WARNING AND ATTENTION SYMBOLS

You must be aware of safety when you install and use this system. This User Guide

provides various procedures. If you do some of these procedures carelessly, you could

injure or kill yourself or damage equipment or property. Some other procedures require

special attention.

FOR YOUR SAFETY

The WARNING! symbol means that if you are not careful:

You could injure or kill yourself, or

You could damage equipment or property.

The ATTENTION! symbol means you should pay special

attention to:

Important instructions for using the system, or

Important instructions for maintaining the system.

The Class II Symbol alerts qualified service personnel to use

only identical replacement parts in this apparatus.

Do not try to open the case of the receiver. There is risk of

electrical shock, which may cause damage to the receiver

and/or personal injury or death to you. There are no user-

serviceable parts inside the receiver. Opening the receiver

case or making unauthorized changes will void the warranty.

To reduce the risk of fire or electric shock, do not expose this

appliance to rain or moisture.

inside_front_cover.fm Page 1 Friday, February 11, 2005 4:17 PM

TABLE OF CONTENTS

Safety Instructions.............................................. 2

Introduction ......................................................... 3

Setting Up the Kit ................................................ 5

Setting Up the Signal Converter..........................5

Setting Up the Remote Control...........................9

Remote Control Operation ............................... 10

Changing the Receiver and Remote

Control Addresses............................................. 10

Checking the Remote Control Address..............11

Setting Up to Control Other Devices..................11

Operating Modes............................................... 17

Controlling the Satellite Receiver...................... 17

Controlling a TV (or a Second TV)....................25

Controlling a VCR (or a Second VCR

or a DVD Player)...............................................27

Controlling a Tuner or Amplifier.........................29

Changing Frequencies...................................... 31

Device Codes..................................................... 33

Troubleshooting the Kit.................................... 42

Limited Warranty............................................... 45

Advance Exchange Program ............................ 46

Post Receipt Exchange Program...................... 46

If You Need Help............................................... 47

Regulatory Factors............................................ 48

Pyramid.book Page 1 Wednesday, February 16, 2005 4:00 PM

SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding-type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided

for your safety. If the provided plug does not fit into your outlet, consult an electri-

cian for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at plugs, con-

venience receptacles, and the point where they exit from the apparatus.

11. Use only attachments/accessories specified by the manufacturer.

12. Unplug this apparatus during lightning storms or when unused for long periods of

time.

13. Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as the power supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the appara-

tus has been exposed to rain or moisture, does not operate normally, or has been

dropped.

Apparatus shall not be exposed to dripping or splashing and no objects filled

with liquids, such as vases, shall be placed on the apparatus.

INSTALLATION

Observe Warnings: Carefully follow all warnings on the device and in the operating

instructions.

Heat: DO NOT place the device near heat sources such as radiators, stoves, heat registers,

or other appliances that produce heat.

CARE AND USE

Cleaning: DO NOT use liquid, abrasive, solvent, or aerosol cleaners. Use a damp cloth for

cleaning.

When Not in Use: Remove the batteries if this device is to be left unattended or unused for a

long period of time.

Refer servicing to qualified personnel when a solid object

or liquid has fallen onto or into the device.

DO NOT attempt to service this device. Refer all

servicing to qualified personnel. Opening covers other

than the battery cover will void the warranty.

Pyramid.book Page 2 Wednesday, February 16, 2005 4:00 PM

INTRODUCTION

The IR-to-UHF Pro Upgrade Kit lets you use an ultra-high frequency

(UHF) remote to control an infrared (IR) DISH Network satellite TV

receiver from much farther away than with an IR remote control, even

through walls that block IR signals.

Note: The remote control/converter combination included in this kit

works only with compatible DIS H Network receivers, and is not for

any other devices. Compatible DISH Network receivers include all

models except Model 7100/7200 (DISHPlayer), Model HM-

DSR100RU (JVC-DVHS), Model 2000, Model 4000, and Model

5000. The UHF Pro remote can control other devices (a TV, for

example) at short distances because it sends IR signals to such devices.

After you set up the kit, when you press any button on the UHF Pro

remote control, the remote control sends a UHF signal to the converter.

Figure 1. UHF Pro Remote Control sends signals to the Converter

Because the UHF signal can go through walls and other objects on its

way to the converter, you can use the UHF Pro remote control in any

room.

Figure 2. UHF Pro signals go through walls and other objects

Pyramid.book Page 3 Wednesday, February 16, 2005 4:00 PM

The converter gets the UHF signal, changes it to IR, and sends the IR

signal to the receiver. The best way to get the IR signal to the receiver

is with the IR extender cable because the signal doesn’t have to go

through the air, but you can also use just the converter to send the

signal to the receiver (see the example in Figure 3).

Figure 3. The Converter changes the UHF Pro

signals to IR to control the receiver

The remote control that comes with the kit gives you easy access to all

the features of a DISH Network satellite TV receiver. You can set up

the remote to control the satellite TV receiver and up to three other

devices. These devices can be a TV, a VCR or DVD player, and a third

device. To control these devices, they must be in the same room as the

remote control.

Note: This remote control may have more features than what your

satellite receiver supports. See your receiver user’s guide for

information.

The remote control included with this kit uses only UHF radio signals

to control the satellite receiver but uses IR to control other devices.

•UHF signals usually travel long distances (200 feet in open air)

and can go through walls and other solid objects. You don’t have

to point a UHF Pro remote control toward the receiver, because

UHF signals spread out in all directions.

•IR signals usually travel only short distances (40 feet or less), and

can’t go through walls or other solid objects. You must point an IR

remote control toward the device, because IR signals travel in

straight lines. There can’t be any objects that block the signal path.

Pyramid.book Page 4 Wednesday, February 16, 2005 4:00 PM

SETTING UPTHE KIT

The kit includes a UHF Pro remote control, batteries, an IR extender

cable, an IR clip, an AC adapter, a converter, and a UHF antenna.

Figure 4. Parts of the IR-to-UHF Pro Upgrade Kit

SETTING UPTHE SIGNAL CONVERTER

1. Make sure you fully install the satellite TV system. See the satellite

receiver’s User Guide.

2. Select a location for the converter that has access to a 110 V power

outlet and is close enough for the IR extender cable to reach the

satellite receiver.

3. Refer to Figure 5 to complete steps a through d.

Figure 5. Converter Back Panel

a. Attach the antenna to the REMOTE ANTENNA

on the back of the converter. You may need to

move the antenna around to find where it

works best.

Pyramid.book Page 5 Wednesday, February 16, 2005 4:00 PM

Tighten the connection only by hand. If you use a

wrench, you may over-tighten the connection and

damage your equipment. Such damage is not covered

by the Limited Warranty.

b. Make sure the REMOTE KEY switch matches the UHF Pro

key at the bottom of the remote. If the switch setting does not

match the key or if you'd like to change these settings, see

Changing Frequencies on page 31.

c. Plug in the IR extender cable to the IR EXTENDER

connection on the back of the converter.

d. Plug in the AC adapter to the POWER connection

on the back of the converter.

4. Refer to Figures 6 and 7 to place the IR extender’s IR head directly

in front of the receiver’s front panel IR sensor. The sensor may be

in an egg-shaped dimple in the front panel, or behind a lens (the IR

signal goes through the panel lens).

Note: The IR extender cable is the best way to get the IR signal

from the converter to the receiver because the signal doesn’t have

to go through the air.

Figure 6. IR Sensor in an egg-shaped dimple

Pyramid.book Page 6 Wednesday, February 16, 2005 4:00 PM

Figure 7. IR Sensor behind a lens

5. To secure the IR head, peel the paper off the strip of tape on the

head (the IR signal goes through the tape), and stick the head into

place.

6. For DISH Player-DVR 522 and DISH Player-DVR 625, place the

IR head about ¼” from the left side of the front panel lens.

Figure 8. DISH Player-DVR 522 IR sensor

7. For DISH 301, DISH 311, DISH 322 receivers, you can use the IR

head clip to set up the IR extender cable.

Figure 9. Attach the IR Extender Head to

the receiver’s bottom panel

Pyramid.book Page 7 Wednesday, February 16, 2005 4:00 PM

a. Attach the IR head clip to the receiver’s bottom panel, on the

grate directly behind the front panel’s IR sensor. You must

center the clip on the second slot from the left. There is a CLIP

label on the bottom panel of some DISH 301, DISH 311, and

DISH 322 receivers.

b. Fit the IR head into the IR head clip, and route the IR extender

cable out through the clip’s slot.

8. Route the IR extender cable under the back of the receiver, to the

converter.

9. You can also use just the converter to send the signal through the

air to the receiver.

Figure 9. UHF Pro signals are converted

to IR and sent through the air to the receiver

a. Make sure you put the converter no more than 20 feet away

from the receiver, and that the converter has a clear signal path

to the receiver.

b. Make sure the lens of the converter points toward the receiver’s

front panel.

10. Plug the power cord into a wall outlet.

11. Press any button on the remote control. A red light on the converter

turns on whenever it receives a signal from the remote control.

Pyramid.book Page 8 Wednesday, February 16, 2005 4:00 PM

Tabla de contenidos

Otros manuales de Mando a distancia de Dish Network

Dish Network

Dish Network 54.0 Manual de usuario

Dish Network

Dish Network Digital PVR Manual de usuario

Dish Network

Dish Network SoloDVR ViP 612 Manual de uso y mantenimiento

Dish Network

Dish Network 54.0 Manual de usuario

Dish Network

Dish Network 20.0 Manual de usuario

Dish Network

Dish Network 3.1 Manual de usuario

Dish Network

Dish Network BASIC REMOTE Manual de usuario

Dish Network

Dish Network 176842 Manual de usuario

Dish Network

Dish Network Platinum PVR Remote Control Manual de usuario

Dish Network

Dish Network 52.0 Manual de usuario

Dish Network

Dish Network 311k Manual de usuario

Dish Network

Dish Network Duo ViP 222 Manual de usuario

Dish Network

Dish Network Platinum Plus 121150 Manual de usuario

Dish Network

Dish Network Platinum Remote Control Manual de usuario

Dish Network

Dish Network EZ Manual de usuario

Dish Network

Dish Network Solo 301 Instrucciones de uso

Dish Network

Dish Network 52.0 Manual de usuario

Dish Network

Dish Network ViP 211 Series Manual de usuario

Dish Network

Dish Network ViP 922 Slingloded DVR Manual de usuario

Dish Network

Dish Network 6.3 Manual de usuario

Dish Network

Dish Network 40.0 Manual de usuario

Dish Network

Dish Network digital remote control Manual de usuario

Dish Network

Dish Network 40.0 Manual de usuario

Dish Network

Dish Network 159263 Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
