do thisinstead of highlighting the

option and then pressing the Select button.

•Use these buttons to enter numbers in a menu. To do this,

first highlight the place where you need to enter the number.

Next, press a number button (or, you can use theUp/Down

arrow buttons to enter the number). Then, move the highlight

to the place for the next number that you need to enter, or press

the Select button if you are done entering numbers.

POUND BUTTON

Use this button in Changing the Remote Control Address on pag e16.

TV (TELEVISION) MODE

Some of the features described below may not

apply to the TV. See your TV owner’s manual

for details about the TV’s features. If a remote

control button is not described in this section, it

does not work in TV mode.

Tabla de contenidos

Otros manuales de Mando a distancia de Dish Network

Dish Network

Dish Network Platinum Remote Control Manual de usuario

Dish Network

Dish Network 311k Manual de usuario

Dish Network

Dish Network 40.0 Manual de usuario

Dish Network

Dish Network 20.1 Manual de usuario

Dish Network

Dish Network 54.0 Manual de usuario

Dish Network

Dish Network EZ Manual de usuario

Dish Network

Dish Network Remote Control Manual de usuario

Dish Network

Dish Network 129418 Manual de usuario

Dish Network

Dish Network 104333 Manual de usuario

Dish Network

Dish Network 52.0 Manual de usuario

Dish Network

Dish Network EZ Manual de usuario

Dish Network

Dish Network 11 Hoja de especificaciones

Dish Network

Dish Network 135331 Manual de usuario

Dish Network

Dish Network Platinum Plus 121150 Manual de usuario

Dish Network

Dish Network 176842 Manual de usuario

Dish Network

Dish Network 20.0 Manual de usuario

Dish Network

Dish Network Digital PVR Manual de usuario

Dish Network

Dish Network 20.0 Manual de usuario

Dish Network

Dish Network Platinum PVR Remote Control Manual de usuario

Dish Network

Dish Network ViP 211 Series Manual de usuario

Dish Network

Dish Network ViP 922 Slingloded DVR Manual de usuario

Dish Network

Dish Network 3.1 Manual de usuario

Dish Network

Dish Network Solo 301 Instrucciones de uso

Dish Network

Dish Network 20.1 Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación

Dish Network digital remote control Manual de usuario

Manuales populares de Mando a distancia de otras marcas
