Danfoss HCS6101-3 Instrucciones de uso

Installation and Setting Instructions

Electronic Programmable and Non-Programmable Fan Coil Thermostats

6000 series with independent fan common

Specication

Power supply: 24 volt powered models - 20-30 Vac, 50/60Hz

230 volt powered models - 210-250 Vac, 50/60Hz

Temperature range: Heating stage - O-5-30°C

Cooling stage - 16-37°C-O

Temperature accuracy: ± 0.5°C

Deadzone adjustment: 1, 2, 3 or 4°C

Voltage rating of contacts: 20-250 Vac, 50/60Hz

Current rating of contacts: 10mA - 3A resistive, 1A inductive

Switching action: Voltage free SPDT contacts, Type 1B

Time accuracy: ± 1 minute

Memory retention: 24V & 230V models: 15 days

Battery model: 1 minute for battery change

IP rating: IP30

Dimensions (mm): 130 x 100 x 38 (W x H x D)

Control pollution situation: Degree 2

Rated impulse voltage: 2.5 KV

Ball pressure test: 75°C

Applications

HC & HCT Models

Features 24 volt 230 volt

Type Code Type Code

Heat or cool operation, selectable at time of installation

3-speed fan output HCS6101-3 087N722500

Heat & cool systems (with auto changeover), for use in 4-pipe systems

3-speed fan output HCT6113-3 087N759326

HC & HCT Models with 3 speed fan

(4 pipe auto change-over)

HCS & HCST Models with 3 speed fan

(Heat or Cool)

HCS & HCST Models

Wiring

Ordering Details

Installation

1. Thermostat Location 2. Unpacking the Thermostat

3. Separating the Wallplate

4. Fitting the Thermostat to the Wall 5. Wiring Access - Incorrect

6. Wiring Access - Correct 7. Cable Size

Max cable size

1.5mm2

Fitting the Thermostat to the Wallplate

Ensure unit is rmly in place

DIL Switch Settings (see rear of circuit board)

ON/OFF

COMPRESSOR

DELAY ON

HEATING

THERMOSTAT

4 EVENTS

EACH DAY *

CHRONO-

PROPORTIONAL

COMPRESSOR DELAY

OFF

COOLING

THERMOSTAT

2 EVENTS EACH DAY

ON/OFF

COMPRESSOR

DELAY ON

NOT USED

4 EVENTS

EACH DAY*

CHRONO-

PROPORTIONAL

COMPRESSOR DELAY

OFF

NOT USED

2 EVENTS EACH DAY

HCS Models HC Models

* not used on non-programmable models * not used on non-programmable models

Danfoss can accept no responsibilty for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to

products already on order provided that such alterations can be made without subsequent changes being necessary in specications already agreed.

Part No: 33071v03 10/07

Danfoss Randall Limited

Ampthill Road,

Bedford, MK42 9ER

Tel: (01234) 364621 Fax: (01234 219705

Email: danfossrandall@danfoss.com

Website: www.danfoss-randall.co.uk
