Precision 7770

External Display Connection Guide

Regulatory Model: P115F

Regulatory Type: P115F001

July 2022

Rev. A00

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use of your product.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid

the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

subsidiaries. Other trademarks may be trademarks of their respective owners.

Chapter 1: Before you begin.......................................................................................................... 4

Check the graphics options on your computer............................................................................................................ 4

External display connection mode................................................................................................................................... 4

UMA Graphics mode..................................................................................................................................................... 5

Hybrid Graphics mode.................................................................................................................................................. 5

Hybrid Graphics mode with Direct Output.............................................................................................................. 5

Discrete Graphics Mode...............................................................................................................................................5

Turn off the internal display..............................................................................................................................................6

Chapter 2: Connect displays..........................................................................................................7

Supported Display................................................................................................................................................................7

Chapter 3: Troubleshooting...........................................................................................................9

Chapter 4: Getting help and contacting Dell.................................................................................10

Contents

Contents 3

Before you begin

You can connect up to two 4K external displays or one 8K and above display using the two Thunderbolt 4 on your Precision

7770.

Total number of displays supported:

●Two 4K external displays: 2 ports (Thunderbolt 4)

●One 8K

Before you begin, ensure that you:

●Check the graphics options on your computer

●Check the ports available on your external displays and decide the Mode of connection.

Check the graphics options on your computer

The number of external displays supported depends on the type of graphics card available on your computer:

●The integrated graphics card can support a maximum of 4 displays

●The discrete graphics card can support a maximum of 4 displays

NOTE:

●Dell Docking Station—WD19DCS display behavior follows the host the Thunderbolt 4 (USB Type-C) port

●The HDMI 2.1 port and MFDC (MFDP) Type-C port on the WD19DCS docking station cannot support dual monitors

simultaneously

For more information on the graphics card available on your computer, run Dell SupportAssist on your computer, or scan your

hardware at www.dell.com/support.

The following are the graphic options that may be installed in your computer:

●Intel UHD Graphics (Integrated graphics)

●NVIDIA RTX A1000 (Discrete graphics)

●NVIDIA RTA A2000 (Discrete graphics)

●NVIDIA RTA A3000 (Discrete graphics)

●NVIDIA RTA A4500 (Discrete graphics)

●NVIDIA RTA A5500 (Discrete graphics)

●NVIDIA GeForce RTX 3080Ti (Discrete graphics)

External display connection mode

External display connection mode selected in the BIOS defines the number of displays supported by the computer.

External display connection modes are:

●UMA Graphics mode

●Hybrid Graphics mode

●Hybrid Graphics mode with Direct Output

●Discrete Graphics mode

4 Before you begin

UMA Graphics mode

Table 1. UMA Graphics mode

Graphic card type Supported ports

Integrated GPU ●HDMI

●USB-C (non-Thunderbolt 4)

●Two Thunderbolt 4

●Laptop display

Hybrid Graphics mode

To enable Hybrid Graphics mode in the computer's BIOS:

1. Restart the system and immediately press <F2> to enter the BIOS.

2. On the BIOS screen, select Video.

3. Select Switchable Graphics.

4. Select Enable Switchable Graphics.

5. Save changes and exit the computer's BIOS.

For more information about accessing and configuring the BIOS, see the computer's Service Manual at www.dell.com/support.

Table 2. Hybrid Graphics mode

Graphic card type Supported ports

Discrete GPU ●HDMI

●USB-C (non-Thunderbolt 4)

●Two Thunderbolt 4

Integrated GPU Laptop display, Two Thunderbolt 4

Hybrid Graphics mode with Direct Output

To enable Hybrid Graphics mode with Direct Output in the computer's BIOS:

1. Restart the system and immediately press <F2> to enter the BIOS.

2. On the BIOS screen, select Video.

3. Select Switchable Graphics.

4. Select Enable Switchable Graphics.

5. Select Discrete Graphics Controller Direct Output Mode.

6. Save changes and exit the computer's BIOS

For more information about accessing and configuring the BIOS, see the computer's Service Manual at www.dell.com/support.

Table 3. Hybrid Graphics mode with Direct Output

Graphic card type Supported ports

Discrete GPU ●HDMI

●USB-C (non-Thunderbolt 4)

●Two Thunderbolt 4

Integrated GPU Laptop display

Discrete Graphics Mode

To enable Discrete Mode in the computer's BIOS:

1. Restart the system and immediately press <F2> to enter the BIOS.

2. On the BIOS screen, select Video.

Before you begin 5

3. Select Switchable Graphics.

4. Uncheck Enable Switchable Graphics.

5. Save changes and exit the computer's BIOS

For more information about accessing and configuring the BIOS, see the computer's Service Manual at www.dell.com/support.

Table 4. Discrete Graphics mode

Graphic card type Supported ports

Discrete GPU ●Laptop display

●HDMI

●USB-C (non-Thunderbolt 4)

●Two Thunderbolt 4

Turn off the internal display

There may be instances where you may want to turn off the computer's internal display to connect more external displays.

You can turn off the LCD display of your computer by using the Intel HD Graphics Command Center.

To turn off the display:

1. In the Windows search bar, type Intel Graphics Command Center and press <Enter>.

2. Accept the Intel Graphics Command Center software licence agreement.

3. On the Intel Graphics Command Center window, click Display. The list of active displays is listed under the Connected

Displays section.

4. Click the ellipsis (...) in the top-right corner of your primary display, then click Extend > Display 2.

5. Click the ellipsis (...) in the top-right corner of display 2, then click Make Display Primary.

6. Click the ellipsis (...) in the top-right corner of your computer's display, then click Disable.

6Before you begin

Connect displays

Depending on the connectors available on your external display, you can connect the displays to the Thunderbolt 4 (USB

Type-C) ports, HDMI port, Mini DisplayPort on your computer using:

●Thunderbolt 4 cables, adapters or docking stations

●USB Type-C cables. adapters or docking stations

●HDMI cables or adapters

NOTE: To experience the full resolution supported by your external displays, use appropriate cables. For examples, use

DisplayPort or HDMI cables for 4K and above resolution.

Supported Display

Table 5. Supported display via host display port under different modes

Graphics card mode Connect to External Displays

One External Display Two External

Displays

Three External

Displays

Four External Displays

(Internal Display Off)

UMA ●HDMI: 3840 x 2160

@ 60 Hz

●HDMI: 3840 x 2160

@ 60 Hz

●Type-C: 7680 x

4320 @ 60 Hz

●HDMI: 3840 x 2160

@ 60 Hz

●Type-C: 7680 x

4320 @ 60 Hz

●Type-C: 7680 x

4320 @ 60 Hz

●HDMI: 3840 x 2160 @ 60

●Type-C: 7680 x 4320 @

60 Hz

●Type-C: 7680 x 4320 @

60 Hz

●Type-C: 7680 x 4320 @

60 Hz

Hybrid mode HDMI/Type-C: 7680 x

4320 @ 60 Hz

●HDMI: 7680 x

4320 @ 60 Hz

●Type-C: 7680 x

4320 @ 60 Hz

●HDMI: 7680 x

4320 @ 60 Hz

●Type-C: 7680 x

4320 @ 60 Hz

●Type-C: 7680 x

4320 @ 60 Hz

●HDMI: 7680 x 4320 @ 60

●Type-C: 7680 x 4320 @

60 Hz

●Type-C: 7680 x 4320 @

60 Hz

●Type-C: 7680 x 4320 @

60 Hz

Hybrid mode with

Direct Output

HDMI/Type-C: 7680 x

4320 @ 60 Hz

●HDMI: 7680 x

4320 @ 60 Hz

●Type-C: 7680 x

4320 @ 60 Hz

●HDMI: 7680 x

4320 @ 60 Hz

●Type-C: 3840 x

2160 @ 60 Hz

●Type-C: 3840 x

2160 @ 60 Hz

●HDMI: 3840 x 2160 @ 60

●Type-C: 3840 x 2160 @

60 Hz

●Type-C: 3840 x 2160 @

60 Hz

●Type-C: 3840 x 2160 @

60 Hz

Discrete Mode HDMI/Type-C: 7680 x

4320 @ 60 Hz

●HDMI: 7680 x

4320 @ 60 Hz

●Type-C: 7680 x

4320 @ 60 Hz

Internal Display Off

●HDMI: 7680 x

4320 @ 60 Hz

●Type-C: 3840 x

2160 @ 60 Hz

●Type-C: 3840 x

2160 @ 60 Hz

●HDMI: 3840 x 2160 @ 60

●Type-C: 3840 x 2160 @

60 Hz

●Type-C: 3840 x 2160 @

60 Hz

●Type-C: 3840 x 2160 @

60 Hz

Connect displays 7

*When connecting via docking station, additional external displays can be connected under Hybrid mode (with Internal Display

Off).

NOTE: Discrete mode and UMA modes are disabled when additional external displays are connected via docking station.

Table 6. Supported display via docking station under Hybrid mode

Hybrid mode

TBT Dock Type-C TBT + DP + DP + HDMI/MFDP: *4k@60 Hz +

2k@60 Hz*3

●Up to 3 if internal display

●Up to 4 if internal display

off

●Connect either HDMI

or MFDP only, do not

connect both of them

Single Cable Dock ●DP + DP + HDMI : FHD@60 Hz*3

●DP + DP + MFDP : FHD@60 Hz*3

Dual Cable Dock ●DP + DP + HDMI: 2k@60 Hz*3

●DP + DP + MFDP: 2k@60 Hz*3

Table 7. Supported display via docking station under Discrete mode

Discrete mode

TBT Dock ●DP + DP: 8K@60 Hz*1

●DP + HDMI: 4K@60 Hz*2

●MFDP/HDMI+DP1+DP2: 4K@60 Hz*3

●TBT + DP1+DP2+HDMI: 4K@60 Hz*4

●Up to 3 if internal display

●Up to 4 if internal display

off

●Connect either HDMI

or MFDP only, do not

connect both of them

Single Cable Dock ●DP + DP: 4K@60 Hz *2

●DP + HDMI: 4K@60 Hz*2

●DP + MFDP: 4K@60 Hz*2

Dual Cable Dock ●DP + DP: 8K@60 Hz*1

●DP+DP+HDMI/MFDP: 4K@60 Hz*3

8 Connect displays

Troubleshooting

Question

When I connect an 8K display using the USB Type-C to DisplayPort adapter, the monitor resolution is 4k.

Cause

This may be because of incorrect settings in the BIOS.

Workaround

Ensure BIOS setting is special graphics mode or discrete graphics mode.

For more information about accessing and configuring the BIOS, see the computer's Service Manual at www.dell.com/support.

Question

When I connect an 8K display using the USB Type-C to DisplayPort adapter, the display resolution can reach to 8K, but refresh

rate cannot reach to 60Hz.

Workaround

Connect the 8K display with the dual USB Type-C to DisplayPort adapter or one USB Type-C to DisplayPort adapter + one Mini

DisplayPort.

Connect the 8K display with dual cable WD19DCS dock dual DisplayPort or Host dual USB Type-C to DisplayPort adapter or

Host DisplayPort adapter + one Mini DisplayPort.

Troubleshooting 9

Getting help and contacting Dell

Self-help resources

You can get information and help on Dell products and services using these self-help resources:

Table 8. Self-help resources

Self-help resources Resource location

Information about Dell products and services www.dell.com

My Dell app

Tips

Contact Support In Windows search, type Contact Support, and press

Enter.

Online help for operating system www.dell.com/support/windows

Access top solutions, diagnostics, drivers and downloads, and

learn more about your computer through videos, manuals and

documents.

Your Dell computer is uniquely identified by a Service Tag or

Express Service Code. To view relevant support resources for

your Dell computer, enter the Service Tag or Express Service

Code at www.dell.com/support.

For more information on how to find the Service Tag for your

computer, see Locate the Service Tag on your computer.

Dell knowledge base articles for a variety of computer

concerns

1. Go to www.dell.com/support.

2. On the menu bar at the top of the Support page, select

Support > Knowledge Base.

3. In the Search field on the Knowledge Base page, type the

keyword, topic, or model number, and then click or tap the

search icon to view the related articles.

Contacting Dell

To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell.

NOTE: Availability varies by country/region and product, and some services may not be available in your country/region.

NOTE: If you do not have an active Internet connection, you can find contact information about your purchase invoice,

packing slip, bill, or Dell product catalog.

10 Getting help and contacting Dell

Otros manuales para Precision 7770

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de De oficina de Dell

Dell

Dell Inspiron 5720 Manual de usuario

Dell

Dell Vostro 400 Manual de usuario

Dell

Dell OptiPlex 5060 Manual de usuario

Dell

Dell T3400 - Precision - 2 GB RAM Manual de usuario

Dell

Dell OptiPlex 7040 Manual de usuario

Dell

Dell Precision Tower 3630 Manual de usuario

Dell

Dell OptiPlex FX160 Manual de usuario

Dell

Dell Wyse Z90D7 Manual de usuario

Dell

Dell OptiPlex 790 Manual del propietario

Dell

Dell Dimension 8300 Series Manual de usuario

Dell

Dell Inspiron 20 3000 Series Manual de operación y mantenimiento

Dell

Dell OptiPlex 3020 Manual de usuario

Dell

Dell OptiPlex 980 - Desktop Manual de usuario

Dell

Dell Inspiron 5570 Manual de operación y mantenimiento

Dell

Dell OptiPlex 7010 Manual del propietario

Dell

Dell Dimension XPS Gen 4 Manual de usuario

Dell

Dell External OEMR R420 Manual de usuario

Dell

Dell OptiPlex 745 Manual de usuario

Dell

Dell Latitude 5400 Chrome Manual de operación y mantenimiento

Dell

Dell Precision T1700 Manual de usuario

Dell

Dell Inspiron 24 Manual de usuario

Dell

Dell Precision Workstation T1500 Manual de usuario

Dell

Dell OptiPlex 3240 Manual de usuario

Dell

Dell INSPIRON DCSLF Manual de usuario

Manuales populares de De oficina de otras marcas

HP m9060n - Pavilion - Elite Hoja de especificaciones

Asus

Asus E210 Series Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

HP Presario SV7000 - Desktop PC Manual de usuario

HP ProDesk 400 G5 Manual

Logitech

Logitech MK320 Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

HP Z1 Manual de usuario

Everex

Everex eXplora Manual de usuario

Lenovo

Lenovo ThinkCentre M75e Manual de usuario

Compaq

Compaq iPAQ Internet Device Manual de usuario
